1235 / 1378
1235
ROUND DIES
1235
13
Prices in EURO - VAT not included
9353G
LEFT USAGE
M
HSS
Orig. Völkel - Art. 272
Product description as Art. 9350G
ISO METRIC THREAD according to DIN 13-M Coarse Metric- Tolerance 6g
LEFT-HAND USE.
HSS, with chamfer, for steel with R up to 600 N/mm^2.
Ø
mm
3
4
5
6
8
10
12
Pitch
mm 0,5
0,7
0,8
1
1,25
1,5
1,75
Dimensions
mm 20x5 20x5 20x7 20x7 25x9 30x11 38x14
9353G
Each 11,20 11,20 12,10 12,10 14,10 18,50 26,10
Ø
mm
14
16
18
20
22
24
Pitch
mm 2
2
2,5
2,5
2,5
3
Dimensions
mm 38x14 45x18 45x18 45x18 55x22 55x22
9353G
Each 29,80 41,60 41,60 41,60 61,10 61,10
vuoto
ROUNDDIES
9354G
INOX
M
HSS-E
Orig. Völkel - Art. 574
Product description as Art. 9350G
ISO METRIC THREAD, according to DIN 13 – M Coarse Metric -Tolerance 6g
RIGHT-HAND USE.
HSS. Normal chamfer. For stainless steel and steel with R up to 1200 N/mm^2.
Ø
mm
3
4
5
6
8
10
12
Pitch
mm 0,5
0,7
0,8
1
1,25
1,5
1,75
Dimensions
mm 20x5 20x5 20x7 20x7 25x9 30x11 38x14
9354G
Each 10,80 10,80 11,10 11,10 15,70 22,40 35,20
Ø
mm
14
16
18
20
22
24
Pitch
mm 2
2
2,5
2,5
2,5
3
Dimensions
mm 38x14 45x18 45x18 45x18 55x22 55x22
9354G
Each 35,20 53,10 53,10 53,10 94,40 94,40
vuoto
ROUNDDIES
9357G
MF
HSS
Orig. Völkel - Art. 264-266
Product description as Art. 9350G
ISO FINE METRIC THREAD, according to DIN 13 - MF Fine Metric – Tolerance 6g
RIGHT-HAND USE.
HSS. Normal chamfer. For steel with R up to 800 N/mm^2.
Ø
mm
3
3,5
4
4
5
6
6
Pitch
mm
0,35
0,35
0,35
0,5
0,5
0,5
0,75
Dimensions
mm 20x5 20x5 20x5 20x5 20x5 20x5 20x7
9357G
Each 15,10 15,10 15,10 15,10 15,10 15,10 12,50
Ø
mm
7
8
8
8
9
10
10
Pitch
mm
0,75
0,5
0,75
1
1
0,5
0,75
Dimensions
mm 25x9 25x9 25x9 25x9 25x9 30x11 30x11
9357G
Each 16,10 16,10 13,40 13,40 20,20 20,20 20,20
Ø
mm
10
10
11
12
12
12
14
Pitch
mm
1
1,25
1
1
1,25
1,5
1
Dimensions
mm 30x11 30x11 30x11 38x10 38x10 38x10 38x10
9357G
Each 16,10 16,10 23,10 20,20 20,20 19,60 25,60
Ø
mm
14
14
15
16
16
18
18
Pitch
mm
1,25
1,5
1
1
1,5
1
1,5
Dimensions
mm 38x10 38x10 38x10 45x14 45x14 45x14 45x14
9357G
Each 22,40 22,40 35,20 35,20 27,20 32,80 27,20
Ø
mm
18
20
20
20
22
22
24
Pitch
mm
2
1
1,5
2
1,5
2
1
Dimensions
mm 45x14 45x14 45x14 45x14 55x16 55x16 55x16
9357G
Each 32,80 32,80 27,20 32,80 45,10 53,10 53,10
Ø
mm
24
24
25
26
27
27
28
Pitch
mm
1,5
2
1,5
1,5
1,5
2
1,5
Dimensions
mm 55x16 55x16 55x16 55x16 65x18 65x18 65x18
9357G
Each 45,10 53,10 69,10 69,10 78,40 78,40 78,40
Ø
mm
30
30
30
32
33
33
34
Pitch
mm
1
1,5
2
1,5
1,5
2
1,5
Dimensions
mm 65x18 65x18 65x18 65x18 65x18 65x18 65x18
9357G
Each 78,40 78,40 78,40 78,40 78,40 78,40 78,40
Ø
mm
36
36
36
36
39
39
39
Pitch
mm
1
1,5
2
3
1,5
2
3
Dimensions
mm 65x18 65x18 65x18 65x25 75x20 75x20 75x30
9357G
Each 111,00 78,40 78,40 78,40 125,00 125,00 125,00
Ø
mm
40
40
40
Pitch
mm
1,5
2
3
Dimensions
mm 75x20 75x20 75x30
9357G
Each 125,00 125,00 125,00
vuoto
ROUNDDIES
