1141 / 1378
1141
TANGED STRAIGHT SHANK SPOTTING DRILLS, RIGHT HAND CUTTING
1141
13
Prices in EURO - VAT not included
TANGED STRAIGHT SHANK SPOTTING DRILLS, RIGHT HAND CUTTING
8612G
HSS
Orig. Hartner - Art. 81191
Type N. EXTRA-SHORT pattern.
HSS.
Very short spiral flute. It replaces pre-holes obtained by using drill bushes.
Perfect centring also on inclined surfaces.
Cylindrical shank.
With 120° cutting angle.
Ø
mm
3
4
5
6
8
10 12 16 20
Helix length
mm 12 12 14 16 21 25 30 37 45
Overall length
mm 46 55 62 66 79 89 102 115 131
8612G
Each 13,50 13,30 14,50 14,20 23,60 26,50 38,50 50,00 80,80
vuoto
TANGEDSTRAIGHTSHANKSPOTTINGDRILLS,RIGHTHANDCUTTING
8613G
HSS
Orig. Hartner - Art. 81192
Product description as Art. 8612G
With 90° cutting angle.
Ø
mm
3
4
5
6
8
10 12 16 20
Helix length
mm 12 12 14 16 21 25 30 37 45
Overall length
mm 46 55 62 66 79 89 102 115 131
8613G
Each 13,50 13,30 13,80 14,20 23,60 26,50 38,50 50,00 80,80
vuoto
TANGEDSTRAIGHTSHANKSPOTTINGDRILLS,RIGHTHANDCUTTING
TUNGSTEN-CARBIDE STUB DRILLS, RIGHT HAND CUTTING
8615G
HARTMETALL
Orig. Hartner - Art. 89242
Type N. EXTRA-SHORT pattern.
SOLID CARBIDE up to 10mm.
For manganese high-resistance steel, cast iron, aluminium alloys with high silicium content and
difficult to chip materials.
Cylindrical shank.
With 120° cutting angle.
Ø
mm
5
6
8
10
12
16
20
Helix length
mm 14
16
21
25
30
37
45
Overall length
mm 62
66
79
89
102
115
131
8615G
Each 38,40 40,50 63,70 89,70 122,00 223,00 376,00
vuoto
TUNGSTEN-CARBIDESTUBDRILLS,RIGHTHANDCUTTING
8616G
HARTMETALL
Orig. Hartner - Art. 89243
Product description as Art. 8615G
With 90° cutting angle.
Ø
mm
5
6
8
10
12
16
20
Helix length
mm 14
16
21
25
30
37
45
Overall length
mm 62
66
79
89
102
115
131
8616G
Each 35,50 39,10 60,00 86,80 116,00 214,00 365,00
vuoto
TUNGSTEN-CARBIDESTUBDRILLS,RIGHTHANDCUTTING
STUB DRILLS FOR SPOT WELDS
8616GT
HSS-E
TIN
Prod. SCU
EXTRA-SHORT type (SPOLTE-DRILL), self-centring. COBALT HSS-E, TIN coating.
For welding points and beads.
Special shank to fit pneumatic equipment.
Ø 8mm, overall length 40mm.
8616GT
Each 13,10
vuoto
STUBDRILLSFORSPOTWELDS
8617G
HSS-E
EXTRA-SHORT type, self-centring. COBALT HSS-E.
For welding points and beads.
To be used also with hand drills.
Cylindrical shank. RIGHT-HAND rotation.
Ø
mm
6
7
8
10
Overall length
mm 66
74
79
89
8617G
Each 6,40
7,46
8,52 14,20
vuoto
STUBDRILLSFORSPOTWELDS
8617GA
HSS-E
TIN
EXTRA-SHORT type, self-centring. COBALT HSS-E, TIN coating.
For welding points and beads.
To be used also with hand drills.
Cylindrical shank. RIGHT-HAND rotation.
Ø
mm
6
7
8
10
Overall length
mm 66
74
79
89
8617GA
Each 9,94 11,00 12,10 17,80
vuoto
STUBDRILLSFORSPOTWELDS
