CLAMPING DEVICES
676
9
Prices in EURO - VAT not included
2825A
2825B
2825C
2825E
2825F
2825L
2825P
2825R
2825RA
2825S
2825T
Product description as Art. 2822A
Grooved-type, chamfered - DIN 6315 B.
Art.
2825A 2825B 2825C 2825E 2825F 2825L 2825P
Bolts thread
M.
8
10
12-14 12-14 16-18 16-18 20-22
Groove (C) width
mm 9
11
14
14
18
18
22
Length (L)
mm 80
100
125
160
160
200
200
Thickness (A)
mm 15
20
25
25
30
30
40
Width (B)
mm 25
30
40
40
50
50
50
Each 10,40 11,80 12,40 14,10 17,40 19,50 26,80
Art.
2825R 2825RA 2825S 2825T
Bolts thread
M.
20-22
24
24
24
Groove (C) width
mm 22
26
26
26
Length (L)
mm 250
200
250
315
Thickness (A)
mm 40
40
40
40
Width (B)
mm 60
70
70
70
Each 33,30 29,90 37,10 54,70
vuoto
CLAMPINGDEVICES
2826A
2826B
2826C
2826E
2826L
Product description as Art. 2822A
Grooved-type, with pin.
Art.
2826A 2826B 2826C 2826E 2826L
Bolts thread
M.
8
10
12-14 16-18 20-22
Groove (C) width
mm 9
11
14
18
22
Length (L)
mm 100
125
160
200
250
Thickness (A)
mm 15
20
25
30
40
Width (B)
mm 30
30
40
50
60
Nib (F) width
mm 16
20
25
28
35
Each 16,10 19,50 24,10 33,90 55,90
vuoto
CLAMPINGDEVICES
2827A
2827B
2827D
2827E
Product description as Art. 2822A
Simple construction type with adjusting screw - Similar to DIN 6314.
Art.
2827A 2827B 2827D 2827E
Bolts thread
M.
10
12-14 16-18 20-22
Groove (C) width
mm 11
14
18
22
Length (L)
mm 80
100
125
160
Thickness (A)
mm 15
20
25
30
Width (B)
mm 30
40
50
60
Adjustable height (H)
mm 8-28 10-32 13-40 18-60
Screw diameter
M.
10
12
16
20
Each 21,30 25,30 36,40 55,20
vuoto
CLAMPINGDEVICES
2827GL
2827GP
2827GT
Product description as Art. 2822A
Curved-type, adjustable. Complete with screw for nuts, nut and washer. Suitable to tighten thick
items in restricted areas.
Art.
2827GL 2827GP 2827GT
Length (L)
mm 140
140
175
Width (B)
mm 50
50
60
Height (H) up to
mm 50
75
85
Screw thread
M.
12x125 16x160 20x200
Bore (B1) Ø
mm 17
17
21
Each 90,10 96,80 144,00
vuoto
CLAMPINGDEVICES
2828A
2828B
2828C
2828D
2828E
2828F
Product description as Art. 2822A
Simple construction, toothed extremity.
Art.
2828A 2828B 2828C 2828D 2828E 2828F
Groove (C) width
mm 9
11
14
18
22
26
Length (L)
mm 60
80
100
125
160
200
Thickness (A)
mm 15
15
20
25
30
30
Width (B)
mm 25
30
40
50
60
70
Screw thread
M.
8
10
12-14 16-18 20-22
24
Each 11,80 15,10 17,20 25,10 35,20 50,20
vuoto
CLAMPINGDEVICES
