LONG DRILLS FOR BRASS, BRONZE AND NON-FERROUS ALLOYS, RIGHT-HAND ROTATION
1128
13
Prices in EURO - VAT not included
LONG DRILLS FOR BRASS, BRONZE AND NON-FERROUS ALLOYS, RIGHT-HAND ROTATION
8481G
HSS
Orig. Hartner - Art. 81320-118°
DIN 340. Type H. HSS. Cutting angle 118°. LONG pattern.
For brass, bronze, short-chip non-ferrous alloys.
Cylindrical shank.
Ø
mm
1
1,2 1,3 1,4 1,6 1,7*
1,8 1,9
2
2,2 2,3 2,4*
2,5 2,6 2,7
Overall length
mm 56
65
65
70
76
76
80
80
85
90
90
95
95
95 100
Helix length
mm 33
41
41
45
50
50
53
53
56
59
59
62
62
62
66
8481G
Each 12,20 12,40 12,50 12,30 10,90 8,30 11,50 9,90 8,18 10,30 9,42 7,68 8,56 11,10 9,52
Ø
mm
2,8 2,9
3
3,1 3,2 3,3*
3,4*
3,5 3,6 3,7*
3,9*
4
4,1 4,2 4,4*
Overall length
mm 100 100 100 106 106 106 112 112 112 112 119 119 119 119 126
Helix length
mm 66
66
66
69
69
69
73
73
73
73
78
78
78
78
82
8481G
Each 9,52 9,72 8,66 12,20 10,70 11,80 11,20 10,10 20,70 5,08 21,70 10,40 21,20 12,90 11,20
Ø
mm
4,5 4,6 4,7 4,8*
5
5,3*
5,4*
5,5 5,7*
5,8*
5,9
6
6,1*
6,2 6,3*
Overall length
mm 126 126 126 132 132 132 139 139 139 139 139 139 148 148 148
Helix length
mm 82
82
82
87
87
87
91
91
91
91
91
91
97
97
97
8481G
Each 13,20 19,80 24,60 19,60 13,90 38,10 35,10 16,20 36,60 44,80 40,90 17,30 38,90 43,80 35,90
Ø
mm
6,5*
6,6*
6,7*
6,8 6,9*
7
7,2*
7,3*
7,5 7,8*
8
8,2*
8,3*
8,4*
9*
Overall length
mm 148 148 148 156 156 156 156 156 156 165 165 165 165 165 175
Helix length
mm 97
97
97 102 102 102 102 102 102 109 109 109 109 109 115
8481G
Each 24,60 36,40 52,90 50,00 48,20 26,50 39,50 36,40 46,20 41,10 27,90 41,50 31,80 43,00 26,70
Ø
mm
9,5 10*
10,5*
11*
11,5* 12,5*
Overall length
mm 175 184 184 195 195 205
Helix length
mm 115 121 121 128 128 134
8481G
Each 55,80 34,90 43,00 44,90 45,10 49,30
Up to Ø 6.7mm in 10pcs packing units. - * Sizes running out of stock.
vuoto
LONGDRILLSFORBRASS,BRONZEANDNON-FERROUSALLOYS,RIGHT-HANDROTATION
DRILLS FOR ALUMINIUM AND COPPER, RIGHT-HAND ROTATION
8481GE
HSS
Orig. Hartner - Art. 81330
DIN 340. Type W. HSS. Cutting angle 130°. LONG pattern.
For aluminium, copper and relevant alloys.
Cylindrical shank.
Ø
mm
2
2,5
3
3,2
3,5
4
4,5
Overall length
mm 85
95
100
106
112
119
126
Helix length
mm 56
62
66
69
73
78
82
8481GE
Each 7,60
8,46
9,04 12,10 10,20 10,90 13,20
Ø
mm
5
5,5
6
6,5
7
7,5
8
Overall length
mm 132
139
139
148
156
156
165
Helix length
mm 87
91
91
97
102
102
109
8481GE
Each 12,40 16,20 17,50 22,60 24,60 34,70 25,50
Ø
mm
8,5
9
9,5*
10
11*
12*
13*
Overall length
mm 165
175
175
184
195
205
205
Helix length
mm 109
115
115
121
128
134
134
8481GE
Each 37,10 36,10 37,90 41,90 67,30 79,90 80,90
Up to Ø 6.5mm in 10pcs packing units. * Sizes running out of stock.
vuoto
DRILLSFORALUMINIUMANDCOPPER,RIGHT-HANDROTATION
LONG DRILLS FOR METALS, RIGHT-HAND ROTATION
8482G
HSS
Orig. Hartner - Art. 81340
DIN 340. Type FN. HSS. Cutting angle 130°. LONG pattern.
Thinned cutting edge according to DIN 1412 A.
For steel up to R 1000 N/sqmm, cast iron, aluminium and aluminium alloys.
Cylindrical shank.
Ø
mm
1
1,1*
1,2 1,3 1,4 1,5 1,6*
1,7 1,8 1,9
2
2,1 2,2*
2,3 2,4
Overall length
mm 56
60
65
65
70
70
76
76
80
80
85
85
90
90
95
Helix length
mm 33
37
41
41
45
45
50
50
53
53
56
56
59
59
62
8482G
Each 13,10 14,30 13,20 13,60 12,60 10,80 9,70 10,20 10,20 10,10 9,48 10,80 11,10 11,20 11,40
Ø
mm
2,5 2,6 2,7 2,8 2,9
3
3,1 3,2 3,3 3,4 3,5 3,6 3,7 3,8 3,9
Overall length
mm 95
95 100 100 100 100 106 106 106 112 112 112 112 119 119
Helix length
mm 62
62
66
66
66
66
69
69
69
73
73
73
73
78
78
8482G
Each 9,92 11,40 11,70 11,70 11,80 10,10 13,50 11,40 13,10 13,50 11,70 14,80 14,40 14,30 14,60
Ø
mm
4
4,1 4,2 4,3 4,4 4,5 4,6*
4,7*
4,8 4,9*
5
5,1 5,2 5,4 5,5
Overall length
mm 119 119 119 126 126 126 126 126 132 132 132 132 132 139 139
Helix length
mm 78
78
78
82
82
82
82
82
87
87
87
87
87
91
91
8482G
Each 12,60 15,60 14,30 15,80 17,30 14,60 19,60 16,60 17,30 17,80 15,40 18,50 19,40 20,10 18,20
Ø
mm
5,6 5,7 5,8 5,9
6
6,1*
6,2 6,3 6,5 6,6*
6,7*
6,8 6,9
7
7,1*
Overall length
mm 139 139 139 139 139 148 148 148 148 148 148 156 156 156 156
Helix length
mm 91
91
91
91
91
97
97
97
97
97
97 102 102 102 102
8482G
Each 22,60 22,60 23,70 24,80 18,60 21,60 26,50 27,70 20,90 27,20 31,60 31,60 32,20 24,30 38,40
SEGUE >>>
