THREAD INSERTS IN STAINLESS STEEL
1260
13
Prices in EURO - VAT not included
9501GE
BSW
Special type for housing threaded inserts Art. 9500 GE.
For threads BSW
inches
1/8
3/16
1/4
5/16
3/8
7/16
1/2
Pre-hole Ø
mm 3,4
5,1
6,7
8,3
9,9
11,6
13,0
Supplier code
03201 03202 03203 03204 03205 03206 03207
9501GE
Each 8,42
8,42
8,42
9,14
9,58 12,80 14,60
vuoto
THREAD INSERTS INSTAINLESSSTEEL
9501GF
BSF
Special type for housing threaded inserts Art. 9500 GF.
For threads BSF
inches
3/16
1/4
5/16
3/8
7/16
1/2
Pre-hole Ø
mm 5,0
6,6
8,3
9,9
11,6
13,0
Supplier code
03251 03253 03255 03256 03257 03258
9501GF
Each 8,42
8,42
9,14
9,58 12,80 14,60
vuoto
THREAD INSERTS INSTAINLESSSTEEL
9501GL
BSP
Special type for housing threaded inserts Art. 9500 GL.
Thread BSB (G)
1/8
1/4
3/8
1/2
5/8
3/4
1
Pre-hole Ø
mm 10
13,60 17,10 21,50 23,40
27
33,70
Supplier code
03301 03302 03303 03304 03305 03306 03307
9501GL
Each 12,10 15,30 19,80 32,30 47,40 47,40 75,50
vuoto
THREAD INSERTS INSTAINLESSSTEEL
9502GA
APPLICATION TOOLS
For mounting threaded inserts Art. 9500 G to 9500 GF.
Size
2
4
5
6
7
For metric inserts
M 2x0,4 e 2,2x0,45
3x0,5
3,5x0,6
4x0,7
-
For inserts with threads
UNC No. 2
UNC No. 5, UNC/UNF No. 4,
BSW 1/8
UNC/UNF No. 6
UNC/UNF No. 8
UNC No. 10, BSW 3/16
Supplier code
08002
08004
08005
08006
08007
9502GA
Each
8,28
8,28
8,28
8,28
8,28
Size
8
9
10
11
12
For metric inserts
M
5x0,8
6x1
7x1
8x1 e 8x1,25
9x1 e 9x1,25
For inserts with threads
UNF No. 10, UNC No. 12,
BSF 3/16
UNC/UNF/BSW/BSF 1/4
UNC/BSW 5/16
UNF/BSF 5/16
UNC/BSW 3/8
Supplier code
08008
08009
08010
08011
08012
9502GA
Each
8,28
8,28
9,44
9,44
10,20
Size
13
14
15
16
17
For metric inserts
M 10x1, 10x1,25, 10x1,5
11x1,25 e 11x1,5
12x1, 12x1,25, 12x1,5,
12x1,75
14x1,5 e 14x2
14x1 e 14x1,25
For inserts with threads
UNF/BSF 3/8
UNC/UNF/BSW/BSF 7/16 UNC/UNF/BSW/BSF 1/2 UNC/UNF/BSW/BSF 9/16
-
Supplier code
08013
08014
08015
08016
08017
9502GA
Each
10,20
11,90
11,90
14,30
14,30
Size
18
20
21
22
For metric inserts
M
16x1,5 e 16x2
18x1,5, 18x2, 18x2,5
20x1,5, 20x2, 20x2,5
22x1,5, 22x2, 22x2,5
For inserts with threads
UNC/UNF/BSW/BSF 5/8
UNC/BSW/BSF 3/4
UNF 3/4
UNC/UNF/BSW/BSF 7/8
Supplier code
08018
08020
08021
08022
9502GA
Each
15,70
15,70
15,70
19,80
vuoto
THREAD INSERTS INSTAINLESSSTEEL
9502GAR
1/4 ,,
APPLICATION TOOLS WITH HEXAGONAL JOINT 1/4 DIN 3126 C6,3
Handy or machine application, to install threaded inserts Art. 9500 G as well as all inside
threaded bushings from M 3 to M 12.
For metric inserts
M
3
4
5
6
8
10
12
Hexagonal drive
inches 1/4
1/4
1/4
1/4
1/4
1/4
1/4
Supplier code
08091 08092 08093 08094 08095 08096 08097
9502GAR
Each 8,28
8,28
8,28
8,28
9,44 10,20 11,90
vuoto
THREAD INSERTS INSTAINLESSSTEEL
9502GAS
1/4 ,,
1/2 ,,
APPLICATION TOOLS WITH HEXAGONAL JOINT 1/4-1/2 DIN 3126 C6,3
Handy or machine application, to install threaded inserts Art. 9500 GL as well as all inside
threaded bushings from BSP (G) 1/8" to 1".
For BSP (G) inserts
inches
1/8
1/4
3/8
1/2
5/8
3/4
1
Threads per inch
No.
28
19
19
14
14
14
11
Hexagonal drive
inches 1/4
1/4
1/4
1/4
1/2
1/2
1/2
Supplier code
08080 08081 08082 08083 08084 08085 08087
9502GAS
Each 13,50 13,50 15,70 18,00 22,50 22,50 31,40
vuoto
THREAD INSERTS INSTAINLESSSTEEL
