ASSORTMENTS OF ELASTIC PLIERS - ER/ESX TYPE
457
6
Prices in EURO - VAT not included
ASSORTMENTS OF ELASTIC PLIERS - ER/ESX TYPE
1560GZE
Prod. SCU
On support for easy access.
Size
16
20
25
32
Chucks included Art.
1560GS 1560GT 1560GV 1560GZ
min/max tightening Ø mm 1-10
2-13
2-16
3-20
Chucks included
No
10
12
15
18
1560GZE
Each 208,00 269,00 318,00 391,00
vuoto
ASSORTMENTSOFELASTICPLIERS -ER/ESXTYPE
DIN 6499-B/ISO 15488 ER/ESX COLLETS FOR CHUCKS, WIDE OPENING
1561GA
8
Prod. SCU - Orig. Fahrion
In special steel. High rotation precision up to 5 µm. This product allows using higher working
parameters, it gives tools longer life, saving on working costs. Treated surface, ruby balls, lapped,
with beveled edges for collets stronger clamping and chucks longer life. Particularly suitable for
use with HSC and orig. Fahrion chucks.
Size 8.
Clamping elastic capacity 0.5mm. Dimensions (mm) D = 8,5 L = 13,6.
Tightening Ø
mm
1
1,5
2
2,5
3
3,5
4
1561GA
Each 46,10 46,10 46,10 46,10 38,40 38,40 38,40
Tightening Ø
mm
4,5
5
1561GA
Each 38,40 38,40
vuoto
DIN 6499-B/ISO 15488ER/ESXCOLLETSFORCHUCKS,WIDEOPENING
1561GB
11
Product description as Art. 1561GA
Size 11.
Clamping elastic capacity 0.5mm. Dimensions (mm) D = 11,5 L = 18.
Tightening Ø
mm
1
1,5
2
2,5
3
3,5
4
1561GB
Each 42,80 42,80 42,80 42,80 34,60 34,60 34,60
Tightening Ø
mm
4,5
5
5,5
6
6,5
7
1561GB
Each 34,60 34,60 34,60 34,60 34,60 34,60
vuoto
DIN 6499-B/ISO 15488ER/ESXCOLLETSFORCHUCKS,WIDEOPENING
1561GC
16
Product description as Art. 1561GA
Size 16.
Clamping elastic capacity 1mm (0.5 for clamping Ø 1-1.5mm).
Dimensions (mm) D = 17 L = 27,5.
Tightening Ø
mm
1
1,5
2
2,5
3
3,5
4
1561GC
Each 41,40 41,40 41,40 41,40 32,70 55,70 32,70
Tightening Ø
mm
4,5
5
5,5
6
6,5
7
7,5
1561GC
Each 55,70 32,70 55,70 32,70 55,70 32,70 55,70
Tightening Ø
mm
8
8,5
9
9,5
10
1561GC
Each 32,70 55,70 32,70 55,70 32,70
vuoto
DIN 6499-B/ISO 15488ER/ESXCOLLETSFORCHUCKS,WIDEOPENING
1561GF
20
Product description as Art. 1561GA
Size 20.
Clamping elastic capacity 1mm. Dimensions (mm) D = 21 L = 31,5.
Tightening Ø
mm
2
2,5
3
3,5
4
5
6
1561GF
Each 42,60 42,60 33,70 56,70 33,70 33,70 33,70
Tightening Ø
mm
7
8
9
10
11
12
13
1561GF
Each 33,70 33,70 33,70 33,70 33,70 33,70 33,70
vuoto
DIN 6499-B/ISO 15488ER/ESXCOLLETSFORCHUCKS,WIDEOPENING
1561GL
25
Product description as Art. 1561GA
Size 25.
Clamping elastic capacity 1mm. Dimensions (mm) D = 26 L = 34.
Tightening Ø
mm
2
2,5
3
3,5
4
5
6
1561GL
Each 44,90 44,90 34,60 57,60 34,60 34,60 34,60
Tightening Ø
mm
7
8
9
10
11
12
13
1561GL
Each 34,60 34,60 34,60 34,60 34,60 34,60 34,60
Tightening Ø
mm
14
15
16
1561GL
Each 34,60 34,60 34,60
vuoto
