SHELL-END MILLS
1167
13
Prices in EURO - VAT not included
8766E
HSS-E-8%
TiAIN
Spiral flute end mills for ROUGHING. Short series.
DIN 844 A – UNI 8244 A – ISO 1641/1. Weldon shank. Cutting tolerance J14.
Ø 6 to 22mm=4 flute/Ø 25-30mm=5 flute
HSS-E COBALT 8%, TiAIN coating.
Ø
mm
10
12
14
16
18
20
Overall length
mm 72
83
83
92
92
104
Cutting edge length
mm 22
26
26
32
32
38
Drive Ø
mm 10
12
12
16
16
20
8766E
Each 61,60 76,60 84,40 112,00 119,00 141,00
vuoto
SHELL-ENDMILLS
8768
HSS-E-8%
Spiral flute end mills for ROUGHING. Long series.
Weldon shank. Cutting tolerance J14.
Ø 8 to 22mm=4 flute/Ø 25mm=5 flute
HSS-E COBALT 8%
Ø
mm
8
10
12
14
15
16
18
Overall length
mm 88
95
110
110
110
123
123
Cutting edge length
mm 38
45
53
53
53
63
63
Drive Ø
mm 10
10
12
12
12
16
16
8768
Each 59,80 59,80 66,60 87,30 107,00 107,00 124,00
Ø
mm
20
22
25
Overall length
mm 141
151
166
Cutting edge length
mm 75
75
90
Drive Ø
mm 20
20
25
8768
Each 135,00 144,00 171,00
vuoto
SHELL-ENDMILLS
8770
HSS-E-5%
Spiral flute end mills for ROUGHING. Short series. DIN 845 B – UNI 8250- ISO 1641/2. Morse
taper shank and threaded hole. Cutting tolerance J14.
Ø 16 to 22mm=4 flute/Ø 24 to 32mm=5 flute
HSS-E COBALT 5%
Ø
mm
16 18 20 22 24 26 28 30 32
Overall length
mm 117 117 123 140 147 147 147 147 178
Cutting edge length
mm 32 32 38 38 45 45 45 45 53
Drive
C.M.
2
2
2
3
3
3
3
3
4
8770
Each 69,30 76,60 82,80 91,10 106,00 124,00 132,00 142,00 176,00
vuoto
SHELL-ENDMILLS
8771
HSS-E-8%
Product description as Art. 8770
HSS-E COBALT 8%
Ø
mm
16 18 20 22 24 26 28 30 32
Overall length
mm 117 117 123 140 147 147 147 147 178
Cutting edge length
mm 32 32 38 38 45 45 45 45 53
Drive
C.M.
2
2
2
3
3
3
3
3
4
8771
Each 79,80 87,60 96,20 112,00 125,00 135,00 149,00 166,00 218,00
vuoto
SHELL-ENDMILLS
8775
HSS-E-8%
Four-flute end mills for ROUGHING, fine pitch. Short series.
DIN 844 A – UNI 8244A – ISO 1641/1. HSS-E COBALT 8%. Weldon shank. Cutting tolerance
J14. For finer surface finish.
Ø
mm
10
12
14
15
16
18
20
22
Overall length
mm 72
83
83
83
92
92
104 104
Cutting edge length
mm 22
26
26
26
32
32
38
38
Drive Ø
mm 10
12
12
12
16
16
20
20
8775
Each 44,10 46,30 54,50 63,40 63,40 71,60 80,50 110,00
vuoto
SHELL-ENDMILLS
8779
HSS-E-5%
Reinforced helical teeth. N type. DIN 1880 – UNI 3903 – ISO 2586.
HSS-E COBALT 5%.
Longitudinal and transversal driving slot. Cutting tolerance J16.
Ø
mm
40
50
63
80
Thickness
mm 32
36
40
45
Bore Ø
mm 16
22
27
27
Teeth
No
8
8
8
10
8779
Each 104,00 133,00 183,00 314,00
vuoto
SHELL-ENDMILLS
8781
HSS-E-5%
Shell mills, reinforced helical teeth. N type. DIN 841.
HSS-E COBALT 5%.
Longitudinal driving slot. Cutting tolerance J16.
Ø
mm
30
35
40
50
60
75
Thickness
mm 30
35
40
50
60
75
Bore Ø
mm 13
16
16
22
27
27
Teeth
No
6
6
8
8
8
10
8781
Each 105,00 114,00 136,00 205,00 276,00 500,00
vuoto
