MACHINE TAPS
1233
13
Prices in EURO - VAT not included
9311GD
UNC
HSS-E
Orig. Völkel - Art. 757
Product description as Art. 9311GC
HSS-E. Short chamfer. With 35° right-hand spiral flute for structural steel; for metals up to R 900
N/mm². Blind holes.
Thread UNC
7/16
1/2
9/16
5/8
3/4
7/8
1
Threads per inch
No
14
13
12
11
10
9
8
Overall length
mm 100
110
110
110
125
140
160
Thread length
mm 17
20
20
22
25
27
30
Shank Ø
mm 8
9
11
12
14
18
20
Shank square
mm 6,2
7
9
9
11
14,5
16
9311GD
Each 24,40 24,40 35,20 35,20 70,40 84,90 95,80
vuoto
MACHINETAPS
9314G
UNF
HSS-E
Orig. Völkel - Art. 765
REINFORCED SHANK
RIGHT-HAND USE
UNF AMERICAN THREAD- According to ANSI-B1.1 (DIN 371)
HSS-E. Proper chamfer. Universal type. Through holes.
Thread UNF
No. 4 No. 5 No. 6 No. 8 No. 10 No. 12 1/4
Threads per inch
No
48
44
40
36
32
28
28
Overall length
mm 50
56
56
63
70
70
80
Thread length
mm 10
11
12
13
15
16
17
Shank Ø
mm 3,5
3,5
4
4,5
6
6
7
Shank square
mm 2,7
2,7
3
3,4
4,9
4,9
5,5
9314G
Each 11,50 11,50 11,50 11,50 11,50 11,50 11,50
Thread UNF
5/16
3/8
Threads per inch
No
24
24
Overall length
mm 90
100
Thread length
mm 17
18
Shank Ø
mm 8
9
Shank square
mm 6,2
7
9314G
Each 14,60 16,30
vuoto
MACHINETAPS
9315G
UNF
HSS-E
Orig. Völkel - Art. 767
Product description as Art. 9314G
HSS-E. Short chamfer. With 35° right-hand spiral flute for structural steel; for metals up to R 900
N/mm². Deep blind holes.
Thread UNF
1/4
5/16
3/8
Threads per inch
No
28
24
24
Overall length
mm 80
90
100
Thread length
mm 10
10
10
Shank Ø
mm 7
8
9
Shank square
mm 5,5
6,2
7
9315G
Each 14,60 17,60 19,30
vuoto
MACHINETAPS
9315GE
UNF
HSS-E
Orig. Völkel - Art. 775
REDUCED SHANK
RIGHT-HAND USE
UNF AMERICAN THREAD according to ANSI-B1.1 (DIN 376)
HSS-E. Proper chamfer. Universal type. Through holes.
Thread UNF
7/16
1/2
5/8
3/4
1
Threads per inch
No
20
20
18
16
12
Overall length
mm 100
100
100
110
150
Thread length
mm 22
22
22
25
28
Shank Ø
mm 8
9
12
14
20
Shank square
mm 6.2
7
9
11
16
9315GE
Each 19,30 19,30 29,10 56,20 77,40
vuoto
MACHINETAPS
9315GP
UNF
HSS-E
Orig. Völkel - Art. 777
Product description as Art. 9315GE
HSS-E. Short chamfer. With 35° right-hand spiral flute for structural steel; for metals up to R 900
N/mm². Blind holes.
Thread UNF
7/16
1/2
5/8
3/4
1
Threads per inch
No
20
20
18
16
12
Overall length
mm 100
100
100
110
150
Thread length
mm 13
13
15
17
20
Shank Ø
mm 8
9
12
14
20
Shank square
mm 6,2
7
9
11
16
9315GP
Each 24,40 24,40 35,20 70,40 95,80
