END MILLS
1162
13
Prices in EURO - VAT not included
8746
HSS-E-8%
Three-flute end mills. Long series. DIN 8245 A--ISO 1641/1.
Central tang drive. Weldon shank. Cutting tolerance e8
HSS-E COBALT 8%
Ø
mm
3
4
5
6
8
10
12
Overall length
mm 56
63
68
68
88
95
110
Cutting edge length
mm 12
19
24
24
38
45
53
Drive Ø
mm 6
6
6
6
10
10
12
8746
Each 22,20 22,20 22,20 22,20 28,10 30,40 37,10
Ø
mm
14
16
18
20
Overall length
mm 110
123
123
141
Cutting edge length
mm 53
63
63
75
Drive Ø
mm 12
16
16
20
8746
Each 43,10 54,50 65,70 76,90
vuoto
ENDMILLS
8747
HSS-E-8%
Three-flute end mills, 45° bent. Short series. ISO 1641/2.
Central tang drive. Weldon shank. Cutting tolerance J14.
HSS-E COBALT 8%.
Ø
mm
6
8
10
12
14
16
18
Overall length
mm 57
69
72
83
83
92
92
Cutting edge length
mm 13
19
22
26
26
32
32
Drive Ø
mm 6
10
10
12
12
16
16
8747
Each 15,90 20,40 23,40 28,70 35,40 44,40 53,50
Ø
mm
20
Overall length
mm 104
Cutting edge length
mm 38
Drive Ø
mm 20
8747
Each 58,80
vuoto
ENDMILLS
8748
HSS-E-5%
Two-flute end mills. Short series. DIN 326 D-UNI 8260 A-ISO 1641/2.
Central tang drive. Morse taper shank and threaded hole. Cutting tolerance e8.
HSS-E COBALT 5%
Ø
mm
10
15
16
18
20
22
24
Overall length
mm 85
104
107
107
110
132
136
Cutting edge length
mm 13
16
19
19
22
22
26
Drive
C.M.
1
2
2
2
2
3
3
8748
Each 40,80 52,50 47,90 54,30 66,10 75,90 81,90
Ø
mm
25
30
32
Overall length
mm 136
136
171
Cutting edge length
mm 26
26
32
Drive
C.M.
3
3
4
8748
Each 85,30 106,00 135,00
Size mm 10 running out of stock.
vuoto
ENDMILLS
8748E
HSS-E-8%
Product description as Art. 8748
HSS-E COBALT 8%
Ø
mm
10
12
15
16
18
20
22
Overall length
mm 85
88
104
107
107
110
132
Cutting edge length
mm 13
16
16
19
19
22
22
Drive
C.M.
1
1
2
2
2
2
3
8748E
Each 47,10 47,40 60,20 60,20 65,90 81,20 93,10
Ø
mm
24
25
30
32
Overall length
mm 136
136
136
171
Cutting edge length
mm 26
26
26
32
Drive
C.M.
3
3
3
4
8748E
Each 101,00 103,00 127,00 161,00
Sizes mm 10 and 12 running out of stock.
vuoto
ENDMILLS
8749
HSS-E-5%
Three-flute end mills. Normal series. DIN 845 B- UNI 8250 – ISO 1641/2.
Central tang drive. Morse taper shank and threaded hole. Cutting tolerance e8.
HSS-E COBALT 5%
Ø
mm
14
15
16
18
20
22
24
Overall length
mm 117
117
117
117
123
140
147
Cutting edge length
mm 32
32
32
32
38
38
45
Drive
C.M.
2
2
2
2
2
3
3
8749
Each 52,20 57,90 57,90 58,60 75,30 80,30 91,10
Ø
mm
25
30
32
Overall length
mm 147
147
178
Cutting edge length
mm 45
45
53
Drive
C.M.
3
3
4
8749
Each 93,50 117,00 156,00
Size mm 14 running out of stock.
vuoto
ENDMILLS
