CARBIDE TIPPED TWIST DRILLS, RIGHT-HAND ROTATION
1134
13
Prices in EURO - VAT not included
8513G
HARTMETALL
Prod. SCU
Similar to DIN 345. HSS body.
SOLID CARBIDE cutting edges.
Cutting angle 120°.
For manganese hardened steel, nickel, cast iron, bronze, brass, aluminium, bakelite, etc. with
resistance ranging from R 700N/sqmm to R 2300 N/sqmm.
Morse taper shank.
Ø
mm
10 14,5 35
36
37
38
39
Overall length
mm 168 212 339 344 344 349 349
Helix length
mm 87 114 190 195 195 200 200
Drive
C.M.
1
2
4
4
4
4
4
8513G
Each 51,10 62,30 443,00 414,00 447,00 468,00 494,00
Product running out of stock.
CARBIDETIPPEDTWISTDRILLS,RIGHT-HANDROTATION
LONG DRILLS FOR METALS, RIGHT-HAND ROTATION
8515G
HSS
Orig. Hartner - Art. 82210
DIN 341. Type N. HSS. Cutting angle 118°. LONG pattern.
For steel up to R 900N/sqmm, cast iron, spheroidal cast iron, aluminium and aluminium alloys,
bronze and brass.
Morse taper shank.
Ø
mm
6,5*
7
7,5*
8
8,5 9,5*
10 10,5*
11 11,5*
12*
12,5 13 13,5 14
Overall length
mm 167 174 174 181 181 188 197 197 206 206 215 215 215 223 223
Helix length
mm 86
93
93 100 100 107 116 116 125 125 134 134 134 142 142
Drive
C.M.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
8515G
Each 26,80 39,30 29,30 35,40 35,90 35,50 41,30 42,80 43,30 43,30 43,30 43,80 43,80 48,70 49,20
Ø
mm
14,5 15 15,5 16 16,5 17 17,5 18 18,5 19 19,5 20 20,5 21 21,5
Overall length
mm 245 245 251 251 257 257 263 263 269 269 275 275 282 282 289
Helix length
mm 147 147 153 153 159 159 165 165 171 171 177 177 184 184 191
Drive
C.M.
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
8515G
Each 62,90 60,90 60,10 64,90 68,80 67,80 76,70 76,70 85,50 83,50 97,30 91,40 116,00 106,00 126,00
Ø
mm
22 22,5 23
24
25
26
27
28
29
30
33
34
35
36 37*
Overall length
mm 289 296 296 327 327 335 343 343 351 351 397 406 406 416 416
Helix length
mm 191 198 198 206 206 214 222 222 230 230 248 257 257 267 267
Drive
C.M.
2
2
2
3
3
3
3
3
3
3
4
4
4
4
4
8515G
Each 115,00 127,00 119,00 146,00 147,00 169,00 181,00 203,00 234,00 232,00 299,00 380,00 364,00 417,00 397,00
Ø
mm
38
39 40*
41*
43*
44*
47*
48*
49
50
Overall length
mm 426 426 426 436 447 447 459 470 470 470
Helix length
mm 277 277 277 287 298 298 310 321 321 321
Drive
C.M.
4
4
4
4
4
4
4
4
4
4
8515G
Each 454,00 484,00 501,00 483,00 524,00 586,00 637,00 730,00 855,00 835,00
* Sizes running out of stock.
vuoto
LONGDRILLSFORMETALS,RIGHT-HANDROTATION
EXTRA-LONG DRILLS FOR METALS, RIGHT-HAND ROTATION
8520G
HSS
Orig. Hartner - Art. 82340
DIN 1870. Type FNR1. HSS. Cutting angle 130°,
EXTRA-LONG pattern.
For steel up to 900 N/sqmm, cast iron, bronze and brass.
For deep holes up to 10 times the drill diameter, without chip discharge.
Morse taper shank.
Ø
mm
8
9
9,5*
10 10,5 11 11,5*
12 12,5*
13 13,5 14
15
16
17
Overall length
mm 265 275 275 285 285 300 300 310 310 310 325 325 340 355 355
Helix length
mm 165 175 175 185 185 195 195 205 205 205 220 220 220 230 230
Drive
C.M.
1
1
1
1
1
1
1
1
1
1
1
1
2
2
2
8520G
Each 81,20 93,60 118,00 108,00 135,00 111,00 119,00 115,00 113,00 126,00 141,00 136,00 148,00 155,00 161,00
Ø
mm
17,5 18 18,5*
19
20 20,5 21
22
23
24
25 26,5*
28 28,5*
29*
Overall length
mm 370 370 370 370 385 385 385 405 405 440 440 440 460 460 460
Helix length
mm 245 245 245 245 260 260 260 270 270 290 290 290 305 305 305
Drive
C.M.
2
2
2
2
2
2
2
2
2
3
3
3
3
3
3
8520G
Each 173,00 173,00 161,00 196,00 224,00 334,00 264,00 269,00 330,00 370,00 364,00 405,00 465,00 457,00 464,00
Ø
mm
30
Overall length
mm 460
Helix length
mm 305
Drive
C.M.
3
8520G
Each 517,00
* Sizes running out of stock.
