CLAMPING DEVICES
680
9
Prices in EURO - VAT not included
2830E
Rods for Art. 2830 A (except 50mm) and 2830 B.
Shape
convex
Support (B) Ø
mm
37
Height (A-C)
mm 18-8
2830E
Each
16,80
vuoto
CLAMPINGDEVICES
2830L
Product description as Art. 2830E
Shape
prismatic
Support (B) Ø
mm
32
Height (A-C)
mm 23-8
2830L
Each
26,80
vuoto
CLAMPINGDEVICES
2830M
Product description as Art. 2830E
Shape
prismatic
Support (B) Ø
mm
56
Height (A-C)
mm 38-8
2830M
Each
36,80
vuoto
CLAMPINGDEVICES
CLAMPING DEVICES
2831GA
Prod. SCU
Secure and consistently high quality clamping devices. Double lever function, which does not
allow any uncoupling during sealing. Galvanised steel with vinyl handle and stainless steel rivets.
Comes complete with threaded hexagonal steel tip. Max. force expressed in daN.
Vertical type, flat base.
Max. force
daN
70
150
200
350
500
700
Threaded screw Ø
M 5
6
8
10
10
12
Hexagonal tip dimensions mm 8
10
13
16
16
18
Weight
grams 100
210
315
740
1180 1650
2831GA
Each 19,40 21,10 29,20 35,20 45,90 48,30
