1178 / 1378
1178
COUNTERSINKS
1178
13
Prices in EURO - VAT not included
8800G
60
HSS
Orig. Dürr - Art. 216 -31
Three flutes, HSS ground.
For countersinking holes in iron and steel. Vibration-free.
60° HEAD TAPER – DIN 334. Cylindrical shank.
HSS
Type
6,3
8
10
12,5 12,5L 16
16L
Countersink max Ø
mm 6,3
8
10
12,5
12,5
16
16
Countersink min Ø
mm 1,6
2
2,5
3,2
3,2
4
4
Drive Ø
mm 5
6
6
8
8
10
10
Overall length
mm 45
50
50
56
159
63
162
8800G
Each 13,60 13,90 17,40 18,60 141,00 22,60 177,00
Type
20
20L
25
25L
30
30L 31,5L
Countersink max Ø
mm 20
20
25
25
30
30
31,5
Countersink min Ø
mm 5
5
6,3
6.3
10
4
4
Drive Ø
mm 10
10
10
10
12
12
12
Overall length
mm 67
165
71
169
75
200
200
8800G
Each 31,80 245,00 43,50 289,00 82,50 422,00 399,00
vuoto
COUNTERSINKS
8802G
60
HSS
TIN
Orig. Dürr - Art. 216-31
Product description as Art. 8800G
HSS, TIN coated.
Countersink max Ø
mm
6,3
8
10
12,5
16
20
25
Countersink min Ø
mm 1,6
2
2,5
3,2
4
5
6,3
Drive Ø
mm 5
6
6
8
10
10
10
Overall length
mm 45
50
50
56
63
67
71
8802G
Each 24,10 26,70 32,20 36,70 41,50 58,10 78,10
vuoto
COUNTERSINKS
8804G
60
HSS
Orig. Dürr - Art. 216-61
Three flutes, HSS ground.
For countersinking holes in iron and steel. Vibration-free.
60° HEAD TAPER – DIN 334. Morse taper shank.
Countersink max Ø
mm
16
20
25 31,5 40
50
63
80
Countersink min Ø
mm 4
5
6,3
10 12,5 16
20
25
Drive
C.M.
1
2
2
2
3
3
4
4
Overall length
mm 90
106 112 118 150 160 190 200
8804G
Each 42,10 59,20 61,60 77,20 120,00 158,00 307,00 531,00
Size mm 16 running out of stock.
vuoto
COUNTERSINKS
8806G
75
HSS
Orig. Dürr - Art. 216-31
Three flutes, HSS ground.
For countersinking holes in iron and steel. Vibration-free.
75° HEAD TAPER. Cylindrical shank.
Countersink max Ø
mm
8
10
12,5
15
20
25
Countersink min Ø
mm 2
2,5
2,8
3,2
3,5
3,8
Drive Ø
mm 6
6
8
8
10
10
Overall length
mm 50
54
54
56
63
71
8806G
Each 22,90 25,20 28,50 38,30 56,70 63,10
vuoto
COUNTERSINKS
8808G
75
HSS
Orig. Dürr - Art. 216-61
Three flutes, HSS ground.
For countersinking holes in iron and steel. Vibration-free.
75° HEAD TAPER. Morse taper shank.
Countersink max Ø
mm
15
20
25
30
Countersink min Ø
mm 3,2
3,5
3,8
4,2
Drive
C.M.
1
1
2
2
Overall length
mm 87
90
110
114
8808G
Each 55,20 63,10 80,80 128,00
Size mm 25 running out of stock.
vuoto
COUNTERSINKS
60°/90° COUNTERSINKS
8809G
60 - 90
HSS
Orig. Dürr - Art. 217-31
Three flutes, HSS ground. For countersinking holes in iron and steel. Vibration-free. 60°/90°
HEAD TAPER. Cylindrical shank.
Countersink max Ø
mm
6
8
10
12
Countersink min Ø
mm 2
2
2
2
Drive Ø
mm 6
8
10
12
Overall length
mm 60
70
75
75
8809G
Each 20,80 21,80 27,30 29,10
Same mills in hardmetal available on request.
vuoto
60°/90°COUNTERSINKS
