SELF-CENTRING CHUCKS
461
6
Prices in EURO - VAT not included
1569G
new
Simple guide, special spheroidal die cast body.
4-jaws very high-precision model.
With 2 jaw sets: 1 for inside use, 1 for outside use and wrench. Slipping parts hardened and
ground. Excellent vibration absorption, crown forged, balanced and hardened. In compliance with
DIN 6350 A standards.
Ø
mm
100
125
160
200
250
315
Bore Ø
mm 20
32
42
55
76
103
Max rounds/revolution No 4500
4000
3600
3000
2500
2000
Tightening force
kN 27
31
47
55
63
69
1569G
Each 884,00 968,00 1.160,00 1.380,00 1.890,00 2.800,00
On request we supply Jaws sets for indoor, outdoor and not hardened.
vuoto
Riferimenti quote
A (Diametro)
mm 100
125
160
200
250
315
B (H6) mm
mm 70
95
125
160
200
260
C
mm 3
4
4
4
5
5
D
mm 50
56
65
73,5
82
95
E
mm 20
32
42
55
76
103
F
mm 83
108
140
176
224
286
G
mm 3xM8 3xM8 3xM10 3xM10 3xM12 3xM16
H
mm 48
52
61
69
90
130
J
mm 18
22,5
26
32,5
40
46
K
mm 8
9
10
11
12
14
Peso c.a.
Kg 2,9
4,5
8,2
14,6
25,7
44,2
SELF-CENTRINGCHUCKS
1570G
Double guide, special spheroidal die cast body.
3-jaws very high-precision model.
With 2 jaw sets: 1 for inside use, 1 for outside use and wrench. Slipping parts hardened and
ground. High clamping values, guaranteed by pinion and crown extra-toothing. Pinions and crown
ground and hardened. In compliance with DIN 6350 standards.
Ø
mm
200
230
250
315
Bore Ø
mm 55
65
76
103
Weight
Kg
15
16
26,5
48
1570G
Each 2.050,00 2.450,00 2.820,00 4.330,00
vuoto
SELF-CENTRINGCHUCKS
1570GA
Sets of 3 internal jaws, hardened. For Art. 1570 G.
Ø
mm
200
230
250
315
1570GA
Per set 700,00 627,00 930,00 1.340,00
vuoto
SELF-CENTRINGCHUCKS
1570GB
Sets of 3 external jaws, hardened. For Art.1570 G.
Ø
mm
200
230
250
315
1570GB
Per set 676,00 630,00 916,00 1.450,00
vuoto
SELF-CENTRINGCHUCKS
1570GE
Sets of 3 blocks, not hardened. Per Art. 1570 G.
Ø
mm
200
230
250
315
1570GE
Per set 136,00 136,00 197,00 282,00
vuoto
SELF-CENTRINGCHUCKS
1570GF
Sets of 3 hardened supports, for blocks. Per Art. 1570 G.
Ø
mm
200
230
250
315
1570GF
Per set 627,00 627,00 702,00 1.130,00
vuoto
