STRAIGHT SHANK SUBLAND DRILLS 180° INCLUDED ANGLE,, RIGHT HAND CUTTING
1137
13
Prices in EURO - VAT not included
STRAIGHT SHANK SUBLAND DRILLS 180° INCLUDED ANGLE,, RIGHT HAND CUTTING
8546G
HSS
Orig. Hartner - Art. 85210
DIN 8376. Type N. HSS. Cutting angle 118°.
With independent flutes. Small spriral flute for drilling.
180° flat stepped bigger spiral flute.
Cylindrical shank.
For screws
M.
3
4
5
6
8
10
Guide tip Ø d
mm 3,4
4,5
5,5
6,6
9
11
Countersink D Ø
mm 6
8
10
11
15
18
Guiding spiral I length
mm 9
11
13
15
19
23
Spiral total length.
mm 57
75
87
94
114
130
Overall length
mm 93
117
133
142
169
191
8546G
Each 43,80 49,10 58,80 68,10 85,60 179,00
vuoto
STRAIGHTSHANKSUBLANDDRILLS 180° INCLUDEDANGLE,,RIGHTHANDCUTTING
STRAIGHT SHANK SUBLAND DRILLS 90° INCLUDED ANGLE, RIGHT HAND CUTTING
8552G
HSS
Orig. Hartner - Art. 85916
Type N. HSS. Cutting angle 118°.
90° countersinking angle for countersink-head screw seats. FINE tolerance.
Cylindrical shank.
For screws
M.
3
4
5
6
8
10
Guide tip Ø d
mm 3,2
4,3
5,3
6,4
8,4
10,5
Countersink D Ø
mm 6
8
10
11,5
15
19
Guiding spiral I length
mm 9
11
13
15
19
23
Spiral total length.
mm 28
37
43
47
56
64
Overall length
mm 66
79
89
95
111
127
8552G
Each 29,40 32,50 41,80 49,50 62,90 94,90
vuoto
STRAIGHTSHANKSUBLANDDRILLS 90° INCLUDEDANGLE,RIGHTHANDCUTTING
8553G
HSS
Orig. Hartner - Art. 85917
Type N. HSS. Cutting angle 118°.
90° countersinking angle for countersink-head screw seats. MEDIUM tolerance.
Cylindrical shank.
For screws
M.
3
4
5
6
8
Guide tip Ø d
mm 3,4
4,5
5,5
6,6
9
Countersink D Ø
mm 6,6
9
11
13
17,2
Guiding spiral I length
mm 9
11
13
15
19
Spiral total length.
mm 31
40
47
51
62
Overall length
mm 70
84
95
102
123
8553G
Each 31,10 35,60 48,50 57,80 92,80
vuoto
STRAIGHTSHANKSUBLANDDRILLS 90° INCLUDEDANGLE,RIGHTHANDCUTTING
STRAIGHT SHANK SUBLAND DRILLS 90° INCLUDED ANGLE, RIGHT HAND CUTTING
8558G
HSS
Orig. Hartner - Art. 85010
DIN 8374. Type N. HSS. Cutting angle 118°. With independent flutes.
Small spiral flute for drilling. Bigger spiral flute with 90° countersinking angle for countersink-head
screw seats. FINE tolerance. Cylindrical shank.
For screws
M.
3
4
5
6
8
Guide tip Ø d
mm 3,2
4,3
5,3
6,4
8,4
Countersink D Ø
mm 6
8
10
11,5
15
Guiding spiral I length
mm 9
11
13
15
19
Spiral total length.
mm 57
75
87
94
114
Overall length
mm 93
117
133
142
169
8558G
Each 44,90 52,60 63,90 74,30 127,00
vuoto
STRAIGHTSHANKSUBLANDDRILLS 90° INCLUDEDANGLE,RIGHTHANDCUTTING
8559G
HSS
Orig. Hartner - Art. 85110
DIN 8374. Type N. HSS. Cutting angle 118°. With independent flutes.
Small spiral flute for drilling. Bigger spiral flute with 90° countersinking angle for countersink-head
screw seats. MEDIUM tolerance. Cylindrical shank.
For screws
M.
3
4
5
6
8
Guide tip Ø d
mm 3,4
4,5
5,5
6,6
9
Countersink D Ø
mm 6,6
9
11
13
17,2
Guiding spiral I length
mm 9
11
13
15
19
Spiral total length.
mm 63
81
94
101
130
Overall length
mm 101
125
142
151
191
8559G
Each 52,60 62,90 74,30 113,00 189,00
vuoto
STRAIGHTSHANKSUBLANDDRILLS 90° INCLUDEDANGLE,RIGHTHANDCUTTING
