MACHINE TAPS
1221
13
Prices in EURO - VAT not included
MACHINE TAPS
9162G
M
HSS-E
Orig. Völkel
REINFORCED SHANK - RIGHT-HAND USE
ISO METRIC THREAD according to DIN 13 (DIN 371) – M Coarse Metric – Tolerance ISO2/6H.
HSS-E. Universal type. Short chamfer, blind and through holes.
Ø
mm
2
2,2
2,3
2,5
2,6
3
3,5
Pitch
mm 0,4
0,45
0,4
0,45
0,45
0,5
0,6
Overall length
mm 45
45
45
50
50
56
56
Thread length
mm 8
8
9
9
9
11
13
Shank Ø
mm 2,8
2,8
2,8
2,8
2,8
3,5
4
Shank square
mm 2,1
2,1
2,1
2,1
2,1
2,7
3
Supplier code
374
-
374
374
374
374
374
9162G
Each 9,44 19,10 9,44
9,44
9,44
7,70
8,72
Ø
mm
4
5
6
7
8
10
Pitch
mm 0,7
0,8
1
1
1,25
1,5
Overall length
mm 63
70
80
80
90
100
Thread length
mm 13
16
19
19
22
24
Shank Ø
mm 4,5
6
6
7
8
10
Shank square
mm 3,4
4,9
4,9
5,5
6,2
8
Supplier code
374
374
374
374
374
374
9162G
Each 7,70
8,14
8,14 11,40 9,88 12,20
Size mm 2,2 running out of stock.
MACHINETAPS
9164G
LEFT USAGE
M
HSS-E
Orig. Völkel - Art. 334
REINFORCED SHANK - LEFT-HAND USE
ISO METRIC THREAD according to DIN 13 (DIN 371) Metric Coarse M - Tolerance ISO2/6H.
HSS-E. Short chamfer. Multi-purpose. For blind and through holes.
Ø
mm
3
4
5
6
8
10
Pitch
mm 0,5
0,7
0,8
1
1,25
1,5
Overall length
mm 56
63
70
80
90
100
Thread length
mm 11
13
16
19
22
24
Shank Ø
mm 3,5
4,5
6
6
8
10
Shank square
mm 2,7
3,4
4,9
4,9
6,2
8
9164G
Each 12,80 12,80 13,40 13,40 16,10 18,20
MACHINETAPS
9170G
M
HSS-E
Orig. Völkel - Art. 375
REINFORCED SHANK - RIGHT-HAND USE
ISO METRIC THREAD according to DIN 13 (DIN 371) – M Coarse Metric – Tolerance ISO2/6H.
HSS-E. Correct chamfer. For metals up to R 900 N/mm². Through holes.
Ø
mm
2
2,5
3
4
5
6
8
10
Pitch
mm 0,4 0,45 0,5
0,7
0,8
1
1,25 1,5
Overall length
mm 45
50
56
63
70
80
90
100
Thread length
mm 8
9
11
13
16
19
22
24
Shank Ø
mm 2,8
2,8
3,5
4,5
6
6
8
10
Shank square
mm 2,1
2,1
2,7
3,4
4,9
4,9
6,2
8
9170G
Each 10,20 10,20 7,98 7,98 8,56 8,56 10,30 12,80
On request we supply taps from M 1 a M 2,5.
MACHINETAPS
9172G
new
M
HSS-E
Orig. Völkel - Art. 320
Product description as Art. 9170G
HSS-E. Correct chamfer. For metals up to R 900 N/mm², alloyed and unalloyed. Through holes.
Type long and extra long.
Type
3
4
4A 4B
5
5A 5B
Ø
mm 3
4
4
4
5
5
5
Pitch
mm 0,5
0,7
0,7
0,7
0,8
0,8
0,8
Overall length
mm 100
100
120
150
100
120
150
Thread length
mm 11
13
13
13
16
16
16
Shank Ø
mm 3.5
4,5
4,5
4,5
6
6
6
Shank square
mm 2,7
3,4
3,4
3,4
4,9
4,9
4,9
9172G
Each 11,20 11,20 11,80 12,40 11,80 12,80 13,80
Type
6
6A 6B
8
8A 8B 10
Ø
mm 6
6
6
8
8
8
10
Pitch
mm 1
1
1
1,25
1,25
1,25
1,5
Overall length
mm 100
120
150
100
120
150
100
Thread length
mm 19
19
19
22
22
22
24
Shank Ø
mm 6
6
6
8
8
8
10
Shank square
mm 4,9
4,9
4,9
6,2
6,2
6,2
8
9172G
Each 11,80 12,80 13,80 14,10 14,80 16,90 14,80
Type
10A 10B 12
12A 12B
Ø
mm 10
10
12
12
12
Pitch
mm 1,5
1,5
1.75
1.75
1.75
Overall length
mm 120
150
100
120
150
Thread length
mm 24
24
29
29
29
Shank Ø
mm 10
10
12
12
12
Shank square
mm 8
8
9
9
9
9172G
Each 16,90 20,40 16,70 19,60 24,10
