1236 / 1378
1236
ROUND DIES
1236
13
Prices in EURO - VAT not included
9358G
LEFT USAGE
MF
HSS
Orig. Völkel - Art. 262
Product description as Art. 9350G
ISO FINE METRIC THREAD, according to DIN 13 - MF Fine Metric – Tolerance 6g
LEFT-HAND USE.
HSS. Normal chamfer. For steel with R up to 800 N/mm^2.
Ø
mm
6
8
8
10
10
12
12
Pitch
mm
0,75
0,75
1
1
1,25
1
1,25
Dimensions
mm 20x7 25x9 25x9 30x11 30x11 38x10 38x10
9358G
Each 18,50 20,10 20,10 24,10 24,10 29,40 29,40
Ø
mm
12
14
14
16
16
18
20
Pitch
mm
1,5
1,25
1,5
1
1,5
1,5
1,5
Dimensions
mm 38x10 38x10 38x10 45x14 45x14 45x14 45x14
9358G
Each 29,40 30,50 30,50 41,60 41,60 46,50 46,50
Ø
mm
22
24
24
30
Pitch
mm
1,5
1,5
2
2
Dimensions
mm 55x16 55x16 55x16 65x18
9358G
Each 66,10 66,10 66,10 129,00
vuoto
ROUNDDIES
9360G
BSW
HSS
Orig. Völkel - Art. 224
Product description as Art. 9350G
BSW WHITWORTH THREAD, according to BS 84
RIGHT-HAND USE.
HSS. Normal chamfer. For steel with R up to 800 N/mm^2.
Ø
inches
1/8
5/32
3/16
7/32
1/4
5/16
3/8
Threads per inch
No
40
32
24
24
20
18
16
Dimensions
mm 20x5 20x5 20x7 20x7 20x7 25x9 30x11
9360G
Each 14,10 14,10 14,10 14,10 14,10 16,10 17,60
Ø
inches
7/16
1/2
9/16
5/8
3/4
7/8
1
Threads per inch
No
14
12
12
11
10
9
8
Dimensions
mm 30x11 38x14 38x14 45x18 45x18 55x22 55x22
9360G
Each 20,40 23,10 28,20 31,10 31,10 47,90 47,90
vuoto
ROUNDDIES
9362G
BSF
HSS
Orig. Völkel - Art. 228
Product description as Art. 9350G
BSF FINE WHITWORTH THREAD (BS 84 STANDARD)
RIGHT-HAND USE.
HSS. Normal chamfer. For steel with R up to 800 N/mm^2.
Ø
inches
3/16
1/4
5/16
3/8
7/16
1/2
5/8
Threads per inch
No
32
26
22
20
18
16
14
Dimensions
mm 20x7 20x7 25x9 30x11 30x11 38x10 45x14
9362G
Each 14,10 14,10 16,10 19,20 20,40 28,80 43,60
Ø
inches
3/4
7/8
1
Threads per inch
No
12
11
10
Dimensions
mm 45x14 55x22 55x22
9362G
Each 43,60 55,90 55,90
vuoto
ROUNDDIES
9364G
UNC
HSS
Orig. Völkel - Art. 234
Product description as Art. 9350G
UNC AMERICAN THREAD, according to ANSI-B1.1
RIGHT-HAND USE.
HSS. Normal chamfer. For steel with R up to 800 N/mm^2.
Thread UNC
No. 1 No. 2 No. 3 No. 4 No. 5 No. 6 No. 8
Threads per inch
No
64
56
48
40
40
32
32
Dimensions
mm 16x5 16x5 16x5 20x5 20x5 20x7 20x7
9364G
Each 24,10 24,10 24,10 17,60 17,60 17,60 17,60
Thread UNC
No. 10 No. 12 1/4
5/16
3/8
7/16
1/2
Threads per inch
No
24
24
20
18
16
14
13
Dimensions
mm 20x7 20x7 20x7 25x9 30x11 30x11 38x14
9364G
Each 17,60 17,60 14,10 16,10 17,60 20,40 23,10
Thread UNC
9/16
5/8
3/4
7/8
1
Threads per inch
No
12
11
10
9
8
Dimensions
mm 38x14 45x18 45x18 55x22 55x22
9364G
Each 28,20 31,10 31,10 47,90 47,90
vuoto
ROUNDDIES
