AIR RATCHES
503
7
Prices in EURO - VAT not included
1716GA 8
Prod. Pneutec - Art. UT 8000 BG
Product description as Art. 1716GA
Low noise level.
Air outlet on the rear side.
360° rotating air hose connection.
Drive for bushes
inches 3/8
Max torque
Nm 40
For bolts up to
M.
6
Air consumption
l/sec 1,9
No-load speed
rev/min 270
Length
mm 196
Noise level
dB 85
Vibrations
m/s²
< 2,5
Air drive
inches 1/4
Weight
Kg
0,5
1716GA 8
Each 225,00
Operating pressure: Atm 6,3.
vuoto
AIRRATCHES
1716GBA
Prod. Pneutec - Art. UT 5015 D
Professional type.
High performance model for continuous screwing operation.With lever change for clockwise and
counter-clockwise operation. Aluminium housing sheathed in rubber.
With air outlet orientable through a rotating ferrule situated in the middle dof the handle.
Drive for bushes
inches 1/2
Max torque
Nm 80
For bolts up to
M.
6
Air consumption
l/sec 1,9
No-load speed
rev/min 180
Length
mm 285
Noise level
dB 85
Vibrations
m/s²
<2,5
Air drive
inches 1/4
Weight
Kg
1,2
1716GBA
Each 206,00
Operating pressure: Atm 6,3.
vuoto
AIRRATCHES
1716GC
Prod. Pneutec - Art. UT 8015 G
Professional type.
High performance model for continuous screwing operation.With lever change for clockwise and
counter-clockwise operation. Aluminium housing sheathed in rubber. Air outlet adjustable through
rotating ferrule at the back of the handle.
Drive for bushes
inches 1/2
Max torque
Nm 70
For bolts up to
M.
8
Air consumption
l/sec 1,9
No-load speed
rev/min 150
Length
mm 256
Noise level
dB 85
Vibrations
m/s²
2,6
Air drive
inches 1/4
Weight
Kg
1,2
1716GC
Each 281,00
Operating pressure: Atm 6,3.
vuoto
AIRRATCHES
1716GDA
Prod. Pneutec - Art. UT 8014 A
Professional type.
High performance model with a high ratio between dimension, weight and torque value. For
continuous screwing operation. With lever change for clockwise and counter-clockwise operation.
Aluminium housing sheathed in rubber.
Drive for bushes
inches 1/2
Max torque
Nm 95
For bolts up to
M.
10
Air consumption
l/sec
3
No-load speed
rev/min 160
Length
mm 270
Noise level
dB 88
Vibrations
m/s²
8,1
Air drive
inches 1/4
Weight
Kg
1,2
1716GDA
Each 262,00
Operating pressure: Atm 6,3.
vuoto
AIRRATCHES
