TUNGSTEN CARBIDE SOLID END MILLS WITH FIRE COATING
1176
13
Prices in EURO - VAT not included
8799D
new
HARTMETALL
FIRE
Orig. Hartner - Art. 84902
Product description as Art. 8799C
Long series DIN 6527 L. Type N with 4 helical cutting edges to 35°/38°. Cutting right. Front tooth
in the middle.
Cylindrical shank DIN 6535 HB.
Ø
mm
4
5
6
8
10 12 16 20 25
Overall length
mm 57 57 57 63 72 83 92 104 121
Cutting edge length
mm 11 13 13 19 22 26 32 38 45
Drive Ø
mm 6
6
6
8
10 12 16 20 25
8799D
Each 35,60 35,60 43,40 60,10 88,40 113,00 198,00 300,00 477,00
vuoto
TUNGSTENCARBIDESOLIDENDMILLSWITHFIRECOATING
8799EA
new
HARTMETALL
FIRE
Orig. Hartner - Art. 84911
New program of milling cutters with special FIRE coating for maximum protection of the tool to
cracking, maximum resistance to heat and humidity, which increase the life and performance.
Micro-grain carbide type DK 460 UF high plasticity for a greater flexibility in processing and
therefore less chance of breakage.
Very fine surface finish and dimensional precision.
Long series DIN 6527 L. Type N with 2 helical cutting edges to 30°. Cutting right. Front tooth in the
middle.
Cylindrical shank DIN 6535 HA. Universal use for quarries, grooves, slots, etc. in materials with
strength up to 1400 N/mm².
Ø
mm
2
3
4
5
6
8
10
12
Overall length
mm 57
57
57
57
57
63
72
83
Cutting edge length
mm 6
7
8
10
10
16
19
22
Drive Ø
mm 6
6
6
6
6
8
10
12
8799EA
Each 30,10 30,10 28,50 28,50 26,70 37,10 54,50 79,10
vuoto
TUNGSTENCARBIDESOLIDENDMILLSWITHFIRECOATING
8799EF
new
HARTMETALL
FIRE
Orig. Hartner - Art. 84917
Product description as Art. 8799EA
Long series DIN 6527 L. Type N with 2 helical cutting edges to 30°. Cutting right.
Cylindrical shank DIN 6535 HA. Universal use for quarries, grooves, slots, etc. in materials with
strength up to 1400 N/mm².
Ø
mm
2
3
4
5
6
8
10 12 20
Overall length
mm 57 57 57 57 57 63 72 83 104
Cutting edge length
mm 6
7
8
10 10 16 19 22 32
Drive Ø
mm 6
6
6
6
6
8
10 12 20
8799EF
Each 31,60 31,60 31,60 31,60 31,60 40,30 52,10 72,60 185,00
vuoto
TUNGSTENCARBIDESOLIDENDMILLSWITHFIRECOATING
8799EH
new
HARTMETALL
FIRE
Orig. Hartner - Art. 84903
Product description as Art. 8799EA
Long series DIN 6527 L. Type NH with 3 helical cutting edges to 45°. Cutting right. Front tooth in
the middle.
Cylindrical shank DIN 6535 HA. Universal use for quarries, grooves, slots, etc. in materials with
strength up to 1400 N/mm².
Ø
mm
3
4
5
6
8
10
12
Overall length
mm 57
57
57
57
63
72
83
Cutting edge length
mm 7
8
10
10
16
19
22
Drive Ø
mm 6
6
6
6
8
10
12
8799EH
Each 29,20 29,20 29,20 29,20 37,90 56,10 86,80
Ø
mm
14
16
20
Overall length
mm 83
92
104
Cutting edge length
mm 22
26
32
Drive Ø
mm 12
16
20
8799EH
Each 108,00 146,00 237,00
vuoto
TUNGSTENCARBIDESOLIDENDMILLSWITHFIRECOATING
8799EL
new
HARTMETALL
FIRE
Orig. Hartner - Art. 84915
Product description as Art. 8799EA
Long series DIN 6527 L. Type NH with 4 helical cutting edges to 30°. Cutting right. Front tooth in
the middle.
Cylindrical shank DIN 6535 HB. Universal use for quarries, grooves, slots, etc. in materials with
strength up to 1400 N/mm².
Ø
mm
2
3
4
5
6
8
10
Overall length
mm 57
57
57
57
57
63
72
Cutting edge length
mm 7
8
11
13
13
19
22
Drive Ø
mm 6
6
6
6
6
8
10
8799EL
Each 36,30 36,30 35,60 35,60 39,50 46,60 73,40
Ø
mm
12
14
16
18
20
Overall length
mm 83
83
92
92
104
Cutting edge length
mm 26
26
32
32
38
Drive Ø
mm 12
14
16
18
20
8799EL
Each 99,50 128,00 169,00 215,00 267,00
