DRILL BUSHES
1160
13
Prices in EURO - VAT not included
8698
LONG type with collar. DIN 172.
In special steel, hardened and ground. Hardness Hrc 60-62.
Tolerance: int. Ø F7 – ext. Ø n. 6.
Int Ø d1
mm
2
2,5
3
3,2
3,5
4
4,3
4,5
5
5,5
6
6,5
7
7,5
d2-d3 ext. Ø
mm 5-8
5-8
6-9
6-9 7-10 7-10 8-11 8-11 8-11 10-13 10-13 12-15 12-15 12-15
l1-l2 Height
mm 9-7
9-7 12-9,5 12-9,5 12-9,5 12-9,5 12-9,5 12-9,5 12-9,5 16-13 16-13 16-13 16-13 16-13
8698
Each 2,60 2,60 2,60 2,60 2,52 2,52 2,32 2,32 2,32 2,50 2,50 2,76 2,76 2,76
Int Ø d1
mm
8
8,5
9
9,5
10
10,5
11
11,5
12
12,5
13
13,5
14
14,5
d2-d3 ext. Ø
mm 12-15 15-18 15-18 15-18 15-18 18-22 18-22 18-22 18-22 22-26 22-26 22-26 22-26 22-26
l1-l2 Height
mm 16-13 20-17 20-17 20-17 20-17 20-16 20-16 20-16 20-16 28-24 28-24 28-24 28-24 28-24
8698
Each 2,76 3,12 3,12 3,12 3,12 3,36 3,36 3,36 3,36 5,00 5,00 5,00 5,00 5,00
Int Ø d1
mm
15
15,5
16
16,5
17
17,5
18
18,5
19
19,5
20
d2-d3 ext. Ø
mm 22-26 26-30 26-30 26-30 26-30 26-30 26-30 30-34 30-34 30-34 30-34
l1-l2 Height
mm 28-24 28-24 28-24 28-24 28-24 28-24 28-24 36-31 36-31 36-31 36-31
8698
Each 5,00 5,88 5,88 5,88 5,88 5,88 5,88 7,76 7,76 7,76 7,76
DRILLBUSHES
END MILLS
8732
HSS-E-8%
Prod. SCU
Two-flute end mills. Short series. DIN 327 B – UNI 8254 A-ISO 1641/1.
Central tang drive. Weldon shank. Cutting tolerance e8.
HSS-E COBALT 8%
Ø
mm
2
2,5
3
3,5
4
4,5
5
5,5
Overall length
mm 48
48
49
49
51
51
52
52
Cutting edge length
mm 4
4
5
5
7
7
8
8
Drive Ø
mm 6
6
6
6
6
6
6
6
8732
Each 18,20 18,20 14,30 14,30 14,30 16,10 16,10 16,10
Ø
mm
6
6,5
7
7,5
8
8,5
9
9,5
Overall length
mm 52
60
60
60
61
61
61
61
Cutting edge length
mm 8
10
10
10
11
11
11
11
Drive Ø
mm 6
10
10
10
10
10
10
10
8732
Each 16,10 20,40 20,40 20,40 20,40 23,50 23,50 23,50
Ø
mm
10
11
12
13
14
15
16
17
Overall length
mm 63
70
73
73
73
73
79
79
Cutting edge length
mm 13
13
16
16
16
16
19
19
Drive Ø
mm 10
12
12
12
12
12
16
16
8732
Each 23,50 27,90 27,90 40,30 40,30 41,40 41,40 48,90
Ø
mm
18
19
20
22
25
30
Overall length
mm 79
79
88
88
102 102
Cutting edge length
mm 19
19
22
22
26
26
Drive Ø
mm 16
16
20
20
25
25
8732
Each 45,20 60,90 56,50 70,90 82,80 116,00
vuoto
ENDMILLS
8734
HSS-E-8%
TiAIN
Product description as Art. 8732
HSS-E COBALT 8%, TiAIN coating.
Ø
mm
4
5
6
8
10
12
14
Overall length
mm 51
52
52
61
63
73
73
Cutting edge length
mm 7
8
8
11
13
16
16
Drive Ø
mm 6
6
6
10
10
12
12
8734
Each 29,30 29,30 29,30 39,40 43,90 59,10 65,80
Ø
mm
16
18
20
Overall length
mm 79
79
88
Cutting edge length
mm 19
19
22
Drive Ø
mm 16
16
20
8734
Each 86,10 92,10 110,00
vuoto
ENDMILLS
8737
HSS-E-8%
Two-flute end mills. Long series. ISO 1641/1. Central tang drive.
Weldon shank. Cutting tolerance e8.
HSS-E COBALT 8%
Ø
mm
3
4
5
6
8
10
12
Overall length
mm 56
63
68
68
88
95
110
Cutting edge length
mm 8
11
13
13
19
22
26
Drive Ø
mm 6
6
6
6
10
10
12
8737
Each 20,30 20,30 20,30 20,30 21,90 28,50 33,80
Ø
mm
14
16
18
20
Overall length
mm 110
123
123
141
Cutting edge length
mm 26
32
32
38
Drive Ø
mm 12
16
16
20
8737
Each 42,20 51,10 62,50 71,60
