1156 / 1378
1156
CENTRE DRILLS
1156
13
Prices in EURO - VAT not included
CENTRE DRILLS
8660G
HSS
Prod. SCU
DIN 333 – Form A. HSS.
For drilling metals and steel. Right-hand cutting.
60° countersink taper .Cutting angle 135°.
Tip Ø
mm
1
1,25
1,6
2
2,5
3,15
4
Body Ø
mm 3,15
3,15
4
5
6,3
8
10
Overall length
mm 31,5
31,5
35,5
40
45
50
56
8660G
Each 1,54
1,54
1,74
2,12
2,30
3,08
5,00
Tip Ø
mm
5
6,3
8
10
Body Ø
mm 12,5
16
20
25
Overall length
mm 63
71
80
100
8660G
Each 6,34 12,50 26,10 61,60
vuoto
CENTREDRILLS
DRILL BITS WITH EXAGONAL SHANK 1/4
8665
HSSG
1/4 ,,
Orig. Völkel - Art. 671
Short type, 1/4 hex drive, suitable for use with screwdrivers, screwers, drills, etc
HSS-G.
For drilling metals with resistance up to R 600 N/mm², light alloys, plastic material, etc.
Ø
mm
1
1,5
2
2,5
3
3,3
3,5
4
Overall length
mm 32
32
34
36
38
40
40
44
Helix length
mm 7
10
12
14
16
18
18
20
8665
Each 4,50 4,50 4,50 4,50 4,50 4,50 4,50 4,50
Ø
mm
4,2
4,5
5
5,5
6
6,5
6,8
7
Overall length
mm 45
46
50
50
50
50
50
50
Helix length
mm 20
24
26
26
26
30
30
30
8665
Each 4,50 4,50 4,50 4,64 4,64 4,64 4,64 4,64
Ø
mm
7,5
8
8,5
9
9,5
10 10,2
Overall length
mm 51
51
53
53
54
54
54
Helix length
mm 32
32
33
33
38
38
38
8665
Each 5,44 5,44 6,24 6,24 7,04 7,04 7,04
For assortments with bits for metals and wood see Art. 4525 GB.
vuoto
DRILLBITSWITHEXAGONALSHANK1/4
8665A
HSSG
1/4 ,,
Orig. Völkel - Art. 67100
Assortment of 19 points, 0.5 mm progression.
Contents:
1 pcs. per size Art. 8665 Ø 1-1.5-2-2.5-3-3.5-4-4.5-5-5.5-6-6.5-7-7.5-8-8.5-9-9.5-10mm.
In plastic holder.
8665A
Each 77,70
vuoto
DRILLBITSWITHEXAGONALSHANK1/4
8665E
HSS
1/4 ,,
Prod. SCU
Short type, 1/4 - E 6.3 hex drive, suitable for use with screwdrivers, screwers, drills, etc
In HSS.
For drilling metals with resistance up to R 600 N/mm², light alloys, plastic materials, etc.
Ø
mm
1
2
3
4
5
6
Overall length
mm 57
70
80
95
110
110
Helix length
mm 12
25
32
40
50
55
8665E
Each 1,26
1,36
1,48
1,92
2,50
3,18
vuoto
DRILLBITSWITHEXAGONALSHANK1/4
GONIOMETER FOR TWIST DRILL TO GRIND
8680G
Prod. SCU
Suitable for positioning drills against the grinding wheel. The positioning is carried out on 2 axes.
Micrometric adjustment for drill feed.
Aluminium alloy body with steel adjusting bars.
For drills from 3mm to 19mm with cylindrical shank.
8680G
Each 30,10
vuoto
GONIOMETERFOR TWISTDRILLTOGRIND
