SOLID CARBIDE END MILLS
1174
13
Prices in EURO - VAT not included
8797
HARTMETALL
Short series. Micrograin solid carbide.
30° four flutes. Right cutting.
Two central frontal teeth. Cylindrical shank. For cutting out and finishing.
Ø
mm
2
2,5
3
3,5
4
4,5
5
Overall length
mm 40
40
40
40
50
50
50
Cutting edge length
mm 5
7
12
12
16
16
20
Drive Ø
mm 3
3
3
3,5
4
4,5
5
8797
Each 14,60 13,10 11,40 13,10 15,20 16,30 16,30
Ø
mm
5,5
6
7
8
9
9,5
10
Overall length
mm 50
50
60
60
70
70
70
Cutting edge length
mm 20
20
22
22
22
22
25
Drive Ø
mm 5,5
6
7
8
9
9,5
10
8797
Each 19,40 20,20 27,70 31,10 43,20 49,10 47,70
Ø
mm
12
13
14
15
16
18
20
Overall length
mm 75
75
85
85
85
100
100
Cutting edge length
mm 27
27
30
30
30
40
40
Drive Ø
mm 12
13
14
15
16
18
20
8797
Each 69,20 76,10 93,30 124,00 134,00 180,00 225,00
Size mm 9,5 running out of stock.
vuoto
SOLIDCARBIDEENDMILLS
8797L
HARTMETALL
Long series. Micrograin solid carbide.
30° four flutes.Right cutting.
Two central frontal teeth. Cylindrical shank. For cutting out and finishing.
Ø
mm
3
4
5
6
8
10
12
Overall length
mm 60
60
70
100
100
100
100
Cutting edge length
mm 30
30
35
40
40
45
45
Drive Ø
mm 3
4
5
6
8
10
12
8797L
Each 15,80 19,10 26,10 36,70 53,60 76,10 101,00
Ø
mm
14
16
18
20
Overall length
mm 100
100
150
150
Cutting edge length
mm 45
45
50
55
Drive Ø
mm 14
16
18
20
8797L
Each 128,00 163,00 287,00 339,00
vuoto
SOLIDCARBIDEENDMILLS
8797R
HARTMETALL
Short series. Micrograin solid carbide.
30° four flutes.Right-hand cutting. Round head.
Cylindrical shank. For slots, splines, etc. For cutting out and finishing.
Ø
mm
2
3
4
5
6
8
10
Overall length
mm 40
40
50
50
50
60
70
Cutting edge length
mm 5
12
16
20
20
22
25
Drive Ø
mm 3
3
4
5
6
8
10
8797R
Each 17,50 13,60 17,70 19,30 23,90 36,70 56,60
Ø
mm
12
14
16
18
20
Overall length
mm 75
85
85
100
100
Cutting edge length
mm 27
30
30
40
40
Drive Ø
mm 12
14
16
18
20
8797R
Each 84,10 110,00 159,00 217,00 273,00
vuoto
SOLIDCARBIDEENDMILLS
8797T
HARTMETALL
Micrograin solid carbide.
Three 60° flutes. Right-hand cutting. Central tang drive.
Cylindrical shank. For cutting out and finishing.
Ø
mm
6
8
10
12
14
16
18
20
Overall length
mm 50
60
70
75
85
85
100 100
Cutting edge length
mm 16
20
22
27
27
30
38
38
Drive Ø
mm 6
8
10
12
14
16
18
20
8797T
Each 20,20 31,10 48,10 69,20 93,30 134,00 184,00 232,00
vuoto
SOLIDCARBIDEENDMILLS
8798
HARTMETALL
High-performance. Hard micrograin solid carbide.
For ROUGHING, 45° three flutes. Right-hand cutting. Central tang drive.
Cylindrical shank.
Ø
mm
6
8
10
12
16
20
Overall length
mm 50
60
70
75
85
100
Cutting edge length
mm 16
20
22
27
30
38
Drive Ø
mm 6
8
10
12
16
20
8798
Each 34,50 53,10 74,80 99,20 201,00 270,00
vuoto
