TUNGSTEN CARBIDE SOLID END MILLS WITH FIRE COATING
1177
13
Prices in EURO - VAT not included
8799EM
new
HARTMETALL
FIRE
Orig. Hartner - Art. 84919
Product description as Art. 8799EA
Long series DIN 6527 L. Type N with 4 helical cutting edges to 30°. Radial head. Cutting right.
Cylindrical shank DIN 6535 HB. Universal use for quarries, grooves, slots, etc. in materials with
strength up to 1400 N/mm².
Ø
mm
3
4
5
6
8
10
12
20
Overall length
mm 57
57
57
57
63
72
83
104
Cutting edge length
mm 8
11
13
13
19
22
26
38
Drive Ø
mm 6
6
6
6
8
10
12
20
8799EM
Each 37,90 37,90 38,70 37,90 47,40 61,60 85,30 214,00
vuoto
TUNGSTENCARBIDESOLIDENDMILLSWITHFIRECOATING
8799EP
new
HARTMETALL
FIRE
Orig. Hartner - Art. 84908
Type for high performance of fine-material hardness up to 50 HRC. With special FIRE coating. For
the accentuated spiral angle, for the special processing of the cutting edges and corners of the
cutting edges allows a perfect stability of cut, a feed more fluid and fast, a machining precision
and surface quality at the highest levels.
Long series with standard factory. Type NH with helical multi-cutting edges to 45 °. Cutting right.
Cylindrical shank DIN 6535 HA.
Ø
mm
3
4
5
6
8
10 12 16 20
Overall length
mm 57 57 57 57 63 72 83 92 104
Cutting edge length
mm 8
11 13 13 19 22 26 32 38
Drive Ø
mm 6
6
6
6
8
10 12 16 20
8799EP
Each 42,70 40,30 37,90 37,90 46,60 71,10 97,90 176,00 245,00
vuoto
TUNGSTENCARBIDESOLIDENDMILLSWITHFIRECOATING
8799ER
new
HARTMETALL
FIRE
Orig. Hartner - Art. 84910
Product description as Art. 8799EP
Extra-long series with standard factory. Type NH with helical multi-cutting edges to 45 °. Cutting
right.
Cylindrical shank DIN 6535 HA.
Ø
mm
6
8
10
12
16
20
Overall length
mm 75
100
100
150
150
150
Cutting edge length
mm 30
40
40
45
65
65
Drive Ø
mm 6
8
10
12
16
20
8799ER
Each 55,30 64,10 114,00 158,00 285,00 427,00
vuoto
TUNGSTENCARBIDESOLIDENDMILLSWITHFIRECOATING
8799ES
new
HARTMETALL
FIRE
Orig. Hartner - Art. 84907
For high performance roughing with material with hardness up to 54 HRC. With special FIRE
coating. With fine pitch chip breaker, with high surface hardness that allows use also with
compressed air.
Long series DIN 6527 L. Type HR with 4 helical cutting edges to 20°. Cutting right. Front tooth in
the middle.
Cylindrical shank DIN 6535 HB.
Ø
mm
6
8
10
12
16
20
Overall length
mm 57
63
72
83
92
104
Cutting edge length
mm 13
19
22
26
32
38
Drive Ø
mm 6
8
10
12
16
20
8799ES
Each 101,00 109,00 120,00 141,00 225,00 338,00
vuoto
TUNGSTENCARBIDESOLIDENDMILLSWITHFIRECOATING
COUNTERSINKS
8799G
30
HSS
Orig. Dürr - Art. 216-31
Three flutes, HSS ground. For countersinking holes in iron and steel. Vibration-free. 30° HEAD
TAPER. Cylindrical shank.
Countersink max Ø
mm
6,3
12,4
16,5
20,5
25
31
Countersink min Ø
mm 2
3
4
5
6
9
Drive Ø
mm 5
8
10
10
10
12
Overall length
mm 50
65
76
83
90
98
8799G
Each 40,20 59,20 72,20 105,00 135,00 194,00
vuoto
COUNTERSINKS
8799GE
new
45
HSS
With 3 cutting edges, ground High-Speed Steel. To countersink holes in iron and steel. No
vibrations. 45 ° CONICAL HEAD Cylindrical connection.
Countersink max Ø
mm
12,4
16,5
20,5
25
Countersink min Ø
mm 3
4
5
6
Drive Ø
mm 8
10
10
10
Overall length
mm 64
68
74
78
8799GE
Each 88,20 108,00 155,00 199,00
vuoto
