MACHINE TAPS
1224
13
Prices in EURO - VAT not included
9202G
M
HSS-E
TIN
INOX
Orig. Völkel - Art. 356 TIN
Product description as Art. 9201G
HSS-E. Short chamfer. Perfekt type, chipless. For aluminium and aluminium alloys, metals up to R
900 N/mm², stainless steel. Roll taps with coolant ejection channels. Through and blind holes.
TIN coating.
Ø
mm
3
4
5
6
8
10
Pitch
mm 0,5
0,7
0,8
1
1,25
1,5
Overall length
mm 56
63
70
80
90
100
Thread length
mm 11
13
16
19
22
24
Shank Ø
mm 3,5
4,5
6
6
8
10
Shank square
mm 2,7
3,4
4,9
4,9
6,2
8
9202G
Each 19,20 21,10 22,70 23,60 28,50 34,40
vuoto
MACHINETAPS
9203G
M
HSS-E
Orig. Völkel - Art. 356-6G
REINFORCED SHANK
RIGHT-HAND USE
ISO METRIC THREAD according to DIN 13 (DIN 371) Metric Coarse M - Tolerance ISO3X/6GX.
HSS-E. Short chamfer. Roll taps with coolant ejection channels, chipless, for aluminium and its
alloys, brass, copper, bronze, zinc. Through and blind holes.
Ø
mm
3
4
5
6
8
10
Pitch
mm 0,5
0,7
0,8
1
1,25
1,5
Overall length
mm 56
63
70
80
90
100
Thread length
mm 11
13
16
19
22
24
Shank Ø
mm 3,5
4,5
6
6
8
10
Shank square
mm 2,7
3,4
4,9
4,9
6,2
8
9203G
Each 15,40 17,30 19,10 19,10 22,50 26,10
vuoto
MACHINETAPS
9212G
M
HSS-E
Orig. Völkel - Art. 384
REDUCED SHANK
LEFT-HAND USE
ISO METRIC THREAD according to DIN 13 (DIN 376)- Metric Coarse M - Tolerance ISO2/6H.
HSS-E. Short chamfer. Universal type. Blind and through holes.
Ø
mm
3
4
5
6
8
10
12
Pitch
mm 0,5
0,7
0,8
1
1,25
1,5
1,75
Overall length
mm 56
63
70
80
90
100
110
Thread length
mm 11
13
16
19
22
24
29
Shank Ø
mm 2,2
2,8
3,5
4,5
6
7
9
Shank square
mm -
2,1
2,7
3,4
4,9
5,5
7
9212G
Each 8,42
8,42
8,86
8,86 10,60 12,80 14,80
Ø
mm
14
16
18
20
22
24
27
Pitch
mm 2
2
2,5
2,5
2,5
3
3
Overall length
mm 110
110
125
140
140
160
160
Thread length
mm 30
32
34
34
34
38
38
Shank Ø
mm 11
12
14
16
18
18
20
Shank square
mm 9
9
11
12
14,5
14,5
16
9212G
Each 19,10 21,40 30,50 41,40 47,20 50,40 80,60
Ø
mm
30
33
36
Pitch
mm 3,5
3,5
4
Overall length
mm 180
180
200
Thread length
mm 45
50
56
Shank Ø
mm 22
25
28
Shank square
mm 18
20
22
9212G
Each 84,20 117,00 192,00
vuoto
MACHINETAPS
9213G
LEFT USAGE
M
HSS-E
Orig. Völkel - Art. 344
REDUCED SHANK
LEFT-HAND USE
ISO METRIC THREAD according to DIN 13 (DIN 376)- Metric Coarse M - Tolerance ISO2/6H.
HSS-E. Short chamfer. Multi-purpose. Blind and through holes.
Ø
mm
12
14
16
18
20
22
24
Pitch
mm 1,75
2
2
2,5
2,5
2,5
3
Overall length
mm 110
110
110
125
140
140
160
Thread length
mm 29
30
32
34
34
34
38
Shank Ø
mm 9
11
12
14
16
18
18
Shank square
mm 7
9
9
11
12
14,5
14,5
9213G
Each 21,70 32,10 36,30 49,40 69,70 72,60 75,50
vuoto
MACHINETAPS
