LONG DRILLS FOR METALS, RIGHT-HAND ROTATION
1129
13
Prices in EURO - VAT not included
Ø
mm
7,2*
7,3 7,4*
7,5 7,6*
7,7*
7,8*
7,9*
8
8,1*
8,2 8,3*
8,4*
8,5 8,6
Overall length
mm 156 156 156 156 165 165 165 165 165 165 165 165 165 165 175
Helix length
mm 102 102 102 102 109 109 109 109 109 109 109 109 109 109 115
8482G
Each 35,60 40,10 29,10 29,90 42,30 42,90 37,90 37,90 27,70 31,40 38,90 44,60 46,80 36,70 45,10
Ø
mm
8,7*
8,8 8,9*
9
9,1*
9,2*
9,3*
9,4*
9,5 9,6*
9,7 9,8 9,9
10 10,8*
Overall length
mm 175 175 175 175 175 175 175 175 175 184 184 184 184 184 195
Helix length
mm 115 115 115 115 115 115 115 115 115 121 121 121 121 121 128
8482G
Each 42,30 45,10 46,20 33,90 54,20 52,50 55,30 65,40 53,60 72,20 75,60 72,20 86,90 41,80 128,00
Ø
mm
11 11,2* 11,5 11,8 12 12,2 12,5 12,8 13
Overall length
mm 195 195 195 195 205 205 205 205 205
Helix length
mm 128 128 128 128 134 134 134 134 134
8482G
Each 63,20 136,00 106,00 131,00 77,80 159,00 84,60 88,10 89,10
Up to Ø 6.5mm in 10pcs packing units. - * Sizes running out of stock.
vuoto
LONGDRILLSFORMETALS,RIGHT-HANDROTATION
8487G
HSS-E
Orig. Hartner - Art. 81341
DIN 340. Type FN. COBALT HSS-E. Cutting angle 130°.
LONG pattern.
Thinned cutting edge according to DIN 1412 A.
For very high-resistance steel, grey cast iron, spheroidal cast iron, stainless steel and spring
steel.
Cylindrical shank.
Ø
mm
1 1,1*
1,2 1,3*
1,4*
1,5 1,6 1,7*
1,8 1,9
2 2,1*
2,2 2,3*
2,4 2,5
Overall length
mm 56 60 65 65 70 70 76 76 80 80 85 85 90 90 95 95
Helix length
mm 33 37 41 41 45 45 50 50 53 53 56 56 59 59 62 62
8487G
Each 16,10 16,60 18,90 15,50 15,10 15,40 17,50 15,70 17,30 16,50 12,10 12,30 15,30 12,60 15,40 12,60
Ø
mm
2,6*
2,7 2,9
3
3,1 3,2 3,3 3,4 3,5 3,6 3,7 3,8 3,9
4 4,1*
4,2
Overall length
mm 95 100 100 100 106 106 106 112 112 112 112 119 119 119 119 119
Helix length
mm 62 66 66 66 69 69 69 73 73 73 73 78 78 78 78 78
8487G
Each 14,40 16,20 18,10 13,20 15,80 15,60 17,40 16,80 15,60 17,30 17,30 16,80 17,70 16,60 18,50 18,40
Ø
mm
4,3 4,4*
4,5 4,6*
4,7 4,8 4,9
5 5,1*
5,2*
5,3*
5,4*
5,5 5,6 5,7 5,8*
Overall length
mm 126 126 126 126 126 132 132 132 132 132 132 139 139 139 139 139
Helix length
mm 82 82 82 82 82 87 87 87 87 87 87 91 91 91 91 91
8487G
Each 19,40 21,80 19,70 22,60 21,10 22,60 22,60 19,70 19,40 22,60 20,50 20,70 23,20 30,50 29,40 24,90
Ø
mm
5,9*
6
6,1 6,2*
6,3 6,4 6,5 6,6 6,7*
6,8 6,9
7 7,1*
7,2*
7,3*
7,4*
Overall length
mm 139 139 148 148 148 148 148 148 148 156 156 156 156 156 156 156
Helix length
mm 91 91 97 97 97 97 97 97 97 102 102 102 102 102 102 102
8487G
Each 22,40 24,30 32,20 23,70 33,90 31,60 27,10 32,20 26,70 32,70 36,70 31,10 35,50 46,80 41,80 49,70
Ø
mm
7,5 7,6*
7,7*
7,8 7,9*
8 8,2*
8,3 8,4*
8,6 8,7 8,8 8,9*
9*
9,1*
9,2*
Overall length
mm 156 165 165 165 165 165 165 165 165 175 175 175 175 175 175 175
Helix length
mm 102 109 109 109 109 109 109 109 109 115 115 115 115 115 115 115
8487G
Each 37,80 49,70 53,10 55,30 56,40 32,70 42,10 57,50 59,80 59,80 56,40 65,40 68,80 39,10 69,90 74,50
Ø
mm
9,3*
9,4*
9,5*
9,6*
9,7 9,8*
9,9*
10 10,5 11 11,5*
Overall length
mm 175 175 175 184 184 184 184 184 184 195 195
Helix length
mm 115 115 115 121 121 121 121 121 121 128 128
8487G
Each 74,50 55,60 47,90 83,50 83,50 89,10 91,40 63,20 84,60 94,80 95,90
Up to Ø 6.7mm in 10pcs packing units. - * Sizes running out of stock.
vuoto
LONGDRILLSFORMETALS,RIGHT-HANDROTATION
8490G
HSS
TIN
Orig. Hartner - Art. 84418
DIN 340. Type N. HSS-TIN. Cutting angle 118°. LONG pattern.
Sharpening according to DIN 1414, form N. TIN-treated surface.
For steel up to R 900/sqmm, cast iron, spheroidal cast iron, aluminium and short-chip aluminium
alloys, bronze, brass.
Cylindrical shank.
Ø
mm
1
1.5
2
2,2*
2,5 2,8
3
3,3 3,8
4
4,2 4,5*
5
5,2*
5,5
Overall length
mm 56
70
85
90
95 100 100 106 119 119 119 126 132 132 139
Helix length
mm 33
45
56
59
62
66
66
69
78
78
78
82
87
87
91
8490G
Each 18,90 16,10 14,20 12,70 14,20 17,40 14,50 15,20 16,50 15,80 15,80 13,80 17,40 15,50 18,90
Ø
mm
5,8*
6
6,2*
6,8*
7
7,2 7,5*
7,8
8
8,2*
8,5 8,8*
9
9,2*
9,5
Overall length
mm 139 139 148 156 156 156 156 165 165 165 165 175 175 175 175
Helix length
mm 91
91
97 102 102 102 102 109 109 109 109 115 115 115 115
8490G
Each 19,70 19,30 26,70 33,60 33,20 42,10 29,10 42,10 34,40 31,90 38,20 37,70 38,80 39,40 47,10
Ø
mm
9,8*
10 10,2* 10,5* 10,8* 11,5 12
Overall length
mm 184 184 184 184 195 195 205
Helix length
mm 121 121 121 121 128 128 134
8490G
Each 55,40 41,10 42,90 42,90 64,20 62,10 59,80
Up to Ø 6.5mm in 10pcs packing units. - * Sizes running out of stock.
