DRILLS FOR METALS, RIGHT-HAND ROTATION
1133
13
Prices in EURO - VAT not included
Ø
mm
19,75*
20 20,25* 20,5 21 21,25* 21,5 21,75*
22 22,5*
23 23,5*
24 24,5 25
Overall length
mm 238 238 243 243 243 248 248 248 248 253 253 276 281 281 281
Helix length
mm 140 140 145 145 145 150 150 150 150 155 155 155 160 160 160
Drive
C.M.
2
2
2
2
2
2
2
2
2
2
2
3
3
3
3
8503G
Each 137,00 120,00 159,00 132,00 143,00 189,00 187,00 203,00 165,00 191,00 186,00 188,00 214,00 227,00 214,00
Ø
mm
25,5*
26 26,5 27 27,5 28 28,5 29 29,5*
30
31 31,5 32
33 34*
Overall length
mm 286 286 286 291 291 291 296 296 296 296 301 301 334 334 339
Helix length
mm 165 165 165 170 170 170 175 175 175 175 180 180 185 185 190
Drive
C.M.
3
3
3
3
3
3
3
3
3
3
3
3
4
4
4
8503G
Each 236,00 250,00 293,00 275,00 325,00 314,00 356,00 327,00 343,00 304,00 356,00 445,00 374,00 399,00 402,00
Ø
mm
36*
37*
38
39 40*
42*
43 45*
46*
47*
Overall length
mm 344 344 349 349 349 354 359 359 364 364
Helix length
mm 195 195 200 200 200 205 210 210 215 215
Drive
C.M.
4
4
4
4
4
4
4
4
4
4
8503G
Each 480,00 463,00 587,00 645,00 712,00 891,00 1.030,00 779,00 768,00 963,00
* Sizes running out of stock.
vuoto
DRILLSFORMETALS,RIGHT-HANDROTATION
DRILLS FOR STAINLESS STEEL AND ALLOYS, RIGHT-HAND ROTATION
8510G
INOX
HSS-E
Orig. Hartner - Art. 82012
DIN 345. Type IS Inox-Drill. COBALT HSS-E. Cutting angle 130°.
Particular drill geometry with special spiral flute and web shape for easier chip ejection.
For stainless steel V2A and V4A, aluminium and copper alloys.
Morse taper shank.
Ø
mm
10*
10,2* 10,5* 11,5 12*
12,8* 13,5*
14 14,25*
15 15,25* 15,75 16*
16,5 17
Overall length
mm 168 168 168 175 182 182 189 189 212 212 218 218 218 223 223
Helix length
mm 87
87
87
94 101 101 108 108 114 114 120 120 120 125 125
Drive
C.M.
1
1
1
1
1
1
1
1
2
2
2
2
2
2
2
8510G
Each 61,50 63,50 63,50 105,00 86,10 84,10 115,00 98,10 125,00 118,00 128,00 140,00 105,00 133,00 118,00
Ø
mm
17,25* 17,5 18 18,5*
20
21 22*
22,5*
23*
23,5*
24*
25*
26 27,5*
28*
Overall length
mm 228 228 228 233 238 243 248 253 253 276 281 281 286 291 291
Helix length
mm 130 130 130 135 140 145 150 155 155 155 160 160 165 170 170
Drive
C.M.
2
2
2
2
2
2
2
2
2
3
3
3
3
3
3
8510G
Each 138,00 130,00 133,00 111,00 149,00 176,00 161,00 198,00 195,00 197,00 204,00 269,00 299,00 422,00 366,00
Ø
mm
29*
29,5*
30*
31*
31,5*
32*
Overall length
mm 296 296 296 301 301 334
Helix length
mm 175 175 175 180 180 185
Drive
C.M.
3
3
3
3
3
4
8510G
Each 297,00 431,00 283,00 454,00 529,00 486,00
* Sizes running out of stock.
vuoto
DRILLSFORSTAINLESSSTEELANDALLOYS,RIGHT-HANDROTATION
CARBIDE TIPPED TWIST DRILLS, RIGHT-HAND ROTATION
8512G
HARTMETALL
Prod. SCU - Art. 89302
DIN 8041. Type N. HSS body.
SOLID CARBIDE K 10/20 cutting edges.
Cutting angle 118°.
For high-resistance hardened steel, manganese, nickel, cast iron, bronze, brass, bakelite,
glassfiber reinforced plastics, etc.
Morse taper shank.
Ø
mm
10 11*
11,5 12 12,5 13
14 14,5 15
16
17
18
19
20
23
Overall length
mm 140 140 146 146 146 146 168 168 168 175 175 185 185 215 225
Helix length
mm 50
50
56
56
56
56
63
63
63
70
70
80
80
90 100
Drive
C.M.
1
1
1
1
1
1
2
2
2
2
2
2
2
3
3
8512G
Each 75,20 61,30 85,30 76,70 97,40 94,10 94,10 116,00 102,00 105,00 110,00 110,00 113,00 147,00 178,00
Ø
mm
24*
25
Overall length
mm 225 225
Helix length
mm 100 100
Drive
C.M.
3
3
8512G
Each 163,00 184,00
* Sizes running out of stock.
vuoto
CARBIDETIPPED TWISTDRILLS,RIGHT-HANDROTATION
