DRILLS FOR METALS, RIGHT-HAND ROTATION
1132
13
Prices in EURO - VAT not included
DRILLS FOR METALS, RIGHT-HAND ROTATION
8500G
HSS
Orig. Hartner - Art. 82010
DIN 345. Type N. HSS. Cutting angle 118°.
For steel up to R 900 N/sqmm, cast iron, spheroidal cast iron, aluminium and aluminium alloys,
bronze and brass.
Morse taper shank.
Ø
mm
6 6,25*
6,5 6,75
7 7,25*
7,5
8
8,5 8,75
9 9,25*
9,5 9,75*
10
Overall length
mm 138 144 144 150 150 150 150 156 156 162 162 162 162 168 168
Helix length
mm 57
53
63
69
69
69
69
75
75
81
81
81
81
87
87
Drive
C.M.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
8500G
Each 29,10 48,30 28,50 31,10 28,50 50,90 32,90 26,10 28,50 47,20 28,10 46,30 33,40 46,30 28,50
Ø
mm
10,25 10,5 10,75 11 11,25 11,5 11,75 12 12,25 12,5 12,75 13 13,25 13,5 13,75
Overall length
mm 168 168 175 175 175 175 175 182 182 182 182 182 189 189 189
Helix length
mm 87
87
94
94
94
94
94 101 101 101 101 101 108 108 108
Drive
C.M.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
8500G
Each 47,20 30,10 46,70 31,10 55,00 35,40 45,20 32,10 49,20 33,90 48,20 34,90 50,10 39,30 50,10
Ø
mm
14 14,25 14,5 14,75 15 15,25 15,5 15,75 16 16,25 16,5 16,75 17 17,25 17,5
Overall length
mm 189 212 212 212 212 218 218 218 218 223 223 223 223 228 228
Helix length
mm 108 114 114 114 114 120 120 120 120 125 125 125 125 130 130
Drive
C.M.
1
2
2
2
2
2
2
2
2
2
2
2
2
2
2
8500G
Each 36,40 60,10 38,80 65,90 40,80 60,10 44,20 58,10 44,20 69,80 47,70 63,90 50,10 68,80 51,10
Ø
mm
17,75 18 18,25 18,5 18,75 19 19,25 19,5 19,75 20 20,25 20,5 20,75 21 21,25
Overall length
mm 228 228 233 233 233 233 238 238 238 238 243 243 243 243 248
Helix length
mm 130 130 135 135 135 135 140 140 140 140 145 145 145 145 150
Drive
C.M.
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
8500G
Each 65,90 53,10 75,70 57,10 72,70 57,10 84,50 65,90 81,60 60,90 95,30 64,90 91,40 68,80 99,20
Ø
mm
21,5 21,75 22 22,25 22,5 22,75 23 23,25 23,5 23,75 24 24,5 24,75 25 25,25
Overall length
mm 248 248 248 248 253 253 253 276 276 281 281 281 281 281 286
Helix length
mm 150 150 150 150 155 155 155 155 155 160 160 160 160 160 165
Drive
C.M.
2
2
2
2
2
2
2
3
3
3
3
3
3
3
3
8500G
Each 78,60 94,30 76,70 99,20 82,60 99,20 89,40 124,00 88,40 131,00 93,40 96,30 143,00 105,00 145,00
Ø
mm
25,5 25,75 26 26,25 26,5 27 27,25 27,5 27,75 28 28,5 28,75 29 29,25 29,5
Overall length
mm 286 286 286 286 286 291 291 291 291 291 296 296 296 296 296
Helix length
mm 165 165 165 165 165 170 170 170 170 170 175 175 175 175 175
Drive
C.M.
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
8500G
Each 107,00 148,00 118,00 173,00 115,00 118,00 187,00 122,00 194,00 129,00 161,00 242,00 141,00 234,00 146,00
Ø
mm
29,75 30 30,5 31 31,25 31,5 31,75 32 32,5 33 33,5 34 34,5 35 35,5
Overall length
mm 296 296 301 301 301 301 306 334 334 334 334 339 339 339 339
Helix length
mm 175 175 180 180 180 180 185 185 185 185 185 190 190 190 190
Drive
C.M.
3
3
3
3
3
3
3
4
4
4
4
4
4
4
4
8500G
Each 196,00 141,00 172,00 168,00 276,00 191,00 199,00 176,00 215,00 190,00 222,00 221,00 258,00 226,00 279,00
Ø
mm
36 36,5 37 37,5 38 38,5 39 39,5 40 40,5 41 41,5 42 42,5*
43
Overall length
mm 344 344 344 344 349 349 349 349 349 354 354 354 354 354 359
Helix length
mm 195 195 195 195 200 200 200 200 200 205 205 205 205 205 210
Drive
C.M.
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
8500G
Each 244,00 287,00 266,00 299,00 281,00 354,00 311,00 387,00 321,00 415,00 342,00 423,00 378,00 360,00 395,00
Ø
mm
43,5 44 44,5*
45 45,5 46 46,5 47 47,5 48 48,5 49 49,5 50
51
Overall length
mm 359 359 359 359 364 364 364 364 364 369 369 369 369 369 412
Helix length
mm 210 210 210 210 215 215 215 215 215 220 220 220 220 220 225
Drive
C.M.
4
4
4
4
4
4
4
4
4
4
4
4
4
4
5
8500G
Each 478,00 417,00 444,00 433,00 531,00 450,00 590,00 484,00 668,00 492,00 619,00 541,00 649,00 531,00 668,00
Ø
mm
52
53
54
55
56
57
58
59
60
Overall length
mm 412 412 417 417 417 422 422 422 422
Helix length
mm 225 225 230 230 230 235 235 235 235
Drive
C.M.
5
5
5
5
5
5
5
5
5
8500G
Each 688,00 776,00 747,00 767,00 826,00 816,00 875,00 963,00 934,00
* Sizes running out of stock.
DRILLSFORMETALS,RIGHT-HANDROTATION
8503G
HSS-E
Orig. Hartner - Art. 82011
DIN 345. Type N. COBALT HSS-E. Cutting angle 118°.
Thinned cutting edge according to DIN 1412 A.
For steel up to R 1000 N/sqmm, cast iron, hardened cast iron, graphite, aluminium alloys, bronze
and brass.
Morse taper shank.
Ø
mm
6
7*
8*
9
10 10,5 11*
11,5 12 12,5*
13 13,5 14 14,5 14,75*
Overall length
mm 138 150 156 162 168 168 175 175 182 182 182 189 189 212 212
Helix length
mm 57
69
75
81
87
87
94
94 101 101 101 108 108 114 114
Drive
C.M.
1
1
1
1
1
1
1
1
1
1
1
1
1
2
2
8503G
Each 63,50 54,30 60,60 59,70 58,70 63,50 63,50 76,10 67,30 72,20 71,20 89,50 79,80 89,50 117,00
Ø
mm
15 15,25 15,5 15,75 16 16,25 16,5 16,75 17 17,25 17,5 18 18,5 18,75* 19,5
Overall length
mm 212 218 218 218 218 223 223 223 223 228 228 228 233 233 238
Helix length
mm 114 120 120 120 120 125 125 125 125 130 130 130 135 135 140
Drive
C.M.
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
8503G
Each 91,40 129,00 93,30 112,00 97,20 131,00 102,00 125,00 102,00 122,00 97,20 104,00 119,00 110,00 142,00
SEGUE >>>
