THREAD INSERTS IN STAINLESS STEEL
1262
13
Prices in EURO - VAT not included
9503GA
UNC
Product description as Art. 9503G
SETS OF MONO-SIZE THREADED INSERTS LENGHT 1,5 x Ø
Each set contains:
No.1 size of threaded inserts according to the indicated quantity,No.1 HSS spotting drill, No.1
threading tap, No.1 tool for the application, No.1 tool for cutting.
Supplied in case.
Thread UNCxno. of threads
2x56
4x40
5x40
6x32
8x32
10x24
Tip Ø
mm 2,4
3,1
3,4
3,8
4,4
5,2
Insert quantity
No
20
20
20
20
20
20
Applying tool
Gr
2
4
4
5
6
7
Cutting tool
Gr
2
4
4
5
6
6
Supplier code
04100 04101 04106 04102 04103 04104
9503GA
Each 43,60
39,40
39,40
39,40
39,40
39,40
Thread UNCxno. of threads
12x24 1/4x20 5/16x18 3/8x16 7/16x14 1/2x13
Tip Ø
mm 5,8
6,7
8,3
9,9
11,6
13
Insert quantity
No
20
20
20
15
10
10
Applying tool
Gr
8
9
10
12
14
15
Cutting tool
Gr
8
9
10
12
14
15
Supplier code
04105 04107 04108 04109 04110 04111
9503GA
Each 39,40
35,50
43,40
46,30
52,10
57,10
vuoto
THREAD INSERTS INSTAINLESSSTEEL
9503GB
UNF
Product description as Art. 9503G
SETS OF MONO-SIZE THREADED INSERTS LENGHT 1,5 x Ø
Each set contains:
No.1 size of threaded inserts according to the indicated quantity,No.1 HSS spotting drill, No.1
threading tap, No.1 tool for the application, No.1 tool for cutting.
Supplied in case.
Thread UNFxno. of threads
4x48 6x40 8x36 10x32 1/4x28 5/16x24 3/8x24 7/16x20 1/2x20
Tip Ø
mm 3
3,8 4,4 5,1 6,7 8,3 9,8 11,5 13
Insert quantity
No 20 20 20 20 20 20 15 10 10
Applying tool
Gr
4
5
6
8
9
11 13 14 15
Cutting tool
Gr
4
5
6
8
9
11 13 14 15
Supplier code
04120 04121 04122 04123 04125 04126 04127 04128 04129
9503GB
Each 39,40 39,40 39,40 39,40 35,50 43,40 46,30 52,10 57,10
vuoto
THREAD INSERTS INSTAINLESSSTEEL
9503GE
BSW
Product description as Art. 9503G
SETS OF MONO-SIZE THREADED INSERTS LENGHT 1,5 x Ø
Each set contains:
No.1 size of threaded inserts according to the indicated quantity,No.1 HSS spotting drill, No.1
threading tap, No.1 tool for the application, No.1 tool for cutting.
Supplied in case.
Øxno. of threads
inchesxNo.
1/8x40 3/16x24 1/4x20 5/16x18 3/8x16 7/16x14 1/2x12
Tip Ø
mm 3,4
5
6,7
8,3
9,9
11,5
13
Insert quantity
No
20
20
20
20
15
10
10
Applying tool
Gr
4
8
9
10
12
14
15
Cutting tool
Gr
4
8
9
11
12
14
15
Supplier code
04141 04142 04143 04144 04145 04146 04147
9503GE
Each 39,40 39,40 35,50 43,40 46,30 52,10 57,10
vuoto
THREAD INSERTS INSTAINLESSSTEEL
9503GF
BSF
Product description as Art. 9503G
SETS OF MONO-SIZE THREADED INSERTS LENGHT 1,5 x Ø
Each set contains:
No.1 size of threaded inserts according to the indicated quantity,No.1 HSS spotting drill, No.1
threading tap, No.1 tool for the application, No.1 tool for cutting.
Supplied in case.
Øxno. of threads
inchesxNo.
3/16x32 1/4x26 5/16x22 3/8x20 7/16x18 1/2x16
Tip Ø
mm
5
6,6
8,3
9,9
11,5
13
Insert quantity
No
20
20
20
15
10
10
Applying tool
Gr
8
9
11
13
14
15
Cutting tool
Gr
6
9
11
13
14
15
Supplier code
04162 04163 04165 04166 04167 04168
9503GF
Each
39,40
35,50
43,40
46,30
52,10
57,10
vuoto
THREAD INSERTS INSTAINLESSSTEEL
