LONG SERIES OIL FEED DRILLS, RIGHT HAND CUTTING
1136
13
Prices in EURO - VAT not included
8527G
HSS
Orig. Hartner - Art. 82523
DIN 341. Type N. HSS. Cutting angle 118°. Forced lubrication through internal cooling channels.
For steel up to R 900 N/sqmm, hardened cast iron, aluminium alloys, bronze and brass.
Morse taper shank.
Side feeding through the end of the morse taper shank.
Ø
mm
10
11
12
13
14
15
16
17*
Overall length
mm 224 233 251 251 259 255 270 267
Helix length
mm 116 125 134 134 142 147 153 159
Drive
C.M.
2
2
2
2
2
2
2
2
8527G
Each 238,00 242,00 246,00 229,00 246,00 258,00 268,00 268,00
Ø
mm
18
19*
20
21
22
24
25
26
Overall length
mm 282 303 309 320 327 342 342 350
Helix length
mm 165 171 177 184 191 206 206 214
Drive
C.M.
2
3
3
3
3
3
3
3
8527G
Each 287,00 388,00 312,00 341,00 361,00 388,00 448,00 485,00
Ø
mm
27
28
29
30
32
34*
35*
40
Overall length
mm 385 385 393 393 421 430 430 450
Helix length
mm 222 222 230 230 248 257 257 277
Drive
C.M.
4
4
4
4
4
4
4
4
8527G
Each 493,00 598,00 567,00 639,00 732,00 828,00 883,00 1.120,00
* Sizes running out of stock.
LONGSERIESOILFEEDDRILLS,RIGHTHANDCUTTING
STRAIGHT SHANK SUBLAND DRILLS 90° INCLUDED ANGLE RIGHT, HAND CUTTING
8538G
HSS
Orig. Hartner - Art. 85920
Type N. HSS. Cutting angle 118°. Countersinking angle 90°.
Cylindrical shank.
For screws
M.
3
4
5
6
8
10
12
Guide tip Ø d
mm 2,5
3,3
4,2
5
6,8
8,5
10,2
Countersink D Ø
mm 3,4
4,5
5,5
6,6
9
11
13,5
Guiding spiral I length
mm 8,8
11,4
13,6
16,5
21
25,5
30
Spiral total length.
mm 20
24
28
31
40
47
54
Overall length
mm 52
58
66
70
84
95
107
8538G
Each 25,30 25,30 27,90 29,40 35,60 45,40 60,90
STRAIGHTSHANKSUBLANDDRILLS90° INCLUDEDANGLERIGHT,HANDCUTTING
8538GE
HARTMETALL
Orig. Hartner - Art. 89254
Type N. SOLID CARBIDE. Cutting angle 120°. Countersinking angle 90°.
Cylindrical shank according to DIN 6535 HE.
For screws
M.
5
6
8
Guide tip Ø d
mm 4,2
5
6,8
Countersink D Ø
mm 5,5
6,6
9
Guiding spiral I length
mm 13,6
16,5
21
Spiral overall length
mm 28
31
40
Overall length
mm 66
70
84
Drive Ø
mm 6
8
10
8538GE
Each 83,90 119,00 157,00
STRAIGHTSHANKSUBLANDDRILLS90° INCLUDEDANGLERIGHT,HANDCUTTING
STRAIGHT SHANK SUBLAND DRILLS 90° INCLUDED ANGLE, RIGHT HAND CUTTING
8539G
HSS
Orig. Hartner - Art. 85310
DIN 8378. Type N. HSS. Cutting angle 118°.
With independent flutes. Small spiral flute for drilling. Big spiral flute with 90° countersinking angle.
Cylindrical shank.
For screws
M.
3
4
5
6
8
10
12
Guide tip Ø d
mm 2,5
3,3
4,2
5
6,8
8,5
10,2
Countersink D Ø
mm 3,4
4,5
5,5
6,6
9
11
13,5
Guiding spiral I length
mm 8,8
11,4
13,6
16,5
21
25,5
30
Spiral total length.
mm 39
47
57
63
81
94
108
Overall length
mm 70
80
93
101
125
142
160
8539G
Each 38,20 39,20 40,20 45,90 53,60 65,10 93,80
STRAIGHTSHANKSUBLANDDRILLS90° INCLUDEDANGLE,RIGHTHANDCUTTING
STRAIGHT SHANK SUBLAND DRILLS 180° INCLUDED ANGLE, RIGHT HAND CUTTING
8540G
HSS
Orig. Hartner - Art. 85918
Type N. HSS. Cutting angle 118°.
180° angle, for seats of embedded flat die screws.
Cylindrical shank.
For screws
M.
3
4
5
6
8
10
Guide tip Ø d
mm 3,4
4,5
5,5
6,6
9
11
Countersink D Ø
mm 6
8
10
11
15
18
Guiding spiral I length
mm 9
11
13
15
19
23
Spiral total length.
mm 28
37
43
47
56
62
Overall length
mm 66
79
89
95
111
123
8540G
Each 29,90 32,10 40,20 46,40 57,80 93,80
