THREAD INSERTS IN STAINLESS STEEL
1259
13
Prices in EURO - VAT not included
9500GE
INOX
BSW
Product description as Art. 9500G
SEPARATE THREADED INSERTS, LENGTH 1.5xØ
Packs of 100 pcs, not sold separately.
Thread Ø BSW
inches
1/8
3/16
1/4
5/16
3/8
7/16
1/2
Threads per inch
No.
40
24
20
18
16
14
12
Supplier code
08341 08342 08343 08344 08345 08346 08347
9500GE
Each 0,94
0,94
0,38
0,46
0,78
0,96
0,96
vuoto
THREAD INSERTS INSTAINLESSSTEEL
9500GF
INOX
BSF
Product description as Art. 9500G
SEPARATE THREADED INSERTS, LENGTH 1.5xØ
Packs of 100 pcs, not sold separately.
Thread Ø BSF
inches
3/16
1/4
5/16
3/8
7/16
1/2
Threads per inch
No.
32
26
22
20
18
16
Supplier code
08362 08363 08365 08366 08367 08368
9500GF
Each 0,94
0,38
0,46
0,78
0,96
0,96
vuoto
THREAD INSERTS INSTAINLESSSTEEL
9500GL
INOX
BSP
Product description as Art. 9500G
SEPARATE THREADED INSERTS, LENGTH 1.5xØ
Up to Ø 1/2" inch, packs of 50 pcs, not sold separately; from Ø 5/8" inch, packs of 5 pcs, not sold
separately.
Thread Ø BSP (G)
inches
1/8
1/4
3/8
1/2
5/8
3/4
1
Threads per inch
No.
28
19
19
14
14
14
11
Supplier code
08380 08381 08382 08383 08384 08385 08387
9500GL
Each 0,58
0,88
1,02
1,32
3,28
3,28 10,10
vuoto
THREAD INSERTS INSTAINLESSSTEEL
9501G
M MF
TAPS FOR THREADED INSERTS
Special type for housing threaded inserts Art. 9500 G.
For int Ø
mm
3
4
5
6
7
8
8
9
Pitch
mm
0,5
0,7
0,8
1
1
1
1,25 1,25
Pre-hole Ø
mm 3,2
4,2
5,2
6,3
7,3
8,3
8,3
9,3
Supplier code
03005 03007 03008 03009 03010 03012 03011 03013
9501G
Each 8,42 8,42 8,42 8,42 10,50 10,50 10,50 12,80
For int Ø
mm
10
10
10
12
12
12
12
14
Pitch
mm
1
1,25 1,5
1
1,25 1,5 1,75 1,25
Pre-hole Ø
mm 10,3 10,3 10,4 12,3 12,3 12,4 12,4 14,5
Supplier code
03017 03016 03015 03023 03022 03021 03020 03029
9501G
Each 12,80 12,80 12,80 17,80 17,80 17,80 14,60 20,20
For int Ø
mm
14
14
16
18
20
22
Pitch
mm
1,5
2
2
2,5
2,5
2,5
Pre-hole Ø
mm 14,5 14,5 16,5 18,6 20,6 22.6
Supplier code
03028 03027 03033 03035 03038 03041
9501G
Each 20,20 20,20 25,40 32,10 35,30 40,70
vuoto
THREAD INSERTS INSTAINLESSSTEEL
9501GA
UNC/NC
Special type for housing threaded inserts Art. 9500 GA.
For threads UNC
inches
No. 2 No. 4 No. 5 No. 6 No. 8 No. 10 No. 12
Pre-hole Ø
mm 2,4
3,0
3,4
3,7
4,4
5,1
5,7
Supplier code
03100 03101 03102 03103 03104 03105 03106
9501GA
Each 12,80 12,80 12,80 12,80 12,80 12,80 12,80
For threads UNC
inches
1/4
5/16
3/8
7/16
1/2
Pre-hole Ø
mm 6,7
8,3
9,9
11,6
13,0
Supplier code
03107 03108 03109 03110 03111
9501GA
Each 8,42
9,14
9,58 12,80 14,60
vuoto
THREAD INSERTS INSTAINLESSSTEEL
9501GB
UNF/NF
Special type for housing threaded inserts Art. 9500 GB.
For threads UNF
No. 4 No. 6 No. 8 No. 10 1/4
5/16
3/8
Pre-hole Ø
mm 3,0
3,7
4,4
5,1
6,6
8,2
9,8
Supplier code
03151 03152 03153 03154 03155 03156 03157
9501GB
Each 12,80 12,80 12,80 12,80 8,42
9,14
9,58
For threads UNF
7/16
1/2
Pre-hole Ø
mm 11,5
13,0
Supplier code
03158 03159
9501GB
Each 12,80 14,60
vuoto
