1255 / 1378
1255
DIE HOLDERS
1255
13
Prices in EURO - VAT not included
DIE HOLDERS
9460
Prod. SCU
Painted body with bars. With adjusting and fixing screws. UNI-DIN Standards.
In high-resistance steel. Fine quality.
Type
16
20
20A 20,6
25
25,4
30
For threading dies Ø UNI
mm -
-
-
20,6
-
25,4
-
For threading dies Ø DIN
mm 16
20
20
-
25
-
30
For threading dies thickness mm 5
7
5
-
9
-
11
9460
Each 9,80 11,60 11,60 11,60 13,40 13,40 13,40
Type
38
38A 38,1
45
45A 50,8
55
For threading dies Ø UNI
mm -
-
38,1
-
-
50,8
-
For threading dies Ø DIN
mm 38
38
-
45
45
-
55
For threading dies thickness mm 10
14
-
14
18
-
16
9460
Each 15,20 15,20 15,20 20,50 20,50 25,10 25,10
Type
55A 63,5
65
65A 75
75A
For threading dies Ø UNI
mm -
63,5
-
-
-
-
For threading dies Ø DIN
mm 55
-
65
65
75
75
For threading dies thickness mm 22
-
18
25
20
30
9460
Each 25,10 35,60 44,50 44,50 59,70 59,70
DIEHOLDERS
9465G
Orig. Völkel - Art. 150
DIN 225 (DIN EN 22568). High-resistance die cast. Body with finely worked seat, lacquered. With
adjusting and fixing screws Extra quality.
Ø and thickness
mm
16x5 20x5 20x7 25x9 30x11 38x10 38x14
9465G
Each 3,86
4,00
4,00
4,50
7,34 11,50 11,50
Ø and thickness
mm
45x14 45x18 55x16 55x22 65x18 65x25
9465G
Each 13,70 13,70 17,60 17,60 29,70 29,70
DIEHOLDERS
9467G
Orig. Völkel - Art. 152
DIN 225 (DIN EN 22568). High-resistance steel. Body with finely worked seat, lacquered with
polished bars. With adjusting and fixing screws.
Extra quality.
Ø and thickness
mm
45x18 55x22 65x25 75x20 75x30 90x22 90x36 105x22 105x36
9467G
Each 22,40 32,10 40,10 67,10 67,10 82,80 82,80 127,00 127,00
DIEHOLDERS
PIPE DIE HOLDERS
9468
9469
9470
Prod. SCU
Made of steel.
Both ends are arranged for mounting of two round dies with different diameter.
Art.
9468
9469
9470
For dyes Ø
mm 20,6x25,4 25,4x38,1 38,1x50,8
Each 29,70
39,70
50,10
vuoto
PIPEDIEHOLDERS
ADJUSTABLE TAP WRENCHES
9472
Prod. SCU
Painted body with levers.
Hardened clamping wedges.
In high-resistance steel. Fine quality.
Size
0
1
2
3
4
For taps by Withworth inches 1/16 to 1/4 1/16 to 3/8 1/32 to 1/2 7/32 to 3/4 7/16 to 1
For taps by
M.
1 to 8
1 to 10
4 to 12
5 to 20
9 to 27
Drive framework opening mm 2,1 to 4,9 2,1 to 5,5
3,4 to 9
4,9 to 12
5,5 to 16
9472
Each 16,10
16,10
23,20
33,10
44,50
Size
5
6
7
For taps by Withworth inches 1/2 to 1 1/4 3/4 to 1 1/2 1-2 1/2
For taps by
M.
13 to 33
19 to 39
27 to 64
Drive framework opening mm 7 to 20
11 to 24
16 to 40
9472
Each 57,90
90,80
90,80
ADJUSTABLETAPWRENCHES
9476G
Orig. Völkel - Art. 130
DIN 1814. High-resistance die cast. Lacquered body with polished levers.
Hardened and ground clamping wedges. Extra quality.
Size
0
1
1 1/2
2
3
For taps by Withworth inches 1/16 to 1/4 1/16 to 3/8 1/16 to 1/2 5/32 to 1/2 7/32 to 3/4
For taps by
M.
1 to 8
1 to 10
1 to 12
4 to 12
5 to 20
Drive framework opening mm 2 to 5
2 to 6,3
2,1 to 8
3 to 9
4,9 to 12
9476G
Each 4,80
5,22
5,22
8,42
15,10
Size
4
5
For taps by Withworth inches 7/16 to 1 1/2 to 1 1/4
For taps by
M.
11 to 27
13 to 32
Drive framework opening mm 5,5 to 16
7 to 20
9476G
Each 28,80
44,70
ADJUSTABLETAPWRENCHES
