PERMANENT MAGNETS
673
9
Prices in EURO - VAT not included
2815E
Product description as Art. 2815A
Bridge-shaped type with 1 x through hole (Art. 2815 E 25-28.6) and 2 x through holes
(Art. 2815 E 57-82.5).
Max length
mm
25
28,6
57
82,5
Overall height
mm 25
29
41
54
Max width
mm 40
45
70
80
Magnetic force
Kg
6,5
9
30
50
Bores Ø
mm 5
5,5
7,5
9,5
2815E
Each 27,20 39,90 160,00 288,00
vuoto
PERMANENTMAGNETS
2815F
Product description as Art. 2815A
U-bolt-shaped type.
Height: 25.4mm. Thickness: 8mm.
2815F
Each 10,60
vuoto
PERMANENTMAGNETS
PERMANENT MAGNETS FOR RAISING
2815Z
Prod. SCU
Powerful NEODIMIO magnet. Sturdy and compact lifting device with lifting hook and control lever
for magnet activation/deactivation, with safety lock. Manufactured according to European safety
standards. Suited to lift and handle cast iron, iron, steel flat and round parts, plates, bars, pipes,
etc.
Plate max load capacity
Kg
300
600
1000 2000
Plate min. thickness
mm 20
30
40
55
Round bar max load capacity Kg 100
200
330
1000
Round bar min. Ø
mm 50
70
75
100
Round bar max Ø
mm 300
400
450
600
Weight
Kg
7
17
38
95
Dimensions B
mm 92
129
156
210
Dimensions H
mm 163
198
277
333
Dimensions H1
mm 85
100
129
167
Dimensions L1
mm 160
231
312
443
Dimensions L
mm 189
267
350
490
Dimensions R
mm 180
200
280
380
Hook bore Ø dimensions
mm 40
55
57
68
2815Z
Each 482,00 761,00 1.230,00 2.370,00
Lifting capacity: 3000kg and 5000kg available on request. To choose the right lifting capacity, see
thickness, surface finish tables and air gap. (table section)
vuoto
PERMANENTMAGNETSFORRAISING
MAGNETIC BLOCKS
2816A
Prod. SCU
Heat resistance: 450°C
In ALNICO alloy, completely magnetised.
Cylindric-type
Ø
mm
6
8
10
Height
mm 20
25
30
2816A
Each 2,32
3,52
5,26
vuoto
MAGNETICBLOCKS
2816B
Product description as Art. 2816A
Rectangular-type
Width x thickness
mm
10x5 12,5x5 15x5 15x10
Height
mm 20
40
60
75
2816B
Each 3,52
7,02 10,60 19,20
vuoto
MAGNETICBLOCKS
PERMANENT CERAMIC MAGNETS
2817A
Prod. SCU
In ceramic material with metal coating.
Cylindric-type with fixing hole.
Ø
mm
45
53
71
Thickness
mm 10
10
15
Bore Ø
mm 4
4
10
Magnetic force
Kg
7
15
30
2817A
Each 10,40 13,60 16,10
