DIN 69871/A MORSE CONE REDUCTION CHUCKS FOR MILLING CUTTERS
452
6
Prices in EURO - VAT not included
DIN 69871/A MORSE CONE REDUCTION CHUCKS FOR MILLING CUTTERS
1560GBF
Prod. SCU
For milling cutters with Morse taper shank, internally threaded. High-precision, max centring of
milling cutters with the highest turning moments.
DIN 69871/A shank, internally threaded end.
Mills drive K1
C.M.
1
2
3
4
Shape/ thread K/G
ISO 40
M16
ISO 40
M16
ISO 40
M16
ISO 40
M16
Height L
mm 50
50
70
95
Height d1
mm 25
32
40
48
1560GBF
Each 137,00 137,00 141,00 148,00
vuoto
DIN 69871/AMORSECONEREDUCTIONCHUCKSFORMILLINGCUTTERS
DIN 69871/A MORSE CONE REDUCTION CHUCKS FOR DRILLS
1560GBL
Prod. SCU
For drill bits with Morse taper shank. High-precision, max centring of drill bits with the highest
turning moments.
DIN 69871/A shank, internally threaded end.
Tips drive K1
C.M.
1
2
3
4
Shape/ thread K/G
ISO 40
M16
ISO 40
M16
ISO 40
M16
ISO 40
M16
Height L
mm 50
50
70
95
Height d1
mm 25
32
40
48
1560GBL
Each 133,00 133,00 137,00 145,00
vuoto
DIN 69871/AMORSECONEREDUCTIONCHUCKSFORDRILLS
DIN 69871/A MONOLITHIC DRILL CHUCKS
1560GBM
Prod. SCU
For drill bits with cylindrical shank. High-precision, max centring of drill bits with the highest
turning moments.
DIN 69871/A shank, internally threaded end.
For tips Ø up to
mm
13
16
Shape/ thread K/G
ISO 40
M16
ISO 40
M16
Height L
mm 100
110
Height D
mm 51
58
1560GBM
Each 409,00 432,00
vuoto
DIN 69871/AMONOLITHICDRILLCHUCKS
DIN 69871/A DRILL HOLDER CHUCKS
1560GBP
Prod. SCU
For chucks with "B" shank. High-precision, max centring of drill bits with the highest turning
moments.
DIN 69871/A shank, internally threaded end.
Type
1
2
3
4
Shape/ thread K/G
ISO 40
M16
ISO 40
M16
ISO 50
M24
ISO 50
M24
Chuck drive "B" K1
B12
B16
B16
B18
Height L
mm 40
40
40
40
1560GBP
Each 132,00 132,00 200,00 200,00
vuoto
DIN 69871/ADRILLHOLDERCHUCKS
