1228 / 1378
1228
MACHINE TAP WITH COLOURED RINGS
1228
13
Prices in EURO - VAT not included
9272GT
INOX
M
HSS-E
Orig. Völkel - Art. 364
Product description as Art. 9272GR
Reinforced shank (12mm, reduced shank), with 39° spiral flute for deep blind holes.
Thread: Coarse Metric M - DIN 13 (DIN 371/376).
Right-hand use.
For all kinds of stainless steel and long chip steel with R up to 1000 N/mm².
Ø
mm
3
4
5
6
8
10
12
Pitch
mm 0,5
0,7
0,8
1
1,25
1,5
1,75
Overall length
mm 56
63
70
80
90
100
110
Thread length
mm 6
7
8
10
14
16
18
Shank Ø
mm 3,5
4,5
6
6
8
10
9
Shank square
mm 2,7
3,4
4,9
4,9
6,2
8
7
9272GT
Each 15,90 15,90 17,20 17,20 19,60 23,80 28,80
Ø
mm
14
16
18
20
Pitch
mm 2
2
2,5
2,5
Overall length
mm 110
110
125
140
Thread length
mm 20
22
25
25
Shank Ø
mm 11
12
14
16
Shank square
mm 9
9
11
12
9272GT
Each 37,80 42,90 58,80 82,30
vuoto
MACHINETAPWITHCOLOUREDRINGS
9273GA
M
HSS-E
Orig. Völkel - Art. 361
Collar RED.
Stainless SUPER-FAST class HSS-E, especially treated for superior performance.
Ground and polished after hardening.
Reinforced shank, short chamber for blind and through holes.
Thread: Coarse metric thread M - DIN 13 (DIN 371).
Right-hand use.
For high-resistance steel with R above 1200 N/mm² and plastics.
Ø
mm
4
5
6
8
10
Pitch
mm 0,7
0,8
1
1,25
1,5
Overall length
mm 63
70
80
90
100
Thread length
mm 9
11
13
15
16
Shank Ø
mm 4,5
6
6
8
10
Shank square
mm 3,4
4,9
4,9
6,2
8
9273GA
Each 15,40
17,20
17,20
18,90
22,30
vuoto
MACHINETAPWITHCOLOUREDRINGS
9273GE
HSS-E-V3
M
Prod. SCU
RED ring.
COBALT HSS-E-V3 sintered with Vanadium powder.
Ground and polished after hardening.
Reinforced shank (from 12mm, reduced shank), with right-hand 15° spiral flute for blind holes.
M Coarse metric thread – DIN 13 (DIN 371/376).
Right-hand use.
For high-resistance steel with R up to 1500 N/sqmm, Titanium and titanium alloys.
Ø
mm
3
14
Pitch
mm 0,5
2
Overall length
mm 56
110
Thread length
mm 11
30
Shank Ø
mm 3,5
11
Shank square
mm 2,7
9
9273GE
Each 13,80
30,10
Product running out of stock.
vuoto
MACHINETAPWITHCOLOUREDRINGS
9273GL
M
HSS-E
Orig. Völkel - Art. 351
BLACK ring.
HSS-E.
Ground and polished after hardening.
Reinforced shank, straight spiral, short chamfer for through and blind holes.
Nitrided surface.
M Coarse metric thread - DIN 13 (DIN 371/376). Right-hand use.
For cast iron, brass, bronze, plastic materials.
Ø
mm
3
4
5
6
8
10
Pitch
mm 0,5
0,7
0,8
1
1,25
1,5
Overall length
mm 56
63
70
80
90
100
Thread length
mm 11
13
16
19
22
24
Shank Ø
mm 3,5
4,5
6
6
8
10
Shank square
mm 2,7
3,4
4,9
4,9
6,2
8
9273GL
Each 13,70 13,70 14,70 14,70 16,90 20,40
vuoto
MACHINETAPWITHCOLOUREDRINGS
