1223 / 1378
1223
MACHINE TAPS
1223
13
Prices in EURO - VAT not included
9190G
new
M
HSS-E
Orig. Völkel - Art. 320
Product description as Art. 9170G
HSS-E. Type with helix at approximately 35 °, for threads deeper than 1 1/2 the diameter. Short
chamfer. For metals up to R 900 N / mm², alloyed and unalloyed.
Deep blind holes.
Type long and extra long.
Type
3
4
4A 4B
5
5A 5B
Ø
mm 3
4
4
4
5
5
5
Pitch
mm 0,5
0,7
0,7
0,7
0,8
0,8
0,8
Overall length
mm 100
100
120
150
100
120
150
Thread length
mm 6
7
7
7
8
8
8
Shank Ø
mm 3,5
4,5
4,5
4,5
6
6
6
Shank square
mm 2,7
3,4
3,4
3,4
4,9
4,9
4,9
9190G
Each 13,40 13,40 13,80 14,30 14,30 15,30 16,40
Type
6
6A 6B
8
8A 8B 10
Ø
mm 6
6
6
8
8
8
10
Pitch
mm 1
1
1
1,25
1,25
1,25
1,5
Overall length
mm 100
120
150
100
120
150
100
Thread length
mm 10
10
10
14
14
14
16
Shank Ø
mm 6
6
6
8
8
8
10
Shank square
mm 4,9
4,9
4,9
6,2
6,2
6,2
8
9190G
Each 14,30 15,30 16,40 16,60 17,50 19,30 18,00
Type
10A 10B 12
12A 12B
Ø
mm 10
10
12
12
12
Pitch
mm 1,5
1,5
1.75
1.75
1.75
Overall length
mm 120
150
100
120
150
Thread length
mm 16
16
18
18
18
Shank Ø
mm 10
10
12
12
12
Shank square
mm 8
8
9
9
9
9190G
Each 19,90 23,40 18,20 21,20 25,40
MACHINETAPS
9192G
INOX
M
HSS-E
VAP
Orig. Völkel - Art. 317 VAP
Product description as Art. 9170G
HSS-E. Type with approximately 35° flute for very deep threads with diameter exceeding 1 1/2.
Short chamfer. For metals up to R 900 N/mm², steel and steel alloys, stainless steels.
Very deep blind holes.
Vaporised.
Ø
mm
3
4
5
6
8
10
Pitch
mm 0,5
0,7
0,8
1
1,25
1,5
Overall length
mm 56
63
70
80
90
100
Thread length
mm 6
7
8
10
14
16
Shank Ø
mm 3,5
4,5
6
6
8
10
Shank square
mm 2,7
3,4
4,9
4,9
6,2
8
9192G
Each 10,60 10,60 11,50 11,50 13,80 17,10
MACHINETAPS
9196G
M
HSS-E
TIN
Orig. Völkel - Art. 317 TIN
Product description as Art. 9170G
HSS-E-TIN. Type with approx. 35° flute, for deep threads with dia. more than 1 1/2. Short
chamfer. For metals up to R 900 N/mm². Deep blind holes.
TIN coating.
Ø
mm
3
4
5
6
8
10
Pitch
mm 0,5
0,7
0,8
1
1,25
1,5
Overall length
mm 56
63
70
80
90
100
Thread length
mm 6
7
8
10
14
16
Shank Ø
mm 3,5
4,5
6
6
8
10
Shank square
mm 2,7
3,4
4,9
4,9
6,2
8
9196G
Each 14,10 14,10 15,10 15,90 19,30 24,90
MACHINETAPS
9201G
M
HSS-E
VAP
INOX
Orig. Völkel - Art. 356 VAP
REINFORCED SHANK
RIGHT-HAND USE
ISO METRIC THREAD according to DIN 13 (DIN 371) Metric Coarse M - Tolerance ISO3X/6GX.
HSS-E. Short chamfer. Roll taps with coolant ejection channels, chipless, for aluminium and its
alloys. Through and blind holes.
Vaporized.
Ø
mm
3
4
5
6
8
10
Pitch
mm 0,5
0,7
0,8
1
1,25
1,5
Overall length
mm 56
63
70
80
90
100
Thread length
mm 11
13
16
19
22
24
Shank Ø
mm 3,5
4,5
6
6
8
10
Shank square
mm 2,7
3,4
4,9
4,9
6,2
8
9201G
Each 16,20 18,20 19,90 19,90 23,80 27,60
MACHINETAPS
