1150 / 1378
1150
ACCESSORIES FOR COOLANT FEED, MULTIPLEX SYSTEM
1150
13
Prices in EURO - VAT not included
8638GB
Orig. Hartner - Art. 86690-63,5
COOLANT RINGS
Made of steel. Lubricant hole 1/4 G. Suitable for tool bit holder Art. 8627 G/8627 GL. (Morse taper
shank 5). Diameter (D) 127mm, diameter (D1) 63.5mm, height (L) 60mm, threaded shank (M) 12.
8638GB
Each 723,00
Product running out of stock.
vuoto
ACCESSORIESFORCOOLANTFEED,MULTIPLEXSYSTEM
8638GE
8638GF
Orig. Hartner - Art. 82578-90
RAPID CONNECTIONS
Made of brass. Threaded internal shank 1/4 G, hose connection Ø 9mm.
Suitable for pipes Art. 8638 GL.
8638GE
Each 95,70
Product running out of stock.
vuoto
Orig. Hartner - Art. 82578-13
Made of brass. Threaded internal shank 1/2 G, hose connection Ø 13mm.
Suitable for pipes Art. 8638 GM.
8638GF
Each 246,00
Product running out of stock.
vuoto
ACCESSORIESFORCOOLANTFEED,MULTIPLEXSYSTEM
8638GL
8638GM
Orig. Hartner - Art. 82571-13,16
COOLANT HOSES, MADE OF STEEL
External threads 1/4 G.
Suitable for rings Art. 8638 GA and chucks Art. 8637 GA to 8637 GM.
Length 200mm.
8638GL
Each 26,80
Product running out of stock.
vuoto
Orig. Hartner - Art. 82571-20,96
External threads 1/2 G.
Suitable for rings Art. 8638 GB.
Length 200mm.
8638GM
Each 27,70
vuoto
Product running out of stock.
ACCESSORIESFORCOOLANTFEED,MULTIPLEXSYSTEM
8638GP
Orig. Hartner - Art. 86807
TORX SCREWS FOR TOOL BIT HOLDER
Thread Ø
M.
2x4 2,5x5 2,5x7 3x6 3x8 3,5x10 4x15 5x20
TORX screw
Gr
6
7
7
9
9
15
20
25
8638GP
Each 3,88 3,98 3,98 4,24 4,24 4,42 4,96 5,24
vuoto
ACCESSORIESFORCOOLANTFEED,MULTIPLEXSYSTEM
STUB DRILLS, RIGHT HAND CUTTING
8642G
HSS
Prod. SCU
DIN 1897. Rolled type. HSS
EXTRA-SHORT pattern. For automatic machines.
Cylindrical shank.
Ø
mm
1
1,2 1,5
2
2,2 2,5 2,8
3
3,2 3,5 3,8
4
4,2 4,5 4,8
Overall length
mm 26
30
32
38
40
43
46
46
49
52
55
55
55
58
62
Helix length
mm 6
8
9
12
13
14
16
16
18
20
22
22
22
24
26
8642G
Each 0,88 0,90 0,74 0,24 0,36 0,30 0,42 0,36 0,36 0,36 0,42 0,36 0,42 0,42 0,60
Ø
mm
5
5,2 5,5 5,8
6
6,5
7
7,5
8
8,5
9
9,5
10
Overall length
mm 62
62
66
66
66
70
74
74
79
79
84
84
89
Helix length
mm 26
26
28
28
28
31
34
34
37
37
40
40
43
8642G
Each 0,48 0,66 0,54 0,72 0,60 0,72 0,78 0,96 1,18 1,42 1,54 1,66 2,14
Up to Ø 10mm in 10pcs packing units.
Sizes mm 1 - 1,2 and 1,5 running out of stock.
vuoto
STUBDRILLS,RIGHTHANDCUTTING
