TAP WRENCHES WITH JAW CHUCK AND SQUARE SHANK 1/4
1258
13
Prices in EURO - VAT not included
TAP WRENCHES WITH JAW CHUCK AND SQUARE SHANK 1/4
9497GA
Orig. Gedore - Art. 8553
Type with 1/4 female square drive to be used with ratchet heads, sliding bars, extensions, etc.
Fully made of steel. Collet with 2 hardened jaws.
Chrome-plated finish.
For taps M 3 to M 6, square drive opening 3.5 to 6mm.
9497GA
Each 30,60
vuoto
TAPWRENCHESWITH JAWCHUCKANDSQUARESHANK1/4
DIE STOCKS WITH SQUARE SHANK 1/4
9497GL
Orig. Gedore - Art. 8553
Type with 1/4 female square drive to be used with ratchet heads, sliding bars, extensions, etc.
Fully made of steel. With adjusting and fixing screws.
Chrome-plated finish.
For dies Ø 20mm.
9497GL
Each 34,80
vuoto
DIESTOCKSWITHSQUARESHANK 1/4
THREAD INSERTS IN STAINLESS STEEL
9500G
INOX
M MF
Orig. V-Coil
DIN 8140
Suitable for thread regeneration. In rhombodail-section stainless steel, spring-shaped, it creates
two perfectly concentric threads, one external coupling with the threaded hole previously made,
and one internal for screw coupling, etc. Drive shank for insertion in the hole, to be removed after
installation by using a suitable cutting tool.
THREADED INSERTS ONLY
Packing units: 100pcs, not sold separately, up to Ø 12mm. From Ø 14mm up to 16mm packing
units: 50pcs, Ø 18mm and 20mm packing units: 25pcs, Ø 22mm packing units: 10pcs.
Type
M
3 0.5 4 0.7 5 0.8 6 1
7 1
8 1 8 1.25 9 1.25 10 1 10 1.25 10 1.25A 10 1.5 12 1 12 1.25
Ø
mm 3
4
5
6
7
8
8
9
10
10
10
10
12
12
Pitch
mm 0,5
0,7
0,8
1
1
1
1,25 1,25
1
1,25 1,25 1,5
1
1,25
Thread length
mm 4,5
6
7,5
9
10,5
12
12
13,5
15
10
15
15
18
12
Supplier code
07305 07307 07308 07309 07310 07312 07311 07313 07317 07216 07316 07315 07324 07223
9500G
Each 0,22 0,22 0,20 0,20 0,34 0,30 0,26 0,50 0,36 0,34 0,36 0,36 0,58 0,50
Type
M
12 1.25A 12 1.5 12 1.75 14 1.25 14 1.25A 14 1.25B 14 1.25C 14 1.5 14 2 16 2 18 2.5 20 2.5 22 2.5
Ø
mm 12
12
12
14
14
14
14
14
14
16
18
20
22
Pitch
mm 1,25 1,5 1,75 1,25 1,25 1,25 1,25 1,5
2
2
2.5
2.5
2.5
Thread length
mm 18
18
18
21
8,4 12,4 16,4
21
21
24
27
30
33
Supplier code
07323 07322 07321 07327 07128 07228 07328 07326 07325 07334 07336 07339 07342
9500G
Each 0,58 0,58 0,58 0,80 0,80 0,80 0,80 0,80 0,80 1,00 1,60 2,04 2,18
Ø 14x1.25 A/B/C are suitable for sparks. Additional diameters available on request.
vuoto
THREAD INSERTS INSTAINLESSSTEEL
9500GA
INOX
UNC
Product description as Art. 9500G
SEPARATE THREADED INSERTS, LENGTH 1.5xØ
Packs of 100 pcs, not sold separately.
Thread Ø UNC
inches
No. 2 No. 4 No. 5 No. 6 No. 8 No. 10 No. 12
Threads per inch
No.
56
40
40
32
32
24
24
Supplier code
08300 08301 08302 08303 08304 08305 08306
9500GA
Each 0,80
0,26
0,30
0,24
0,24
0,26
0,30
Thread Ø UNC
inches
1/4
5/16
3/8
7/16
1/2
Threads per inch
No.
20
18
16
14
13
Supplier code
08307 08308 08309 08310 08311
9500GA
Each 0,30
0,44
0,58
0,76
0,76
vuoto
THREAD INSERTS INSTAINLESSSTEEL
9500GB
INOX
UNF
Product description as Art. 9500G
SEPARATE THREADED INSERTS, LENGTH 1.5xØ
Packs of 100 pcs, not sold separately.
Thread Ø UNF
inches.
No. 4 No. 6 No. 8 No. 10 1/4
5/16
3/8
Threads per inch
No.
48
40
36
32
28
24
24
Supplier code
08390 08391 08392 08393 08325 08326 08327
9500GB
Each 0,70
0,70
0,70
0,28
0,28
0,40
0,58
Thread Ø UNF
inches.
7/16
1/2
Threads per inch
No.
20
20
Supplier code
08328 08329
9500GB
Each 0,76
0,76
vuoto
