LONG CENTRE DRILLS
1140
13
Prices in EURO - VAT not included
LONG CENTRE DRILLS
8602G
HSS
Orig. Hartner - Art. 83110
DIN 333. Form A. Cutting angle 118°.
HSS
For drilling metals and steel. Right-hand cutting.
60° countersink taper. Total length 120mm.
Tip Ø
mm
1
1,6
2
2,5
3,15
Body Ø
mm 4
5
6
8
10
8602G
Each 23,20 22,70 21,20 25,30 49,10
vuoto
LONGCENTREDRILLS
REINFORCED CENTRE DRILLS
8603G
HSS
Orig. Hartner - Art. 83200
DIN 333. Form A. Reinforced type. Cutting angle 118°.
HSS. For drilling metals and steel. Right-hand cutting.
With protective chamfer.
60°/120° countersink taper.
Two working processes with one single operation.
Tip Ø
mm
1,6
2
2,5
3,15
4
5
6,3
Body Ø
mm 6,3
8
10
11,2
14
18
20
Overall length
mm 45
50
56
60
67
75
80
8603G
Each 14,80 16,30 19,80 28,90 36,60 46,40 74,30
vuoto
REINFORCEDCENTREDRILLS
CENTRE DRILLS
8606G
HSS
Orig. Hartner - Art. 83000
DIN 333. Form R. Radius type. Cutting angle 118°.
HSS.
For drilling metal and steel. Right-hand cutting.
For creating arc countersinks, with progressive taper up to 60°.
Tip Ø
mm
1
1,25
1,6
2
2,5
3,15
4
Body Ø
mm 3,15
3,15
4
5
6,3
8
10
Overall length
mm 31,5
31,5
35,5
40
45
50
56
8606G
Each 9,08 10,40 8,66
8,76 10,50 14,10 19,40
Tip Ø
mm
5
6,3
Body Ø
mm 12,5
16
Overall length
mm 63
71
8606G
Each 29,40 43,80
vuoto
CENTREDRILLS
CENTRE DRILLS WITH FLATTED BODY
8608G
HSS
Orig. Hartner - Art. 83600
DIN 333. Form A. Cutting angle 118°.
With flatted body. HSS
For drilling metals and steel. Right-hand cutting.
60° countersink taper.
Tip Ø
mm
1,6
2
2,5
3,15
4
5
6,3
Body Ø
mm 4
5
6,3
8
10
12,5
16
Overall length
mm 35,5
40
45
50
56
63
71
8608G
Each 14,80 12,20 14,20 18,10 25,30 38,70 68,10
vuoto
CENTREDRILLSWITH FLATTEDBODY
8609G
HSS
Orig. Hartner - Art. 83700
DIN 333. Form B. Reinforced type. Cutting angle 118°.
With flatted body. HSS.
For drilling metal and steel. Right-hand cutting.
With protective chamfer. 60°/120° countersink taper.
Two working processes with one single operation.
Tip Ø
mm
1,6
2
2,5
3,15
4
Body Ø
mm 6,3
8
10
11,2
14
Overall length
mm 45
50
56
60
67
8609G
Each 19,80 22,70 27,40 39,20 46,40
Size mm 1,6 running out of stock.
vuoto
CENTREDRILLSWITH FLATTEDBODY
8610G
HSS
Orig. Hartner - Art. 83500
DIN 333. Form R. Radius type. Cutting angle 118°.
With flatted body. HSS.
For drilling metal and steel. Right-hand cutting.
For creating arch countersinks, with progressive taper up to 60°.
Tip Ø
mm
1,6
2
2,5
3,15
4
5
6,3
Body Ø
mm 4
5
6,3
8
10
12,5
16
Overall length
mm 35,5
40
45
50
56
63
71
8610G
Each 13,10 12,20 13,30 18,10 25,30 37,10 65,10
