HAND TAPS
1219
13
Prices in EURO - VAT not included
9135G
9137G
BSP
HSSG
Orig. Völkel - Art. 253 - Art. 253-2
Product description as Art. 9100G
RIGHT-HAND USE.
CYLINDRICAL GAS THREAD G (BSP) according to DIN ISO 228 -1- (DIN 5157).
2pcs set.
Ø
inches
1/8
1/4
3/8
1/2
5/8
3/4
7/8
Threads per inch
No
28
19
19
14
14
14
14
Ø
mm 9,73 13,16 16,66 20,96 22,91 26,44 30,20
Overall length
mm 63
70
70
80
80
90
90
Thread length
mm 20
22
22
22
22
22
22
Shank Ø
mm 7
11
12
16
18
20
22
Shank square
mm 5,5
9
9
12
14,5
16
18
9135G
Per set 14,60 16,10 23,80 32,80 47,90 47,90 81,30
9137G
Per tap 7,26
7,98 11,90 16,40 24,10 24,10 40,70
Ø
inches
1
1.1/8 1.1/4 1.3/8 1.1/2 1.3/4
2
Threads per inch
No
11
11
11
11
11
11
11
Ø
mm 33,25 37,90 41,91 44,32 47,80 53,75 59,61
Overall length
mm 100
125
125
140
140
140
160
Thread length
mm 25
40
40
40
40
40
40
Shank Ø
mm 25
28
32
36
36
40
45
Shank square
mm 20
22
24
29
29
32
35
9135G
Per set 81,30 141,00 141,00 192,00 192,00 384,00 384,00
9137G
Per tap 40,70 70,40 70,40 95,80 95,80 192,00 192,00
vuoto
vuoto
HANDTAPS
MACHINE AND HAND TAPS
9140G
NPT
HSSG
Orig. Völkel - Art. 635
HSSG taps.
Ground and polished after hardening.
RIGHT-HAND USE.
NPT AMERICAN THREAD. Conicity: 1:16. Short chamfer.
Ø
inches
1/8 1/4 3/8 1/2 3/4
1 1.1/4 1.1/2 2
Threads per inch
No 27 18 18 14 14 11,1/2 11,1/2 11,1/2 11,1/2
Overall length
mm 65 70 75 80 100 110 125 140 160
Thread length
mm 19 25 26 31 33 38 41 42 44
Shank Ø
mm 7
11 12 16 20 25 32 36 36
Shank square
mm 5,5
9
9
12 16 20 24 29 29
9140G
Each 17,60 19,50 26,90 33,60 44,30 70,40 106,00 199,00 244,00
vuoto
MACHINEANDHAND TAPS
9141G
BSPT
HSSG
Orig. Völkel - Art. 637 - Art. 975
Product description as Art. 9140G
RIGHT HAND USE
GAS THREAD-TAPERED BSPT. Taper: 1:16, 55°. Short chamfer.
Ø
inches
1/8
1/4
3/8
1/2
3/4
1
1.1/4
Threads per inch
No
28
19
19
14
14
11
11
Overall length
mm 65
70
75
80
100
110
105
Thread length
mm 19
25
26
31
33
38
45
Shank Ø
mm 7
11
12
16
20
25
32
Shank square
mm 5,5
9
9
12
16
20
26
9141G
Each 10,50 12,10 19,20 24,10 35,20 53,10 106,00
The measure 1.1/4 has the right chamfer.
vuoto
MACHINEANDHAND TAPS
9142G
PG
HSSG
Orig. Völkel - Art. 657
Product description as Art. 9140G
RIGHT HAND USE
PG THREAD DIN 40430 compliant.
Ø
PG
7
9
11
13,5
16
21
29
Threads per inch
No
20
18
18
18
18
16
16
Overall length
mm 70
70
80
80
80
90
100
Thread length
mm 22
22
22
22
22
22
25
Shank Ø
mm 9
12
14
16
18
22
28
Shank square
mm 7
9
11
12
14,5
18
22
9142G
Each 14,10 18,60 30,50 36,30 43,60 59,60 98,70
vuoto
MACHINEANDHAND TAPS
