CONVEX RADIUS CUTTERS
1170
13
Prices in EURO - VAT not included
CONVEX RADIUS CUTTERS
8791E
HSS-E-5%
Prod. SCU
DIN 856 A – UNI 4498 -ISO 3860.
HSS-E COBALT 5%. Cutting tolerance J16.
Radius R
mm
1
1,5
2
2,5
3
4
5
Ø
mm 50
50
50
63
63
63
63
Thickness
mm 2
3
4
5
6
8
10
Bore Ø
mm 16
16
16
22
22
22
22
Teeth
No
16
16
16
12
12
12
12
8791E
Each 97,70 97,70 97,70 103,00 103,00 126,00 135,00
Radius R
mm
6
8
10
12
14
16
20
Ø
mm 80
80
100
100
100
110
125
Thickness
mm 12
16
20
24
28
32
40
Bore Ø
mm 27
27
32
32
32
32
32
Teeth
No
12
12
12
12
12
12
12
8791E
Each 165,00 223,00 334,00 479,00 664,00 825,00 1.070,00
vuoto
CONVEXRADIUSCUTTERS
SIDE AND FACE MILLING CUTTERS
8792
HSS-E-5%
Prod. SCU
Helical alternate teeth. N type. DIN 885 A – UNI 3905 – ISO 2587.
HSS-E 5% CO. Driving slot.
Cutting tolerance J16.
Ø and thickness
mm
50x3 50x4 50x5 50x6 63x3 63x4 63x5
Bore Ø
mm 16
16
16
16
22
22
22
Teeth
No
14
14
14
14
16
16
16
8792
Each 85,30 75,70 75,70 75,70 109,00 89,40 89,40
Ø and thickness
mm
63x6 63x8 63x10 80x3 80x4 80x5 80x6
Bore Ø
mm 22
22
22
22
22
22
22
Teeth
No
16
16
16
18
18
18
18
8792
Each 89,40 90,10 105,00 136,00 110,00 110,00 110,00
Ø and thickness
mm
80x8 80x10 100x3 100x4 100x5 100x6 100x8
Bore Ø
mm 22
22
27
27
27
27
27
Teeth
No
18
18
20
20
20
20
20
8792
Each 122,00 134,00 183,00 151,00 151,00 151,00 168,00
Ø and thickness
mm
100x10 100x12 125x4 125x5 125x6 125x8 125x10
Bore Ø
mm 27
27
32
32
32
32
32
Teeth
No
20
20
26
22
22
22
22
8792
Each 178,00 197,00 226,00 214,00 214,00 220,00 245,00
Ø and thickness
mm
125x12 160x6 160x8 160x10 160x12
Bore Ø
mm 32
32
32
32
32
Teeth
No
22
26
26
26
26
8792
Each 259,00 309,00 329,00 357,00 384,00
vuoto
SIDEANDFACEMILLINGCUTTERS
T-SLOT CUTTERS, STRAIGHT SHANK
8793
HSS-E-5%
Prod. SCU
Helical alternate teeth. N type. DIN 851 A – UNI 7339 A – ISO 3337. HSS-E 5% CO.
Weldon shank. Cutting tolerance h12.
Ø
mm
12.5
16
19
22
25
28
32
Thickness
mm 6
8
9
10
11
12
14
Overall length
mm 57
62
71
75
82
83
90
Drive Ø
mm 10
10
12
12
16
16
16
Teeth
No
6
6
6
6
6
6
8
8793
Each 62,20 76,50 80,20 90,10 106,00 122,00 133,00
vuoto
T-SLOTCUTTERS,STRAIGHTSHANK
WOODRUFF KEYSET MILLING CUTTERS STRAIGHT SHANK
8794
HSS-E-5%
Prod. SCU
helical alternate teeth. D type. DIN 850 B – UNI 8263.
HSS-E 5% CO. Weldon shank.
Cutting tolerance h11.
Ø and thickness
mm
10,5x2 10,5x2,5 10,5x3 13,5x2 13,5x3 13,5x4 16,5x4
Overall length
mm 50
50
50
56
56
56
56
Drive Ø
mm 6
6
6
10
10
10
10
8794
Each 36,10 36,10 36,10 42,10 42,10 42,10 48,40
Ø and thickness
mm
16,5x5 16,5x6 19,5x4 19,5x5 19,5x6 22,5x5 22,5x6
Overall length
mm 56
56
63
63
63
63
63
Drive Ø
mm 10
10
10
10
10
10
10
8794
Each 48,40 48,40 55,70 55,70 55,70 61,60 61,60
Ø and thickness
mm
22,5x8 25,5x6 25,5x7 25,5x8
Overall length
mm 63
63
63
63
Drive Ø
mm 10
10
10
10
8794
Each 61,60 71,40 71,40 71,40
vuoto
WOODRUFFKEYSETMILLINGCUTTERSSTRAIGHTSHANK
