HIGH QUALITY PINCERS HOLDER CHUCKS, HIGH SPEED
456
6
Prices in EURO - VAT not included
1560GRA
TIGHTENING WRENCHES FOR CHUCK LOCKING COLLARS
Roller type with steel handle and rubber grip. Suitable to tighten/untighten any chuck locking
collars provided with holes, nuts or smooth. It combines safety operation and quick and precise
performances.
Locking ring nuts Ø
mm
40
50
Overall length
mm 400
480
ER clamps
Gr.
25
32
1560GRA
Each 124,00 124,00
vuoto
HIGHQUALITYPINCERSHOLDERCHUCKS,HIGHSPEED
1560GRE
14x18
Product description as Art. 1560GRA
Suitable for female drive torque wrenches 14x18mm (Art. 803 G 200 - 805 GH 200/300/400 - 805
GR) for controlled tightening.
Locking ring nuts Ø
mm
40
50
Male drive
mm 14x18 14x18
ER clamps
Gr.
25
32
1560GRE
Each 124,00 124,00
vuoto
HIGHQUALITYPINCERSHOLDERCHUCKS,HIGHSPEED
DIN 6499-B/ISO 15488 ER/ESX COLLETS FOR CHUCKS, WIDE OPENING
1560GS
16
Prod. SCU
Made of steel, manufactured to a rotation precision of up to 10 µm. Particularly suitable for work
that does not require high precision and long-lasting tools, but cost saving. With elastic clamping
capacity of 1mm.
Size 16.
Dimensions (mm): D = 17 L = 27,5.
Tightening Ø
mm
3
4
5
6
7
8
9
1560GS
Each 21,30 21,30 21,30 21,30 21,30 21,30 21,30
Tightening Ø
mm
10
1560GS
Each 21,30
vuoto
DIN6499-B/ISO 15488ER/ESXCOLLETSFORCHUCKS,WIDEOPENING
1560GT
20
Product description as Art. 1560GS
Size 20.
Dimensions (mm): D = 21 L = 31,5.
Tightening Ø
mm
3
4
5
6
7
8
9
1560GT
Each 22,10 22,10 22,10 22,10 22,10 22,10 22,10
Tightening Ø
mm
10
11
12
13
1560GT
Each 22,10 22,10 22,10 22,10
vuoto
DIN6499-B/ISO 15488ER/ESXCOLLETSFORCHUCKS,WIDEOPENING
1560GV
25
Product description as Art. 1560GS
Size 25.
Dimensions (mm): D = 26 L = 34.
Tightening Ø
mm
3
4
5
6
7
8
9
1560GV
Each 22,10 22,10 22,10 22,10 22,10 22,10 22,10
Tightening Ø
mm
10
11
12
13
14
15
16
1560GV
Each 22,10 22,10 22,10 22,10 22,10 22,10 22,10
vuoto
DIN6499-B/ISO 15488ER/ESXCOLLETSFORCHUCKS,WIDEOPENING
1560GZ
32
Product description as Art. 1560GS
Size 32.
Dimensions (mm): D = 33 L = 40.
Tightening Ø
mm
3
4
5
6
7
8
9
1560GZ
Each 22,10 22,10 22,10 22,10 22,10 22,10 22,10
Tightening Ø
mm
10
11
12
13
14
15
16
1560GZ
Each 22,10 22,10 22,10 22,10 22,10 22,10 22,10
Tightening Ø
mm
17
18
19
20
1560GZ
Each 22,10 22,10 22,10 22,10
vuoto
DIN6499-B/ISO 15488ER/ESXCOLLETSFORCHUCKS,WIDEOPENING
