FACE PLATE FOR SELF-CENTRING CHUCKS
462
6
Prices in EURO - VAT not included
FACE PLATE FOR SELF-CENTRING CHUCKS
1571P
Prod. SCU
In die cast. Fusion raw finish.
The dimensions listed below are indicative and may be subject to change.
Flange Ø
mm
90
115
145
210
260
320
Flange height
mm 15
22
18
25
25
25
Bore Ø
mm 30
30
15
25
25
30
Hub Ø
mm 60
85
72
118
118
118
Hub height
mm 30
35
40
50
50
55
Weight
Kg
1,5
3
4,5
8
16
25
1571P
Each 18,70 29,80 30,90 93,30 135,00 167,00
The dimensions listed below are indicative and may be subject to change.
Product running out of stock.
vuoto
FACEPLATEFORSELF-CENTRINGCHUCKS
REVOLVING CENTERS
1578
new
60
Prod. SCU
Light. Made of hardened and ground steel, hardness HRC 61-62.
With tip at 60°.
Drive
C.M.
2
3
4
Rotating tip Ø
mm 25
28
32
Body Ø
mm 45
52
60
Radial workload
N 560
790
1100
Weight
Kg 0,350 0,700 1,200
1578
Each 87,10 107,00 122,00
vuoto
REVOLVINGCENTERS
1579
60
Type precision, In forged steel, hardened and ground. Hardness HRc 61-62.
Point at 60°
Drive
C.M.
1
2
3
4
5
Rotating tip Ø
mm 10
18
23
25
38
Body Ø
mm 28
41
50
60
75
Max load
Kg
80
180
270
550
1000
Weight
Kg 0,200 0,550 0,970 1,550 3,200
1579
Each 129,00 134,00 172,00 246,00 358,00
C.M. 7 revolving centres available on request.
vuoto
REVOLVINGCENTERS
1580
60
Heavy duty, high-precision centering.
In high resistance steel, completely hardened and ground. Hardness HRc 61-63.
3 x double ball bearings. Point at 60°
Drive
C.M.
2
3
4
5
6
Rotating tip Ø
mm 18
24
25
38
50
Body Ø
mm 46
60
70
90
105
Max rounds/revolution
No 5500 5500 5000 4000 2800
Max load
Kg 220
500
800
1500 2500
Weight
Kg 0,680 1,300 2,100 4,500 9,200
1580
Each 157,00 209,00 283,00 411,00 1.070,00
vuoto
REVOLVINGCENTERS
BULL NOSE LATHE CENTERS
1582
60
Prod. SCU
Type suitable for pipe and hollow parts lathing and grinding.
Completely in hardened and ground steel.
Self-adjusting and thrust bearings.
Point at 60°
Size
2
2A
3
3A
4
5
Drive
C.M.
2
2
3
3
4
5
Rotating cone max Ø mm 45
55
55
70
70
90
Rotating cone min Ø mm 15
20
20
25
25
32
Max axial load
Kg
80
120
120
150
200
350
1582
Each 223,00 278,00 289,00 334,00 345,00 456,00
vuoto
BULLNOSELATHECENTERS
