TOOL BIT HOLDERS, MECHANICAL FIXING
1285
13
Prices in EURO - VAT not included
9810
Made from treated steel. Disk fixing system with threaded screw, suitable for turning and copying.
Bit holder only, without bits.
Right-hand, internal use.
Flat/round stem Ø
mm
20
25
Cutting angle
degrees 92
92
Overall length
mm 250
300
Head width and length
mm 13x35 17x40
Min. bore Ø
mm 27
34
9810
Each 214,00 256,00
For tool bits see Art. 9834 - 9836 - 9838.
Subplates and spare screws can be supplied on request.
vuoto
TOOLBITHOLDERS,MECHANICALFIXING
9812
Steel, threaded screw fastening suitable for screw threads. Arms do not include padding.
Right-hand, internal use. ISO THREAD.
Flat/round stem Ø
mm
20
25
Pitch
mm 1,5
1,5
Overall length
mm 170
300
Min. bore Ø
mm 24
30
9812
Each 92,10 107,00
For plates see Art. 9840.
Underplates and spare screws can be supplied on request.
vuoto
TOOLBITHOLDERS,MECHANICALFIXING
TOOL BITS, MECHANICAL FIXING
9820
9822
9824
HARTMETALL
TIN
Prod. SCU
HARD METAL, TIN-coated. Universal quality.
Exceptional hardness. Maximum shock and abrasion-proof.
With fixing hole for central pin.
For tool bit holder Art. 9800 – 9802 – 9804 x 20 and 25mm.
TRIANGULAR SHAPE (TNMG)
For fine removal – radius 0.4.
Dimensions: 15.8x9.52x4.76mm.
9820
Each 11,80
vuoto
Product description as Art. 9820
TRIANGULAR SHAPE (TNMG)
For medium removal – radius 0.8.
Dimensions 15.4x9.52x4.76mm.
9822
Each 11,80
vuoto
Product description as Art. 9820
TRIANGULAR SHAPE (TNMG)
For thick removal – radius 1.2.
Dimensions 14.7x9.52x4.76mm.
9824
Each 11,80
vuoto
TOOLBITS,MECHANICALFIXING
9828
9830
HARTMETALL
TIN
HARD METAL, TIN-coated. Universal quality.
Exceptional hardness. Maximum shock and abrasion-proof.
With fixing hole for central pin.
For tool bit holder Art. 9806 x 20 and 25mm.
SQUARE SHAPE (SNMG)
For medium removal – radius 0.8.
Dimensions 12.7x4.76mm.
9828
Each 13,10
vuoto
Product description as Art. 9828
SQUARE SHAPE (SNMG)
For thick removal – radius 1.2.
Dimensions 12.7x4.76mm.
9830
Each 13,10
vuoto
TOOLBITS,MECHANICALFIXING
9832
HARTMETALL
TIN
HARD METAL, TIN coated. Universal quality.
Exceptional hardness. Maximum resistance to impact and abrasion.
Includes mounting hole for screw.
RHOMBOID SHAPE (CNMG)
For tool bit holders Art. 9808 x 20 and 25mm.
For medium removal - radius 0.8.
Dimensions 12.7x4.76mm.
9832
Each 11,10
vuoto
TOOLBITS,MECHANICALFIXING
