HAND TAPS
1218
13
Prices in EURO - VAT not included
9125G
9127G
UNC
HSSG
Orig. Völkel - Art. 233 - Art. 233-3
Product description as Art. 9100G
RIGHT-HAND USE.
UNC AMERICAN THREAD according to ANSI-B.1.1 – Tolerance 2 B- (DIN 352).
3pcs set.
Thread UNC
No. 1 No. 2 No. 3 No. 4 No. 5 No. 6 No. 8
Threads per inch
No
64
56
48
40
40
32
32
Ø
mm 1,85
2,18
2,52
2,85
3,18
3,5
4,17
Overall length
mm 32
36
36
40
40
45
45
Thread length
mm 10
11
11
12
12
14
14
Shank Ø
mm 2,5
2,8
2,8
3,5
3,5
4
4,5
Shank square
mm 2,1
2,1
2,1
2,7
2,7
3
3,4
9125G
Per set 52,70 52,70 52,70 31,80 31,80 31,80 31,80
9127G
Per tap 17,60 17,60 17,60 10,60 10,60 10,60 10,60
Thread UNC
No. 10 No. 12 1/4
5/16
3/8
7/16
1/2
Threads per inch
No
24
24
20
18
16
14
13
Ø
mm 4,83
5,49
6,35
7,94
9,52 11,11 12,7
Overall length
mm 50
50
50
56
70
70
75
Thread length
mm 16
18
19
22
24
24
29
Shank Ø
mm 6
6
6
6
7
8
9
Shank square
mm 4,9
4,9
4,9
4,9
5,5
6,2
7
9125G
Per set 31,80 31,80 17,10 18,80 21,40 26,60 31,80
9127G
Per tap 10,60 10,60 5,66
6,24
7,12
8,86 10,60
Thread UNC
9/16
5/8
3/4
7/8
1
Threads per inch
No
12
11
10
9
8
Ø
mm 14,29 15,87 19,05 22,23 25,4
Overall length
mm 80
80
95
100
110
Thread length
mm 30
32
40
40
50
Shank Ø
mm 11
12
14
18
18
Shank square
mm 9
9
11
14,5
14,5
9125G
Per set 41,40 47,10 62,30 84,10 95,80
9127G
Per tap 13,80 15,70 20,80 28,10 32,10
vuoto
vuoto
HANDTAPS
9130G
9132G
UNF
HSSG
Orig. Völkel - Art. 243 - Art. 243-3
Product description as Art. 9100G
RIGHT-HAND USE.
UNF AMERICAN THREAD according to ANSI-B 1.1 – Tolerance 2 B – (DIN 2181).
2pcs set.
Thread UNF
No. 1 No. 2 No. 3 No. 4 No. 5 No. 6 No. 8
Threads per inch
No
72
64
56
48
44
40
36
Ø
mm 1,85
2,18
2,52
2,85
3,18
3,5
4,17
Overall length
mm 32
32
32
36
36
40
40
Thread length
mm 9
10
10
11
11
12
12
Shank Ø
mm 2,8
2,8
2,8
3,5
3,5
4,5
4,5
Shank square
mm 2,1
2,1
2,1
2,7
2,7
3,4
3,4
9130G
Per set 35,20 35,20 35,20 21,20 21,20 21,20 21,20
9132G
Per tap 17,60 17,60 17,60 10,60 10,60 10,60 10,60
Thread UNF
No. 10 No. 12 1/4
5/16
3/8
7/16
1/2
Threads per inch
No
32
28
28
24
24
20
20
Ø
mm 4,83
5,49
6,35
7,94
9,52 11,11 12,7
Overall length
mm 45
50
50
56
63
63
75
Thread length
mm 14
14
18
22
22
22
22
Shank Ø
mm 6
6
6
6
7
8
9
Shank square
mm 4,9
4,9
4,9
4,9
5,5
6,2
7
9130G
Per set 21,20 21,20 11,40 12,50 14,30 17,80 21,20
9132G
Per tap 10,60 10,60 5,66
6,24
7,12
8,86 10,60
Thread UNF
9/16
5/8
3/4
7/8
1
Threads per inch
No
18
18
16
14
12
Ø
mm 14,29 15,87 19,05 22,23 25,4
Overall length
mm 80
80
95
100
110
Thread length
mm 28
28
32
36
40
Shank Ø
mm 11
12
14
18
18
Shank square
mm 9
9
11
14,5
14,5
9130G
Per set 27,60 31,40 41,60 56,10 63,90
9132G
Per tap 13,80 15,70 20,80 28,10 32,10
vuoto
vuoto
