1286 / 1378
1286
TOOL BITS, MECHANICAL FIXING
1286
13
Prices in EURO - VAT not included
9833L
HARTMETALL
TIN
HARD METAL, TIN coated. Universal quality.
Exceptional hardness. Maximum resistance to impact and abrasion.
Includes mounting hole for screw.
TRIANGULAR SHAPE (16 ER 150 ISO 134), for external threads at 60°.
For tool bit holders Art. 9809 x 20 and 25mm.
Pitch
mm
1
1.25
1.5
1.75
2
2.5
3
9833L
Each 13,60 13,60 13,60 13,60 13,60 13,60 13,60
vuoto
TOOLBITS,MECHANICALFIXING
9833P
HARTMETALL
TIN
Product description as Art. 9833L
RHOMBOID SHAPE (CCMT)
For tool bit holders Art. 9809 E x 8 - 10 - 12 - 16.
Size
mm
8
16
For pad arms
Art. 9809 E 8-10-12 9809 E 16
Radius
mm 0,4
0,4
CCMT shape
060204N
09T304N
9833P
Each
8,78
10,70
vuoto
TOOLBITS,MECHANICALFIXING
9834
9836
9838
HARTMETALL
TIN
HARD METAL, TIN-coated. Universal quality.
Exceptional hardness. Maximum shock and abrasion-proof.
For tool bit holder Art. 9810 x 20 and 25mm.
TRIANGULAR SHAPE (TPUN)
For fine removal – radius 0.4.
Dimensions: 15.8x9.52x3.18mm.
9834
Each 10,50
vuoto
Product description as Art. 9834
TRIANGULAR SHAPE (TPUN)
For medium removal – radius 0.8.
Dimensions: 15.1x9.52x3.18mm.
9836
Each 10,50
vuoto
Product description as Art. 9834
TRIANGULAR SHAPE (TPUN)
For thick removal – radius 1.2.
Dimensions: 14.5x9.52x3.18mm.
9838
Each 10,50
vuoto
TOOLBITS,MECHANICALFIXING
9840
HARTMETALL
TIN
HARD METAL, TIN coated. Universal quality.
Exceptional hardness. Maximum resistance to impact and abrasion.
Includes mounting hole for screw.
TRIANGULAR SHAPE (16 IR 150 ISO 134), for internal threads PITCH 1.5.
For tool bit holders Art. 9812 x 20 and 25mm.
9840
Each 13,40
vuoto
TOOLBITS,MECHANICALFIXING
TOOLS FOR EXTERNAL CUTTING
9845A
Prod. SCU
Made from CHROME-VANADIUM steel.
BLADE HOLDER BODY with fixing screws.
Shank height
mm
20
25
Dimensions
mm 100x44x41 h 110x49x48 h
For insert holder blades
Art.
9845B 1
9845B 2
9845A
Each 55,70
68,50
vuoto
TOOLSFOREXTERNALCUTTING
9845B
Product description as Art. 9845A
TOOLHOLDER BLADES
Size
1
2
Dimensions
mm 109x25,75 h 150x31,75 h
For base
Art.
9845A 20
9845A 25
For inserts
Art.
9845C 1
9845C 2
9845B
Each
41,90
41,90
vuoto
TOOLSFOREXTERNALCUTTING
9845C
In hard metal.
INSERTS
Size
1
2
Thickness at the cutting
edge
mm 3
4
For insert holder blades
Art.
9845B 1 9845B 2
9845C
Each 8,78 10,30
vuoto
