1139 / 1378
1139
STRAIGHT SHANK SUBLAND DRILLS 90° INCLUDED ANGLE, RIGHT HAND CUTTING
1139
13
Prices in EURO - VAT not included
STRAIGHT SHANK SUBLAND DRILLS 90° INCLUDED ANGLE, RIGHT HAND CUTTING
8590G
HSS
Orig. Hartner - Art. 85710
DIN 8379. Type N. HSS. Cutting angle 118°.
With independent flutes. Small spiral flute for drilling.
Bigger spiral flute with 90° countersinking angle.
Morse taper shank.
For screws
M.
8
10
14
16
20
Guide tip Ø d
mm 6,8
8,5
12
14
17,5
Countersink D Ø
mm 9
11
15,5
17,5
22
Guiding spiral I length
mm 21
25,5
34,5
38,5
47,5
Spiral total length.
mm 81
94
120
130
150
Overall length
mm 162
175
218
228
248
Drive
C.M.
1
1
2
2
2
8590G
Each 82,50 85,60 152,00 158,00 215,00
Sizes M 14 and 20 running out of stock.
vuoto
STRAIGHTSHANKSUBLANDDRILLS 90° INCLUDEDANGLE,RIGHTHANDCUTTING
CENTRE DRILLS
8600G
8600GS
HSS
Orig. Hartner - Art. 83100
DIN 333. Form A. Cutting angle 118°.
For drilling metals and steel. 60° countersink taper.
HSS. Right-hand cutting.
Tip Ø
mm
0,5
0,8
1
1,25
1,6
2
2,5
Body Ø
mm 3,15
3,15
3,15
3,15
4
5
6,3
Overall length
mm 25
25
31,5
31,5
35,5
40
45
8600G
Each 9,92
9,54
8,74 10,30 8,74
8,36
9,92
Tip Ø
mm
3,15
4
5
6,3
8
10
Body Ø
mm 8
10
12,5
16
20
25
Overall length
mm 50
56
63
71
80
100
8600G
Each 14,10 20,20 28,50 41,80 65,90 132,00
Art. 8600 G 0.5 and 0.8mm are supplied with one cutting edge only.
vuoto
Orig. Hartner - Art. 83105
Product description as Art. 8600G
HSS. Left-hand cutting.
Tip Ø
mm
1
1,6
2
2,5
3,15
4
Body Ø
mm 3,15
4
5
6,3
8
10
Overall length
mm 31,5
35,5
40
45
50
56
8600GS
Each 13,40 13,50 15,20 15,70 20,10 27,40
vuoto
CENTREDRILLS
8601G
HSS-E
Orig. Hartner - Art. 83101
Product description as Art. 8600G
COBALT HSS-E. Right-hand cutting.
Tip Ø
mm
1
1,6
2
2,5
3,15
4
Body Ø
mm 3,15
4
5
6,3
8
10
Overall length
mm 31,5
35,5
40
45
50
56
8601G
Each 17,80 18,70 18,90 20,70 26,30 37,70
vuoto
CENTREDRILLS
8601GT
HSS
TIN
Orig. Hartner - Art. 84450
DIN 333. Form A. Cutting angle 118°. TIN-coated HSS.
For drilling metals and steel. Right-hand cutting. 60° countersink taper.
Tip Ø
mm
1
1,25
1,6
2
2,5
3.15
4
Body Ø
mm 3,15
3,15
4
5
6,3
8
10
Overall length
mm 31,5
31,5
35,5
40
45
50
56
8601GT
Each 23,30 26,60 21,50 22,70 26,60 32,10 52,10
vuoto
CENTREDRILLS
8601GV
HARTMETALL
Prod. SCU
DIN 333. Form A. Cutting angle 118°. SOLID CARBIDE.
For drilling metals and hard steel. Right-hand cutting. 60° countersink taper.
Tip Ø
mm
1
1,6
2
2,5
3,15
4
Body Ø
mm 3,15
4
5
6,3
8
10
Overall length
mm 31
40
40
45
50
56
8601GV
Each 33,10 38,10 43,40 48,50 61,20 72,10
