MACHINE TAPS
1222
13
Prices in EURO - VAT not included
9174G
M
HSS-E
TIN
Orig. Völkel - Art. 315 TIN
Product description as Art. 9170G
HSS-E-TIN. Correct chamfer. For metals up to R 900 N/mm². Through holes. TIN coating.
Ø
mm
3
4
5
6
8
10
Pitch
mm 0,5
0,7
0,8
1
1,25
1,5
Overall length
mm 56
63
70
80
90
100
Thread length
mm 11
13
16
19
22
24
Shank Ø
mm 3,5
4,5
6
6
8
10
Shank square
mm 2,7
3,4
4,9
4,9
6,2
8
9174G
Each 12,50 12,50 13,10 14,10 17,20 22,30
vuoto
MACHINETAPS
9180G
INOX
M
HSS-E
VAP
Orig. Völkel - Art. 315 VAP
Product description as Art. 9170G
HSS-E. Correct chamfer. For metals up to R 900 N/mm², stainless steel. Through holes.
Vaporized.
Ø
mm
3
4
5
6
8
10
Pitch
mm 0,5
0,7
0,8
1
1,25
1,5
Overall length
mm 56
63
70
80
90
100
Thread length
mm 11
13
16
19
22
24
Shank Ø
mm 3,5
4,5
6
6
8
10
Shank square
mm 2,7
3,4
4,9
4,9
6,2
8
9180G
Each 8,78
8,78
9,44
9,44 11,40 14,10
vuoto
MACHINETAPS
9186G
M
HSS-E
Orig. Völkel - Art. 376
Product description as Art. 9170G
HSS-E. Semi-short chamfer. Helicoidal type with approx.15° flute, for metals up to R 900 N/mm².
Blind holes.
Ø
mm
3
4
5
6
8
10
Pitch
mm 0,5
0,7
0,8
1
1,25
1,5
Overall length
mm 56
63
70
80
90
100
Thread length
mm 11
13
16
19
22
24
Shank Ø
mm 3,5
4,5
6
6
8
10
Shank square
mm 2,7
3,4
4,9
4,9
6,2
8
9186G
Each 10,50 10,50 11,20 11,20 13,70 16,70
vuoto
MACHINETAPS
9187G
M
HSS-E
Orig. Völkel - Art. 379
Product description as Art. 9170G
HSS-E. Proper chamfer. Allzweck type with alternate threads, for metals up to R 900 N/mm², steel
and steel alloys. Through holes.
Ø
mm
3
4
5
6
8
10
Pitch
mm 0,5
0,7
0,8
1
1,25
1,5
Overall length
mm 56
63
70
80
90
100
Thread length
mm 11
13
16
19
22
24
Shank Ø
mm 3,5
4,5
6
6
8
10
Shank square
mm 2,7
3,4
4,9
4,9
6,2
8
9187G
Each 10,60 10,60 11,50 11,50 14,10 16,70
vuoto
MACHINETAPS
9188G
M
HSS-E
Orig. Völkel - Art. 377
Product description as Art. 9170G
HSSE-E. Type with approx. 35° flute, for deep threads with dia. more than 1 1/2. Short chamfer.
For metals up to R 900 N/mm².
Deep blind holes.
Ø
mm
3
4
5
6
8
10
Pitch
mm 0,5
0,7
0,8
1
1,25
1,5
Overall length
mm 56
63
70
80
90
100
Thread length
mm 6
7
8
10
14
16
Shank Ø
mm 3,5
4,5
6
6
8
10
Shank square
mm 2,7
3,4
4,9
4,9
6,2
8
9188G
Each 9,58
9,58 10,50 10,50 12,50 15,40
On request we supply taps from M 1 to M 2,5.
MACHINETAPS
