END MILLS
1161
13
Prices in EURO - VAT not included
8738
HSS-E-8%
Two-flute, ball nose end mills. Short series. ISO 1641/1.
Weldon shank. Cutting tolerance e8.
HSS-E COBALT 8%
Ø
mm
3
4
5
6
7
8
9
10
Overall length
mm 49
51
52
52
60
61
61
63
Cutting edge length
mm 5
7
8
8
10
11
11
13
Drive Ø
mm 6
6
6
6
10
10
10
10
8738
Each 24,90 24,90 24,90 24,90 31,00 31,00 34,70 34,70
Ø
mm
11
12
13
14
15
16
18
20
Overall length
mm 70
73
73
73
73
79
79
82
Cutting edge length
mm 13
16
16
16
16
19
19
22
Drive Ø
mm 12
12
12
12
12
16
16
20
8738
Each 42,70 42,70 48,80 48,80 55,90 55,90 65,90 77,50
vuoto
ENDMILLS
8738E
HSS-E-8%
TiAIN
Product description as Art. 8738
HSS-E COBALT 8%, TiAIN coating.
Ø
mm
4
5
6
8
10
12
14
Overall length
mm 51
52
52
61
63
73
73
Cutting edge length
mm 7
8
8
11
13
16
16
Drive Ø
mm 6
6
6
10
10
12
12
8738E
Each 40,70 40,70 40,70 50,50 56,50 68,50 78,30
Ø
mm
16
18
20
Overall length
mm 79
79
82
Cutting edge length
mm 19
19
22
Drive Ø
mm 16
16
20
8738E
Each 90,40 107,00 123,00
vuoto
ENDMILLS
8739
HSS-E-8%
Two-flute, ball nose end mills. Long series. ISO 1641/1.
Weldon shank. Cutting tolerance e8.
HSS-E COBALT 8%.
Ø
mm
3
4
5
6
8
10
12
Overall length
mm 56
63
68
68
88
95
110
Cutting edge length
mm 8
11
13
13
19
22
26
Drive Ø
mm 6
6
6
6
10
10
12
8739
Each 31,70 31,70 31,70 31,70 40,40 46,50 54,10
Ø
mm
14
16
18
20
Overall length
mm 110
123
123
141
Cutting edge length
mm 26
32
32
38
Drive Ø
mm 12
16
16
20
8739
Each 61,10 69,10 92,10 108,00
vuoto
ENDMILLS
8742
HSS-E-8%
Three-flute end mills. Short series. DIN 844 A-UNI 8244 A-ISO 1641/1.
Central tang drive. Weldon shank. Cutting tolerance e8
HSS-E COBALT 8%
Ø
mm
3
4
5
6
7
8
9
Overall length
mm 52
55
57
53
66
69
69
Cutting edge length
mm 8
11
13
10
16
19
19
Drive Ø
mm 6
6
6
6
10
10
10
8742
Each 13,30 13,30 14,90 14,90 19,60 19,60 24,90
Ø
mm
10
11
12
13
14
15
16
Overall length
mm 72
79
83
83
83
83
92
Cutting edge length
mm 22
22
26
26
26
26
32
Drive Ø
mm 10
12
12
12
12
12
16
8742
Each 24,90 27,20 27,20 34,70 34,70 39,90 39,90
Ø
mm
18
20
22
Overall length
mm 92
104
104
Cutting edge length
mm 32
38
38
Drive Ø
mm 16
20
20
8742
Each 45,20 55,70 82,80
vuoto
ENDMILLS
8743
HSS-E-8%
TiAIN
Product description as Art. 8742
HSS-E COBALT 8%, TiAIN coating.
Ø
mm
4
5
6
8
10
12
14
Overall length
mm 55
57
57
69
72
83
83
Cutting edge length
mm 11
13
13
19
22
26
26
Drive Ø
mm 6
6
6
10
10
12
12
8743
Each 20,50 21,90 21,90 30,60 35,10 40,90 51,10
Ø
mm
16
18
20
Overall length
mm 92
92
104
Cutting edge length
mm 32
32
38
Drive Ø
mm 16
16
20
8743
Each 61,30 67,10 83,10
vuoto
ENDMILLS
