MACHINE TAPS
1234
13
Prices in EURO - VAT not included
9320G
BSP
HSS-E
Orig. Völkel - Art. 785
REDUCED SHANK.
RIGHT-HAND USE.
CYLINDRICAL GAS THREAD G (BSP) – According to DIN ISO 228
HSS-E. Correct chamfer. Universal type. Through holes.
Ø
inches
1/8
1/4
3/8
1/2
5/8
3/4
7/8
Threads per inch
No
28
19
19
14
14
14
14
Overall length
mm 90
100
100
125
125
140
150
Thread length
mm 20
22
22
25
25
28
28
Shank Ø
mm 7
11
12
16
18
20
22
Shank square
mm 5,5
9
9
12
14,5
16
18
9320G
Each 18,50 23,30 27,60 40,70 46,50 60,60 71,20
Ø
inches
1
1.1/8 1.1/4 1.3/8 1.1/2
Threads per inch
No
11
11
11
11
11
Overall length
mm 160
170
170
180
190
Thread length
mm 30
30
30
32
32
Shank Ø
mm 25
28
32
36
36
Shank square
mm 20
22
24
29
29
9320G
Each 93,70 138,00 167,00 217,00 234,00
MACHINETAPS
9322G
BSP
HSS-E
Orig. Völkel - Art. 784
Product description as Art. 9320G
HSS-E. Short chamfer. Universal type. Blind holes.
Ø
inches
1/8
1/4
3/8
1/2
5/8
3/4
1
Threads per inch
No
28
19
19
14
14
14
11
Overall length
mm 90
100
100
125
125
140
160
Thread length
mm 20
22
22
25
25
28
30
Shank Ø
mm 7
11
12
16
18
20
25
Shank square
mm 5,5
9
9
12
14,5
16
20
9322G
Each 17,60 22,10 27,60 38,90 44,30 57,40 83,50
Ø
inches
1.1/8 1.1/4 1.3/8 1.1/2
Threads per inch
No
11
11
11
11
Overall length
mm 170
170
180
190
Thread length
mm 30
30
32
32
Shank Ø
mm 28
32
36
36
Shank square
mm 22
24
29
29
9322G
Each 116,00 157,00 185,00 218,00
MACHINETAPS
9324G
BSP
HSS-E
Orig. Völkel - Art. 787
Product description as Art. 9320G
HSS-E. Short chamfer. Type with approx. 35° spiral flute for metals up to R 900 N/mm². Deep
blind holes.
Ø
inches
1/8 1/4 3/8 1/2 3/4 7/8
1 1.1/4 1.1/2
Threads per inch
No 28 19 19 14 14 14 11 11 11
Overall length
mm 90 100 100 125 140 150 160 170 190
Thread length
mm 20 22 22 25 28 28 30 30 32
Shank Ø
mm 7
11 12 16 20 22 25 32 36
Shank square
mm 5,5
9
9
12 16 18 20 24 29
9324G
Each 20,80 26,70 33,30 46,50 69,70 82,00 102,00 189,00 265,00
MACHINETAPS
ROUND DIES
9350G
M
HSS
Orig. Völkel - Art. 274
Closed type, fully ground according to DIN-EN 22568.
ISO METRIC THREAD, according to DIN 13 – M Coarse Metric -Tolerance 6g
RIGHT-HAND USE.
HSS. Normal chamfer. For steel with R up to 800 N/mm^2.
Ø
mm
1
1,1
1,2
1,4
1,6
1,8
2
2,2
Pitch
mm 0,25 0,25 0,25 0,3 0,35 0,35 0,4 0,45
Dimensions
mm 16x5 16x5 16x5 16x5 16x5 16x5 16x5 16x5
9350G
Each 16,10 16,10 16,10 16,10 16,10 16,10 14,10 14,10
Ø
mm
2,3
2,5
2,6
3
3,5
4
4,5
5
Pitch
mm 0,40 0,45 0,45 0,5
0,6
0,7 0,75 0,8
Dimensions
mm 16x5 16x5 16x5 20x5 20x5 20x5 20x7 20x7
9350G
Each 14,10 14,10 14,10 6,98 10,80 6,98 10,80 7,40
Ø
mm
6
7
8
9
10
11
12
14
Pitch
mm 1
1
1,25 1,25 1,5
1,5 1,75
2
Dimensions
mm 20x7 25x9 25x9 25x9 30x11 30x11 38x14 38x14
9350G
Each 7,40 11,70 7,84 13,30 9,44 14,80 14,40 16,10
Ø
mm
16
18
20
22
24
27
30
33
Pitch
mm 2
2,5
2,5
2,5
3
3
3,5
3,5
Dimensions
mm 45x18 45x18 45x18 55x22 55x22 65x25 65x25 65x25
9350G
Each 22,40 22,40 22,40 42,40 42,40 61,10 61,10 61,10
Ø
mm
36
42
45
48
52
Pitch
mm 4
4,5
4,5
5
5
Dimensions
mm 65x25 75x30 90x36 90x36 90x36
9350G
Each 61,10 95,80 169,00 169,00 169,00
