AIR DRILLS
505
7
Prices in EURO - VAT not included
1718GC
Prod. Pneutec - Art. UT 8807 C
Angular type.
Particularly suitable for 90° angle drilling. Light alloy manufacture, air discharge in the handle end.
Right/left rotation.
Three-jaw chuck, shank 3/8"x 24 threads (Art. 1512GE 10).
Chuck opening and bores steel
mm 10
Air consumption
l/sec 1,8
No-load speed
rev/min 1800
Overall height with chuck
mm 190
Noise level
dB 85
Vibrations
m/s²
< 2,5
Air drive
inches 1/4
Weight
Kg
1,1
1718GC
Each 262,00
Operating pressure: Atm 6,3.
vuoto
AIRDRILLS
AIR SHEARING MACHINES
1718GD
Prod. Pneutec - Art. UT 8900 B / UT 8901
For removing the material by using punches. For perfect cutting of flat and corrugated steel plate
and very narrow bending radius. High feed speed.
HSS punching knife, for oblique and side cutting.
For cutting steel fine
mm 1,5
Air consumption
l/sec
1,5
Length
mm 185 / 235
Minimum bending radius mm 7
Noise level
dB
85
Vibrations
m/s²
5,3
Air drive
inches 1/4
Weight
Kg
1
1718GD
Each 225,00
Operating pressure Atm 6,3.
When the mod. UT 8900 B will run out of stock, mod. UT 8901 will be supplied.
vuoto
AIRSHEARINGMACHINES
AIR SAWING MACHINES
1718GP
Prod. Pneutec - Art. UT 8922
For steel plate, aluminium, plastic, wood, rubber, etc. Particularly suitable for cutting and profiling
vehicle frames, without deformation. Safety start lever.
Complete with 1 blade.
For cutting sheets with thickness up to mm 1,2
Minimum bending radius
mm 16
No. of excursions per minute
10000
Blade excursions
mm 10
Air consumption
l/sec
6
Noise level
dB 72
Vibrations
m/s²
26
Air drive
inches 1/4
Weight
Kg
1
1718GP
Each 319,00
Operating pressure: Atm 6,3.
vuoto
Spare blades for curved cutting of sheet metal and plastic up to thickness=1mm.
For Art. 1718 GP.
O1718GR
Each 4,72
vuoto
Spare blades for cutting of iron and aluminium thickness=5mm. For Art. 1718 GP.
O1718GS
Each 4,72
vuoto
Spare blades for cutting of wood up to thickness=40mm. For Art. 1718 GP.
O1718GT
Each 4,72
vuoto
Spare blades for cutting of rubber and synthetic materials thickness= 40mm. For Art. 1718 GP.
O1718GV
Each 4,34
Art. O1718GV running out of stock.
