SHELL-END MILLS
1166
13
Prices in EURO - VAT not included
8761E
HSS-E-8%
TiAIN
Product description as Art. 8761
HSS-E COBALT 8%, TiAIN coating.
Ø
mm
10
12
14
16
18
20
Overall length
mm 72
83
83
92
92
104
Cutting edge length
mm 22
26
26
32
32
38
Drive Ø
mm 10
12
12
16
16
20
8761E
Each 61,60 76,60 84,40 112,00 119,00 141,00
vuoto
SHELL-ENDMILLS
8762E
HSS-E-8%
Four-flute end mills for SEMI-FINISHING. Long series.
Weldon shank. Cutting tolerance J14.
HSS-E COBALT 8%
Ø
mm
8
10
12
14
15
16
18
Overall length
mm 88
95
110
110
110
123
123
Cutting edge length
mm 38
45
53
53
53
63
63
Drive Ø
mm 10
10
12
12
16
16
16
8762E
Each 59,80 59,80 66,60 87,30 107,00 107,00 124,00
Ø
mm
20
22
Overall length
mm 141
151
Cutting edge length
mm 75
75
Drive Ø
mm 20
20
8762E
Each 135,00 144,00
vuoto
SHELL-ENDMILLS
8763
HSS-E-5%
Spiral flute end mills for SEMI-FINISHING. Short series.
DIN 845 B – UNI 8250 – ISO 1641/2. Morse taper shank and threaded hole.
Cutting tolerance J14.
Ø 16 to 22mm=4 flute/Ø 24 to 32mm=5 flute
HSS-E COBALT 5%
Ø
mm
16
18
20
22
24
26
28
Overall length
mm 117
117
123
140
147
147
147
Cutting edge length
mm 32
32
38
38
45
45
45
Drive
C.M.
2
2
2
3
3
3
3
8763
Each 69,30 76,60 82,80 91,10 106,00 125,00 132,00
Ø
mm
30
32
Overall length
mm 147
178
Cutting edge length
mm 45
53
Drive
C.M.
3
4
8763
Each 142,00 176,00
vuoto
SHELL-ENDMILLS
8764
HSS-E-8%
Product description as Art. 8763
HSS-E COBALT 8%
Ø
mm
16
18
20
22
24
26
28
Overall length
mm 117
117
123
140
147
147
147
Cutting edge length
mm 32
32
38
38
45
45
45
Drive
C.M.
2
2
2
3
3
3
3
8764
Each 79,80 87,60 96,20 112,00 125,00 135,00 149,00
Ø
mm
30
32
Overall length
mm 147
178
Cutting edge length
mm 45
53
Drive
C.M.
3
4
8764
Each 166,00 112,00
vuoto
SHELL-ENDMILLS
8766
HSS-E-8%
Spiral flute end mills for ROUGHING. Short series.
DIN 844 A – UNI 8244 A – ISO 1641/1. Weldon shank. Cutting tolerance J14.
Ø mm 6 = 3 flute / Ø mm 8 a 22 = 4 flute / Ø mm 25-30 = 5 flute.
HSS-E COBALT 8%
Ø
mm
6
8
10
12
14
15
16
Overall length
mm 57
69
72
83
83
83
92
Cutting edge length
mm 13
19
22
26
26
26
32
Drive Ø
mm 6
10
10
12
12
12
16
8766
Each 40,60 40,60 40,60 44,50 50,40 58,60 60,40
Ø
mm
18
20
22
25
30
Overall length
mm 92
104
104
121
121
Cutting edge length
mm 32
38
38
45
45
Drive Ø
mm 16
20
20
25
25
8766
Each 66,10 74,60 102,00 116,00 150,00
